FUJITSU Server PRIMERGY

FUJITSU Server PRIMERGY systems deliver workload-optimized x86 industry standard servers for any workload and business demand. Since there is no single server solution to meet all these needs, Fujitsu offers a broad server portfolio consisting of expandable tower servers, versatile rack-mount servers, density-optimized multi-node servers as well as GPU servers purpose-built for the demands of AI and VDI. While all these systems are designed to handle multiple workloads, each server is optimized for specific use cases. Whatever the size of your business – large enterprise with multiple sites, or a small or medium-sized company with limited space and budget – with the right choice of server, your IT can become the business enabler you have always wanted it to be.

Your infrastructure for the data-driven world

The new portfolio of FUJITSU Server PRIMERGY M6 systems adds another foundational building block for this data-driven transformation. The new servers will support our customers to process and analyze massive amounts of data and to provide a solid foundation for today’s hybrid IT reality. Listen to our new podcast that will provide you with more insights about the new features and benefits.

Fujitsu_Global · Your infrastructure for the data-driven world: The PRIMERGY M6 server generation

ccp

Your infrastructure for the data-driven world

The world is changing massively because of the pandemic. Wherever possible, we work from home to protect not only ourselves but also other people. Companies, schools and other institutions are now facing new challenges. With our new PRIMERGY server generation, we help our customers to move, store and process huge amounts of data and create a solid foundation for today's hybrid IT reality.

Find the right server

	FUJITSU Server PRIMERGY RX1330 M5	FUJITSU Server PRIMERGY TX1330 M4	FUJITSU Server PRIMERGY RX1330 M4	FUJITSU Server PRIMERGY RX2520 M5	FUJITSU Server PRIMERGY RX2530 M5	FUJITSU Server PRIMERGY RX2540 M5	Serwer FUJITSU PRIMERGY RX4770 M6	FUJITSU Server PRIMERGY RX4770 M5	Serwer FUJITSU Serwer PRIMERGY TX1310 M3	FUJITSU Server PRIMERGY TX1320 M4	FUJITSU Server PRIMERGY TX2550 M5	Serwer Fujitsu PRIMERGY GX2460 M1	FUJITSU Server PRIMERGY GX2570 M6	FUJITSU Server PRIMERGY CX2550 M5	FUJITSU Serwer PRIMERGY CX400 M4	FUJITSU Server PRIMERGY CX2560 M5	FUJITSU Server PRIMERGY CX2550 M6	FUJITSU Server PRIMERGY CX2560 M6	FUJITSU Server PRIMERGY CX400 M6	FUJITSU Server PRIMERGY RX2450 M1	FUJITSU Server PRIMERGY RX2530 M6	FUJITSU Server PRIMERGY RX2540 M6
Chipset	Intel^® C256	Intel^® C246	Intel^® C246	Intel^® C624	Intel^® C624	Intel^® C624	Intel^® C621A	Intel^® C624	Intel^® C236	Intel^® C246	Intel^® C624	-	-	Intel^® C621	-	Intel^® C624	Intel^® C621A	Intel^® C621A	-	-	Intel^® C621A	Intel^® C621A
Mainboard type	D3929	D3673	D3675	D3386-B	D3383-B	D3384-B	-	D3753	-	D3673	D3386-B	-	MBD-X12DGO-6	D 3853	-	D 3853	D 3893	D 3894	-	MBD-H12DSU-IN-P	D3890	D3891
Product Type	Mono Socket Rack Server	Mono Socket Tower Server	Mono Socket Rack Server	Dual Socket Rack Server	Dual Socket Rack Server	Dual Socket Rack Server	-	Quad Socket Rack Server	-	Mono Socket Tower Server	Dual Socket Tower Server	-	Dual Socket Rack Server	Dual Socket 1U Server Node	-	Dual Socket 1U Server Node	Dual Socket 1U Server Node	Dual Socket 1U Server Node	Multi-Node Server Chassis	Dual Socket Rack Server	Dual Socket Rack Server	Dual Socket Rack Server
Processor	Intel^® Xeon^® E-2300 processor family, Intel^® Pentium^® processor	Intel^® Xeon^® E-2200 processor family, Intel^® Xeon^® E-2100 processor family, Intel^® Pentium^® processor, Intel^® Core™ i3 processor	Intel^® Xeon^® E-2200 processor family, Intel^® Xeon^® E-2100 processor family, Intel^® Celeron^® processor, Intel^® Core™ i3 processor, Intel^® Pentium^® processor	Intel^® Xeon^® Bronze 3xxx processor, Intel^® Xeon^® Silver 4xxx processor, Intel^® Xeon^® Gold 5xxx processor 1 - 2	Intel^® Xeon^® Bronze 3xxx processor, Intel^® Xeon^® Silver 4xxx processor, Intel^® Xeon^® Gold 5xxx processor, Intel^® Xeon^® Gold 6xxx processor, Intel^® Xeon^® Platinum 8xxx processor 1 - 2 x Intel^® Xeon^® Processor Scalable Family	Intel^® Xeon^® Bronze 3xxx processor, Intel^® Xeon^® Silver 4xxx processor, Intel^® Xeon^® Gold 5xxx processor, Intel^® Xeon^® Gold 6xxx processor, Intel^® Xeon^® Platinum 8xxx processor 1 - 2	-	Intel^® Xeon^® Gold 5xxx processor, Intel^® Xeon^® Gold 6xxx processor, Intel^® Xeon^® Platinum 8xxx processor 2 or 4 4	-	Intel^® Xeon^® E-2200 processor family, Intel^® Xeon^® E-2100 processor family, Intel^® Pentium^® processor, Intel^® Core™ i3 processor	Intel^® Xeon^® Bronze 3xxx processor, Intel^® Xeon^® Silver 4xxx processor, Intel^® Xeon^® Gold 5xxx processor, Intel^® Xeon^® Gold 6xxx processor	-	Intel^® Xeon^® Gold 63xx processor, Intel^® Xeon^® Platinum 83xx processor	Intel^® Xeon^® Gold 5xxx processor, Intel^® Xeon^® Gold 6xxx processor, Intel^® Xeon^® Platinum 8xxx processor	-	Intel^® Xeon^® Bronze 3xxx processor, Intel^® Xeon^® Silver 4xxx processor, Intel^® Xeon^® Gold 5xxx processor, Intel^® Xeon^® Gold 6xxx processor	Intel^® Xeon^® Gold 53xx processor, Intel^® Xeon^® Silver 43xx processor	Intel^® Xeon^® Silver 43xx processor, Intel^® Xeon^® Gold 53xx processor	Intel^® Xeon^® Silver 43xx processor, Intel^® Xeon^® Gold 53xx processor	AMD EPYC™ 7002 series processor	Intel^® Xeon^® Silver 43xx processor, Intel^® Xeon^® Gold 53xx processor, Intel^® Xeon^® Gold 63xx processor, Intel^® Xeon^® Platinum 83xx processor	Intel^® Xeon^® Silver 43xx processor, Intel^® Xeon^® Gold 53xx processor, Intel^® Xeon^® Gold 63xx processor, Intel^® Xeon^® Platinum 83xx processor 1 - 2 x Intel^® Xeon^® Processor Scalable Family
Memory	8 GB - 128 GB, UDIMM (DDR4)	4 GB - 128 GB, DIMM (DDR4)	4 GB - 128 GB, DIMM (DDR4)	8 GB - 768 GB, DIMM (DDR4)	8 GB - 8 TB, DIMM (DDR4 / DDR-T for non-volatile memory modules)	8 GB - 7.5 TB, DIMM (DDR4 / DDR-T for non-volatile memory modules)	-	16 GB - 15 TB, DIMM (DDR4 / DDR-T for non-volatile memory modules)	-	4 GB - 128 GB, DIMM (DDR4)	8 GB - 1.5 TB, DIMM (DDR4 / DDR-T for non-volatile memory modules)	-	512 GB - 2 TB	8 GB - 3.5 TB, DIMM (DDR4 / DDR-T for non-volatile memory modules) 8 GB - 2048 GB	-	8 GB - 3.5 TB, DIMM (DDR4 / DDR-T for non-volatile memory modules)	8 GB - 4 TB, DIMM (DDR4) 8 GB - 4096 GB	8 GB - 6.1 TB, DIMM (DDR4 RDIMM, LRDIMM and Intel^® Optane™ PMem)	12 TB	256 GB - 2 TB, DIMM (DDR4) ECC	8 GB - 10 TB, DIMM (DDR4 RDIMM, LRDIMM and Intel^® Optane™ PMem)	8 GB - 12 TB, DIMM (DDR4 RDIMM, LRDIMM and Intel^® Optane™ PMem)
Memory slots	4	4	4 (2 banks with 2 DIMMs each)	12 (6 DIMMs per CPU, 6 channels with 1 DIMM per channel)	24 (12 DIMMs per CPU, 6 channels with 2 slots per channel)	24 (12 DIMMs per CPU, 6 channels with 2 slots per channel)	-	48 (12 DIMMs per CPU, 6 channels with 2 slots per channel)	-	4	12 (6 DIMMs per CPU, 6 channels with one DIMM per channel)	-	32	16 (8 DIMMs per CPU, 6 channels with 2 slots per channel)	-	16 (8 DIMMs per CPU, 6 channels with 2 slots per channel)	16 (8 DIMMs per CPU, 8 channels with 1 slot per channel)	24 (12 DIMMs per CPU, 8 channels with 2 slots per channel)	96	32 (16 DIMMs per CPU)	32 (16 DIMMs per CPU, 8 channels with 2 slots per channel)	32 (16 DIMMs per CPU, 8 channels with 2 slots per channel)
Memory protection	ECC	ECC	ECC	Advanced ECC, Memory Scrubbing, SDDC	Advanced ECC, Memory Scrubbing, SDDC, Rank sparing memory support, Memory Mirroring support	Advanced ECC, Memory Scrubbing, SDDC, Rank sparing memory support, Memory Mirroring support	-	Advanced ECC, Memory Scrubbing, SDDC, Memory Mirroring support, Rank sparing memory support	-	ECC	Advanced ECC, SDDC	-	-	Advanced ECC, SDDC	-	Advanced ECC, SDDC	ECC, Memory Scrubbing, SDDC	ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support	-	ECC	ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support	ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
Drives (optional)	DVD supermulti, ultraslim, SATA I	DVD-ROM, half height, SATA I DVD Super Multi, half height, SATA I DVD supermulti, ultraslim, SATA I Blu-ray Disc™ Triple Writer, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s	DVD supermulti, ultraslim, SATA I	DVD supermulti, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s	DVD supermulti, ultraslim, SATA I	DVD supermulti, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s	-	DVD supermulti, ultraslim, SATA I	-	DVD supermulti, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0	DVD-ROM, half height, SATA I DVD Super Multi, half height, SATA I DVD supermulti, ultraslim, SATA I Blu-ray Disc™ Triple Writer, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s	-	-	-	-	-	-	-	-	-	DVD supermulti, ultraslim, SATA I	DVD supermulti, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s
PCI-Express 3.0 x4	1 x Low profile	1 x Full height, up to 168 mm length	1 x Low profile	-	-	-	-	-	-	1 x Low profile notched	-	-	-	-	-	-	-	-	-	-	-	-
PCI-Express 4.0 x8	2 x Low profile	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1 x Low profile	3 x Low profile (2nd processor required for slot 4)
Accessible drive bays	1 x 5.25/9.5mm for DVD-RW/Blu-ray	3 x 5.25/1.6-inch 3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD Accessible drive bays are not available in case of max. storage drive configuration	1 x 5.25/0.4-inch for CD-RW/DVD Accessible drive bays are not available in case of max. storage drive configuration	1 x 5.25/0.5-inch for ODD, 1 x 5.25/1.6-inch for backup devices 1 x 5.25/1.6-inch for 1 x backup drive or 1 x ODD	1 x 5.25/0.4-inch for CD-RW/DVD	1 x 5.25/0.4-inch for CD-RW/DVD	-	-	-	1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.5-inch for CD-RW/DVD 1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.4-inch for CD-RW/DVD	3 x 5.25/1.6-inch	-	-	-	-	-	-	-	-	-	1 x 5.25/9.5mm for DVD-RW/Blu-ray	1 x 5.25/9.5mm for DVD-RW/Blu-ray 1 x 5.25/0.4-inch for CD-RW/DVD
Optional accessible drives	Not for 10x 2.5-inch HDD base unit. All possible options described in relevant system configurator.	all possible options described in relevant system configurator	Following limitations applies to 10x 2.5-inch HDD base unit: No CD-RW/DVD, 1x USB 2.0 at the front, no front VGA	1x optical drive, 1x backup drive 1x optical disk drive All possible options described in relevant system configurator.	Ultra slim 9.5mm optical drive (optional) n/a Not for 10 x 2.5-inch base unit. All possible options described in relevant system configurator.	ODD 5.25" possible ODD 5.25" NOT possible All possible options described in relevant system configurator.	-	1 x 5.25/9.5mm for DVD-RW/Blu-ray All possible options described in relevant system configurator.	-	-	3x 1.6x5.25" bays for an optical and/or backup drives All possible options described in relevant system configurator.	-	-	-	-	-	-	-	-	-	2x 2.5-inch hot-plug SAS/SATA rear option Ultra slim 9.5mm optical drive (optional) n/a Not for 10x 2.5-inch/32 x EDSFF base unit. All possible options described in relevant system configurator.	ODD 5.25" possible ODD 5.25" NOT possible All possible options described in relevant system configurator.
Storage drive bays	4/8 x 2.5-inch hot-plug SATA/SAS (Up to 4x NVMe PCIe SSD supported) or 4x 3.5-inch hot-plug or 10 x 2.5-inch hot-plug SATA/SAS Max. 4x 3.5-inch Max. 8x 2.5-inch Max. 10x 2.5-inch 4x 2.5-inch	3.5-inch or 2.5-inch hot-plug SAS/SATA Max. 4x 3.5-inch or 8x 2.5-inch Max. 12x 3.5-inch or 24x 2.5-inch	4/8 x 2.5-inch hot-plug SATA/SAS (Up to 4x NVMe PCIe SSD supported) or 4x 3.5-inch hot-plug or 10 x 2.5-inch hot-plug SATA/SAS Max. 4x 3.5-inch Max. 8x 2.5-inch Max. 10x 2.5-inch	2.5-inch base units (max. 24 x 2.5) or 3.5-inch base units (max. 12 x 3.5) 12 x 2.5-inch hot-plug SAS/SATA 16 x 2.5-inch hot-plug SAS/SATA 24 x 2.5-inch hot-plug SAS/SATA 4 x 3.5-inch hot-plug SAS/SATA 12 x 3.5-inch hot-plug SAS/SATA SAS expander not required with PRAID EP5xxi not expandable, incl. SAS expander optionally expandable to 8x 3.5“ with SAS expander	up to 8 x 2.5-inch, 10 x 2.5-inch or 4 x 3.5-inch baseunit up to 4x 3.5" (LFF) hot plug drives (SAS/SATA) up to 4x 2.5" (SFF) hot plug drives (SAS/SATA); option for upgrade to 8x 2.5" (SFF) hot plug drives up to 8x 2.5" (SFF) hot plug drives (SAS/SATA) up to 10x 2.5" (SFF) hot plug drives (SAS/SATA); thereof up to 4x bays prepared for 2.5" PCIe SSD up to 10x 2.5" (SFF) hot plug drives (SATA or PCIe SSD)	3.5-inch or 2.5-inch hot-plug SAS/SATA 4 x 3.5-inch hot-plug SAS/SATA 12 x 3.5-inch hot-plug SAS/SATA 16 x 2.5-inch hot-plug SAS/SATA 8 x 2.5-inch hot-plug SAS/SATA 24 x 2.5-inch hot-plug SAS/SATA	-	2.5-inch hot-plug SAS/SATA/PCIe 2 x M.2 slot whereas slot 1 supports 80mm or 110mm and slot 2 supports 42mm or 80mm 16 x 2.5-inch hot-plug SAS/SATA/PCIe 8 x 2.5-inch hot-plug SAS/SATA/PCIe	-	3.5-inch non hot-plug or 2.5-inch hot-plug SAS/SATA or 2.5-inch NVMe drives Max. 8x (4x + 4x) x 2.5-inch hot-plug Max. 2 x 3.5-inch non hot-plug SATA Not upgradeable in the field.	3.5-inch or 2.5-inch hot-plug SAS/SATA 4 x 3.5-inch hot-plug SAS/SATA 8 x 3.5-inch hot-plug SAS/SATA 8 x 2.5-inch hot-plug SAS/SATA 16 x 2.5-inch hot-plug SAS/SATA 24 x 2.5-inch hot-plug SAS/SATA optional expandable up to 8 storage drives optional expandable up to 12 storage drives not expandable optional expandable up to 24 storage drives optional expandable up to 32 storage drives	-	6x NVMe/SAS/SATA (front)+4 NVMe (rear, optional) x 2.5-inch 8 x 2.5-inch hot-plug	up to 2x 2.5-inch (in the PRIMERGY CX400 M4 chassis) up to 2x 2.5” HDD/SSD device can be installed in CX400 M4 and 2x M.2 device can be installed in CX2550 M5 node	-	up to 6x 2.5-inch (in the PRIMERGY CX400 M4 chassis) up to 6x 2.5” HDD/SSD devices can be installed in CX400 M4 and 2x M.2 device can be installed in CX2560 M4 node	up to 2x 2.5-inch (in the PRIMERGY CX400 M6 chassis) up to 2x 2.5” HDD/SSD device can be installed in CX400 M6 and 2x M.2 device can be installed in CX2550 M6 node	up to 6x 2.5-inch (in the PRIMERGY CX400 M6 chassis) up to 6x 2.5” SAS/SATA/PCIeSSD devices can be installed in CX400 M6 and 2x M.2 device can be installed in CX2560 M6 node	24x 2.5" drive or HDD less configuration x 2.5-inch hot-plug	up to 16x 2.5” SATA only + 4x 2.5” SAS/SATA + 4x 2.5” NVMe (PCIe Gen3)	up to 4 x 3.5-inch, 8 x 2.5-inch, 10 x 2.5-inch or 32 x EDSFF base unit up to 8x 2.5" (SFF) hot plug drives (SAS/SATA) up to 4x 3.5" (LFF) hot plug drives (SAS/SATA) up to 32x EDSFF hot plug drives (PCIe SSD) up to 10x 2.5" (SFF) hot plug drives (SAS/SATA/PCIe SSD)	up to 64x EDSFF, 16x 2.5-inch, 24x 2.5-inch, 10x 3.5-inch or 12x 3.5-inch base units 16 x 2.5-inch hot-plug SAS/SATA 10 x 3.5-inch hot-plug SAS/SATA 64 12 x 3.5-inch hot-plug SAS/SATA 24 x 2.5-inch hot-plug SAS/SATA
LAN Controller	Intel^® i210 onboard 2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration)	Intel^® i210 onboard 2 x 10/100/1000 Mbit/s Ethernet	Intel^® i210 onboard 2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration)	2 x 1 Gbit/s onboard	2 x 1 Gbit/s onboard, Optional DynamicLoM OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28 (only for 10x HDD/SSD base unit)	2 x 1 Gbit/s onboard, Optional DynamicLoM OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+	-	DynamicLoM based on Intel^® C624 (Intel^® X722) Optional DynamicLoM OCP adaptors:, 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 1 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s SFP+	-	Intel^® i210 onboard 2 x 10/100/1000 Mbit/s Ethernet	2 x 1 Gbit/s onboard	-	-	Intel^® i210 onboard 10/100/1000 Mbit/s Ethernet	-	Intel^® i210 onboard 10/100/1000 Mbit/s Ethernet	Intel^® i210 onboard 10/100/1000 Mbit/s Ethernet	onboard Broadcom^® BCM5727 10/100/1000/10000 Mbit/s Ethernet	-	2x 1GbE (Use AOC LAN card)	Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s QSFP28, 2x 100 Gbit/s QSFP28	Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s QSFP28, 2x 100 Gbit/s QSFP28
Remote Management	Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)	Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible	Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)	Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible	Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible	-	Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible	-	Integrated Remote Management Controller (iRMC S5), IPMI 2.0 compatible	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)	-	-	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)	-	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)	IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)	-	Baseboard management controller (BMC)	Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible	Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible
USB ports	5 (Rear: 2x 3.2 Gen1 for all base units, Front (except 10x 2.5" base unit): 2x USB 3.2 Gen1, 1x USB 3.2 Gen2(20 Gb, Type C) , Front (for 10x 2.5" base unit): 2x USB 3.2 Gen1)	4 (2x internal, 2x external front, USB 3.0 is now known as USB 3.1 Gen 1). Server also has 2x external rear USB 3.1 Gen 2 ports	4 Rear: 2x 3.1 Gen2 for all base units, Front (except 10x 2.5" HDD): 2x USB 3.1 Gen1	7 x USB 3.0 (2x front, 4x rear, 1x internal type A)	5 x USB 3.0 (2x front, 2x rear, 1x internal) - for base unit with 10x 2.5" drives 1x USB 2.0 front only	5 x USB 3.0 (2x front, 2x rear, 1x internal) - for base units with max. drives count: 1x USB 2.0 front only	-	5 x USB 3.0 (2x front, 2x rear, 1x internal)	-	4 (2x internal, 2x external front, USB 3.0 is now known as USB 3.1 Gen 1). Server also has 2x external rear USB 3.1 Gen 2 ports	7 x USB 3.0 (2x front, 4 x rear, 1x internal (type A)	-	2	2 x USB 3.0 (rear) with high density connector	-	2 x USB 3.0 (rear) with high density connector	2 x USB 3.0 (rear) with high density connector	2 x USB 3.0 (rear) with high density connector	-	2 x USB 3.0 (2x rear)	5 x USB 3.0 (2x front, 2x rear, 1x internal)	6 x USB 3.0 (2x front, 2x rear, 2x internal)
Graphics	1 x VGA (15-pin) / optional 1 x front VGA (not for 10x 2.5” base unit)	1 analog graphics interface derived from iRMC (up to 1600x1200 or 1920x1080 at 16bpp)	1 x VGA (15-pin) / optional 1 x front VGA (not for 10x 2.5" HDD base unit)	1 x VGA rear	2 x VGA (thereof 1x front optional - not for base unit with 10x 2.5" drives)	2 x VGA (thereof 1x front optional)	-	2 x VGA (1 x front, 1 x rear)	-	1 analog graphics interface derived from iRMC (up to 1600x1200 or 1920x1080 at 16bpp)	1 x VGA	-	-	1 x VGA (1x rear) with high density connector	-	1 x VGA (1x rear) with high density connector	1 x VGA (1x rear) with high density connector	1 x VGA (1x rear) with high density connector	-	1 x VGA (1x rear)	2 x VGA (thereof 1x front optional - not for base unit with 10x 2.5” and 32x EDSFF drives)	2 x VGA (thereof 1x front optional - not for base unit with 12x 3.5” and 24x 2.5" and 24x NVMe and 64x EDSFF drives)
Management LAN (RJ45)	1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port	Management LAN traffic can be switched to shared onboard Gbit LAN port, 1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s)	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard LAN controller port, speed and connector is related to installed interface card.	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard LAN controller port, speed and connector is related to installed interface card.	-	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard LAN controller port, speed and connector is related to installed interface card.	-	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard LAN port	-	-	Management LAN traffic can be switched to shared onboard Gbit LAN port	-	Management LAN traffic can be switched to shared onboard Gbit LAN port	-	Management LAN traffic can be switched to shared onboard Gbit LAN port	-	1x 1GbE (1x rear)	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s)	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s)
Trusted Platform Module (TPM)	TPM 2.0 module (option)	TPM 2.0 module (option)	Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)	Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)	Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)	Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)	-	Infineon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)	-	TPM 2.0 module (option)	optional TPM	-	-	optional TPM	-	optional TPM	-	optional TPM	-	-	Infineon / TPM 2.0 module; TCG compliant (option)	Infineon / TPM 2.0 module; TCG compliant (option)
Power supply configuration	1x standard power supply or 1x hot-plug power supply or 2x hot-plug power supplies for redundancy depending on model	1 x standard, 1 x hot-plug, 2 x hot-plug redundant, 1 x hot-plug + 1 x Fujitsu FJBU internal battery backup unit (depending on Model)	1x standard power supply or1x hot-plug power supply or 2x hot plug power supplies for redundancy depending on model	1x non hot-plug power supply or 2x hot-plug power supply for redundancy	1 x hot-plug power supply or 2 x hot-plug power supply for redundancy	1 x hot-plug power supply or 2x hot-plug power supply for redundancy	-	2 hot-plug power supplies (standard), single power supply configuration possible	-	1 x standard, 1 x hot-plug, 2 x hot-plug redundant, 1 x hot-plug + 1 x Fujitsu FJBU internal battery backup unit (depending on Model)	1x non hot-plug power supply or 2x hot-plug power supply for redundancy	-	-	-	-	-	-	-	-	2 hot-plug power supplies	1 x hot-plug power supply or 2 x hot-plug power supply for redundancy	1 x hot-plug power supply or 2x hot-plug power supply for redundancy
Weight	Std: max.13 kg / Short depth: max. 10 kg	Rack: 13 kg - 25 kg; Tower: 15kg - 28 kg	up to 13 kg	up to 25 kg	up to 16 kg	up to 25 kg	-	max. 29.7 kg	-	up to 10 kg	Up to 35.5 kg	-	-	4.5 kg	-	4.5 kg	5.1 kg	4.9 kg	approx. 28-43 kg	up to 16.4 kg	max. 18.2 kg	max. 32 kg
Rack (W x D x H)	482.6 mm (Bezel) / 435.4 mm (Body) x 612 x 43 mm	483 x 495 x 175 mm	482.6 mm (Bezel) / 435.4 mm (Body) x 572 x 42.8 mm	482.4 mm (Bezel) / 445mm (Body) x 770 x 86.6 mm	483 mm (Bezel) / 435mm (Body) x 770.7 x 43 mm	482.4 mm (Bezel) / 445 mm (Body) x 770 x 86.6 mm	-	482.6 mm (Bezel) / 434.8 mm (Body) x 724.8 x 86.9 mm	-	-	483 (Bezel); 448 mm (body) x 736 x 177 mm	-	485 x 947 x 175 mm	-	-	-	-	-	480 mm (w/ bezel) / 443.5 mm (body) x 860 x 86.5 mm	-	482.2 mm (Bezel) / 435 mm (Body) x 807.45 x 42.7 mm	482.5 mm (Bezel) / 435 mm (Body) x 800 x 86.9 mm
DC Infrastructure Management	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	-	Infrastructure Manager (ISM) Essential Advanced	-	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	-	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	-	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced
Operating system	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	-	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	-	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	-	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	-	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe	http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe	http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe	http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe	http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe	http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe
Warranty period	1 year	1 year	1 year	3 years	3 years	3 years	-	3 years	-	1 year	3 years	-	3 years	3 years	-	3 years	3 years	3 years	3 years	3 years	3 years	3 years
Warranty type	Onsite warranty	Onsite warranty	Onsite warranty	Onsite warranty	Onsite warranty	Onsite warranty	-	Onsite warranty	-	Onsite Service	Onsite warranty Warranty conditions tbd	-	Onsite warranty	Onsite warranty	-	Onsite warranty	Onsite warranty	Onsite warranty	Onsite warranty	Onsite warranty	Onsite warranty	Onsite warranty
Service Lifecycle	5 years after end of product life	5 years after end of product life	5 years after end of product life	5 years after end of product life	5 years after end of product life	5 years after end of product life	-	5 years after end of product life	-	5 years after end of product life	5 years after end of product life	-	5 years after end of product life	5 years after end of product life	-	5 years after end of product life	5 years after end of product life	5 years after end of product life	5 years	5 years after end of product life	5 years after end of product life	5 years after end of product life
Service Weblink	http://www.fujitsu.com/emeia/products/product-support-services/	http://www.fujitsu.com/fts/services	http://www.fujitsu.com/emeia/products/product-support-services/	http://www.fujitsu.com/emeia/products/product-support-services/	http://www.fujitsu.com/emeia/products/product-support-services/	http://www.fujitsu.com/emeia/products/product-support-services/	-	http://www.fujitsu.com/emeia/products/product-support-services/	-	http://www.fujitsu.com/fts/products/product-support-services/	http://www.fujitsu.com/fts/products/product-support-services/	-	http://www.fujitsu.com/emeia/products/product-support-services/	https://www.fujitsu.com/emeia/support/	-	https://www.fujitsu.com/emeia/support/	https://www.fujitsu.com/emeia/support/	https://www.fujitsu.com/emeia/support/	https://www.fujitsu.com/emeia/support/	http://www.fujitsu.com/emeia/products/product-support-services/	http://www.fujitsu.com/emeia/products/product-support-services/	http://www.fujitsu.com/emeia/products/product-support-services/
PCI-Express 3.0 x8	-	2 x Full height, up to 240 mm length notched	2 x Low profile Length 175mm; PCIe slot 1 supports Modular RAID functions	3 x Low profile	1 x Low profile (2nd processor required for slot 4)	3 x Low profile (2nd processor required for slot 4)	-	-	-	2 x Low profile notched	5 x Full height Note: 2 of the slots become available via optional riser card. Refer to configurator for details	-	-	-	-	-	-	-	-	-	-	-
Active power (max. configuration)	-	231 W	264 W	643 W	883 W	715 W	-	2,335 W	-	231 W	748 W	-	5,347 W	-	-	-	-	-	-	-	1,848 W	2,544 W
Floor-stand (W x D x H)	-	177 x 560 x 455 mm	-	-	-	-	-	-	-	98 x 399 x 340 mm	177 x 777 x 456 mm	-	-	-	-	-	-	-	-	-	-	-
Mounting Depth Rack	-	543 mm	-	740 mm	748.2 mm	740 mm	-	741.3 mm	-	-	-	-	-	-	-	-	-	-	812.8 mm	-	836.95 mm	873.1 mm
Server Management	-	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	-	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	-	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	-	-	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	-	ServerView Suite, Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	ServerView Suite, Infrastructure Manager (ISM) Essential Advanced	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	Infrastructure Manager (ISM) Essential Advanced, ServerView RAID Manager	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite
PCI-Express 4.0 x16	-	-	-	1 x (190 mm) low profile	-	-	-	-	-	-	-	6 x	10 x	-	-	-	2 x low profile (via riser card)	2 x x low profile PCIe 4.0 x16 slots (via riser card)	-	4 x Full height 3x PCIe Gen4 x16 for double-wide GPU, 1x PCIe Gen4 x16	3 x Low profile (2nd processor required for slot 3); 1x16 if fh slot selected	4 x Low profile (2nd processor required for slot 6 and 8)
PCI-Express 3.0 x16	-	-	-	-	3 x Low profile (2nd processor required for slot 4); 1x16 if fh slot selected	3 x Low profile (2nd processor required for slot 5 and 6)	11 x z czego 4 pełnowymiarowe i 7 niskoprofilowych	8 x whereas 4x full height and 4x low profile with up to 167mm length	1 x Pełna wysokość, do 240 mm długości	-	3 x Full height Note: One x16 PCIe slot is available with the first CPU, can be occupied by the optional Riser card. Second CPU adds two more x16 PCIe slots. Refer to configurator for details.	-	-	-	-	-	-	-	-	-	-	-
Typ płyty głównej	-	-	-	-	-	-	D3892	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
Typ produktu	-	-	-	-	-	-	Cztery gniazda - serwer w stelażu	-	Jedno gniazdo - serwer wieżowy	-	-	Dwa gniazda - serwer w stelażu	-	-	Obudowa wielowęzłowego serwera	-	-	-	-	-	-	-
Procesor	-	-	-	-	-	-	Procesory Intel^® Xeon^® Gold 53xxH, Procesory Intel^® Xeon^® Gold 63xxH, Procesory Intel^® Xeon^® Platinum 83xxH, Procesory Intel^® Xeon^® Platinum 83xxHL 2 lub 4	-	Procesor z rodziny Intel^® Xeon^® E3-1200 v6, Procesor Intel^® Celeron^®, Procesor Intel^® Core™ i3, Procesor Intel^® Pentium^® 1 x Procesor z rodziny Intel^® Xeon^® E3-1200 v6, Procesor Intel^® Celeron^®, Procesor Intel^® Core™ i3, Procesor Intel^® Pentium^®	-	-	Procesor AMD EPYC™ z serii 7002, Procesor AMD EPYC™ z serii 7003	-	-	Procesor Intel^® Xeon^® Bronze 3xxx, Procesor Intel^® Xeon^® Silver 4xxx, Procesory Intel^® Xeon^® Gold 5xxx, Procesory Intel^® Xeon^® Gold 6xxx	-	-	-	-	-	-	-
Pamięć	-	-	-	-	-	-	16 GB - 15 TB, DIMM (DDR4 RDIMM, LRDIMM i Intel^® Optane™ PMem)	-	4 GB - 64 GB 4 GB - 64 GB, DIMM (DDR4) 4 GB - 32 GB, DIMM (DDR4)	-	-	128 GB - 1 TB, DIMM (DDR4) ECC	-	-	15 TB	-	-	-	-	-	-	-
Gniazda pamięci	-	-	-	-	-	-	48 (12 modułów DIMM na procesor, 6 kanałów z 2 gniazdami na kanał)	-	4	-	-	16 (8 modułów DIMM na procesor)	-	-	64	-	-	-	-	-	-	-
Zabezpieczenie pamięci	-	-	-	-	-	-	ECC, Czyszczenie pamięci, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Obsługa lustrzanego odwzorowywania pamięci	-	-	-	-	ECC	-	-	-	-	-	-	-	-	-	-
Napędy (opcjonalne)	-	-	-	-	-	-	DVD supermulti, ultraslim, SATA I	-	DVD supermulti, ultraslim, SATA I Napęd RDX, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0	-	-	-	-	-	-	-	-	-	-	-	-	-
Dyski dostępne opcjonalnie	-	-	-	-	-	-	1 x 5,25/9,5 mm dla napędu DVD-RW/Blu-ray Wszystkie możliwe opcje są opisane w odpowiednim konfiguratorze systemu.	-	2 (1x 9,5 mm dla napędu DVD/DVD-RW, 1x 5,25 mm o połowie wysokości)	-	-	1 x 5,25/9,5 mm dla napędu DVD-RW/Blu-ray Wszystkie możliwe opcje są opisane w odpowiednim konfiguratorze systemu.	-	-	-	-	-	-	-	-	-	-
Wnęki napędów pamięci masowej	-	-	-	-	-	-	2,5-calowe gniazda SAS/SATA/PCIe 2 x M.2 z możliwością podłączania w trakcie pracy 8 x 2,5 cala, możliwość podłączania podczas pracy, SAS/SATA/PCIe 16 x 2,5 cala, możliwość podłączania podczas pracy, SAS/SATA/PCIe 24 x 2,5 cala, możliwość podłączania podczas pracy, SAS/SATA/PCIe	-	4 x 3,5 cala, bez możliwości podłączania podczas pracy, SATA 2 x 3,5 cala, łatwa wymiana, SATA Tylko SATA	-	-	2,5 cala, możliwość podłączania podczas pracy, SATA/PCIe 8 x 2,5 cala, możliwość podłączania podczas pracy	-	-	-	-	-	-	-	-	-	-
Kontroler LAN	-	-	-	-	-	-	Dynamic LoM przez gniazdo OCP; zgodne z OCPv3, Opcjonalne przejściówki OCP:, 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s QSFP28, 2 x 100 Gbit/s QSFP28	-	Intel^® i219 (wbudowana) 10/100/1000 Mbit/s Ethernet	-	-	2 x 10 Gbit/s Ethernet	-	-	-	-	-	-	-	-	-	-
Zarządzanie zdalne	-	-	-	-	-	-	Zintegrowany kontroler zarządzania zdalnego (iRMC S5, 512 MB pamięci zintegrowanej, w tym kontroler grafiki), Kompatybilny z IPMI 2.0	-	-	-	-	Kompatybilny z IPMI 2.0	-	-	-	-	-	-	-	-	-	-
Porty USB	-	-	-	-	-	-	5 x USB 3.0 (2 z przodu, 2 z tyłu, 1 w środku)	-	8 (2 z przodu, 4 z tyłu, 1 w środku typu A, 1 w środku dla urządzeń do tworzenia kopii zapasowych)	-	-	4 x USB 3.0 (2 z przodu, 2 z tyłu)	-	-	-	-	-	-	-	-	-	-
Grafika	-	-	-	-	-	-	2 x VGA (1 x z przodu, 1 x z tyłu)	-	1 x DisplayPort x (procesor graficzny Intel iGfx)	-	-	1 x VGA (1 x z tyłu)	-	-	-	-	-	-	-	-	-	-
Zarządzanie siecią LAN (RJ45)	-	-	-	-	-	-	1 x wyznaczony do zarządzania port LAN dla iRMC S5 (10/100/1000 Mbit/s)	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
Moduł Trusted Platform Module (TPM)	-	-	-	-	-	-	Infineon / moduł TPM 2.0; zgodny z wymogami TCG (opcjonalne)	-	Infineon / moduł TPM 1.2 lub TPM 2.0; zgodność z TCG (opcjonalnie)	-	-	-	-	-	-	-	-	-	-	-	-	-
Konfiguracja zasilacza	-	-	-	-	-	-	2 zasilacze z możliwością podłączania w trakcie pracy (w standardzie)	-	1 standardowy zasilacz	-	-	2 zasilacze z możliwością podłączania w trakcie pracy (w standardzie)	-	-	-	-	-	-	-	-	-	-
Moc aktywna (maks. konfiguracja)	-	-	-	-	-	-	2,518 W	-	139 W	-	-	-	-	-	-	-	-	-	-	-	-	-
Waga	-	-	-	-	-	-	maks. 40 kg	-	Maks. 12 kg	-	-	maks. 38 kg	-	-	ok. 21-43 kg	-	-	-	-	-	-	-
Stelaż (szer. x gł. x wys.)	-	-	-	-	-	-	482,7 mm (obudowa) / 435 mm (korpus) x 800 x 129.4 mm	-	-	-	-	438 x 831 x 87 mm	-	-	480,8 mm (z ramką)/444,0 mm (korpus) x 857 x 87.8 mm	-	-	-	-	-	-	-
Głębokość montażu w stelażu	-	-	-	-	-	-	830.7 mm	-	-	-	-	-	-	-	820.0 mm	-	-	-	-	-	-	-
Zarządzanie infrastrukturą centrum danych	-	-	-	-	-	-	Infrastructure Manager (ISM) Essential Advanced	-	Infrastructure Manager (ISM) Essential Advanced	-	-	Infrastructure Manager (ISM) Essential Edition Advanced Edition	-	-	Infrastructure Manager (ISM) Essential Advanced	-	-	-	-	-	-	-
Zarządzanie serwerem	-	-	-	-	-	-	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	-	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	-	-	-	-	-	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite	-	-	-	-	-	-	-
System operacyjny	-	-	-	-	-	-	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	-	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	-	-	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473	-	-	-	-	-	-	-	-	-	-
Okres gwarancji	-	-	-	-	-	-	3 lata	-	1 rok	-	-	3 lata	-	-	3 lata	-	-	-	-	-	-	-
Rodzaj gwarancji	-	-	-	-	-	-	Gwarancja serwisu u klienta	-	Serwis u klienta	-	-	Gwarancja serwisu u klienta	-	-	Gwarancja serwisu u klienta	-	-	-	-	-	-	-
Czas serwisowania	-	-	-	-	-	-	5 lat od zakończenia cyklu eksploatacyjnego produktu	-	5 lat od zakończenia cyklu eksploatacyjnego produktu	-	-	co najmniej 5 lat po wysyłce, szczegółowe informacje można znaleźć na stronie https://support.ts.fujitsu.com/	-	-	5 lat	-	-	-	-	-	-	-
Łącze internetowe do serwisu	-	-	-	-	-	-	http://www.fujitsu.com/emeia/products/product-support-services/	-	http://www.fujitsu.com/fts/products/product-support-services/	-	-	http://www.fujitsu.com/emeia/products/product-support-services/	-	-	https://www.fujitsu.com/emeia/support/	-	-	-	-	-	-	-
PCI-Express 3.0 x4 (mech. x16)	-	-	-	-	-	-	-	-	1 x Pełna wysokość, do 215 mm długości	-	-	-	-	-	-	-	-	-	-	-	-	-
Stojak (szer. x gł. x wys.)	-	-	-	-	-	-	-	-	180 x 313 x 374 mm	-	-	-	-	-	-	-	-	-	-	-	-	-
PCI-Express x1	-	-	-	-	-	-	-	-	-	1 x Low profile PCI-Express 3.0	-	-	-	-	-	-	-	-	-	-	-	-
PCI-slots	-	-	-	-	-	-	-	-	-	-	1 x PCI 32Bit, available via optional riser card. Refer to configurator for details	-	-	-	-	-	-	-	-	-	-	-

Solutions to maximize value and performance

PRIMERGY Components

The right options for your IT infrastructures

Data Center Persistent Memory

Memory breakthrough for the biggest data challenges

Infrastructure Manager (ISM)

Centralized control over the entire data center including servers, storage and networking

Server Security

Solid base of integrated security features throughout the lifecycle

Traditional Values. Innovative Success.

Whatever the size of your business – large enterprise with multiple sites, or a small or medium-sized company with limited space and budget – with the right choice of server, your IT can become the business enabler you’ve always wanted it to be. PRIMERGY servers systems will take your IT backend to the next generation, equipping you for whatever challenge the future brings.


Business-proven quality ensures continuous operation with almost no unplanned downtimes	Highest efficiency cuts cost, accelerates IT workloads to shorten time-to-business results	More agility in daily operations helps to turn IT faster into a business advantage	Seamless integration in heterogeneous environments cut operational cost, complexity and shortens time-to-operation

Experience the values of PRIMERGY servers from a different angle

PRIMERGY Value Proposition Video - Quality

Resources

PRIMERGY Family Overview

Servers for the datadriven world

FUJITSU Server PRIMERGY

25 years of excellence

Watch the video

Positioning Card

A fantastic blend of systems, solutions and expertise to guarantee maximum productivity, efficiency and flexibility, delivering confidence and reliability.
