FUJITSU Server PRIMEQUEST 3800E2
FUJITSU Server PRIMEQUEST 3800E2
- Octo-socket rack server that offers superior performance and optimized efficiency for the most demanding mission-critical environments
- Intel® Xeon® Platinum processors with up to 28 cores per processor and fastest available DDR4 memory modules
- Memory capacity of up to 24TB (DDR4 only) or 36TB with Intel® Optane™ DC Persistent Memory
- Optimized economics in a compact 7U form-factor and mission-critical level reliability including advanced RAS features
- Improves performance for in-memory databases such as SAP HANA® and Microsoft SQL Server 2017, thereby making it the right choice for the most complex mission-critical workloads in big data processing environments
|
|
|
|
Dynamic, scalable platform for the most demanding mission-critical environments |
Mission critical uptime leads to highest availability values in the x86 industry standard |
High serviceability |
Cost efficiency for your data center |
|
Unprecedented performance and memory capacity for high-volume, high-value workloads such as online transaction processing (OLTP) and database applications. Cost-efficient 7U chassis packs superior performance in an economic, space-saving footprint. |
Business continuity ensured even if there is a failure in one of the partitions. Built-in error prevention/correction and self-healing capabilities result in outstanding platform reliability. |
All serviceable system modules can be accessed from the front or rear of the system without any cabling hassle. Online maintenance. |
Unity of x86 efficiency and flexibility with mission-critical availability; Eliminate costs related to the UNIX world. Enhanced performance in a significantly smaller form factor. |
-
Dynamic, scalable platform for the most demanding mission-critical environments
Unprecedented performance and memory capacity for high-volume, high-value workloads such as online transaction processing (OLTP) and database applications. Cost-efficient 7U chassis packs superior performance in an economic, space-saving footprint. -
Mission critical uptime leads to highest availability values in the x86 industry standard
Business continuity ensured even if there is a failure in one of the partitions. Built-in error prevention/correction and self-healing capabilities result in outstanding platform reliability. -
High serviceability
All serviceable system modules can be accessed from the front or rear of the system without any cabling hassle. Online maintenance. -
Cost efficiency for your data center
Unity of x86 efficiency and flexibility with mission-critical availability; Eliminate costs related to the UNIX world. Enhanced performance in a significantly smaller form factor.
Product Video
Tech Specs
| Chipset |
Intel® C621 |
| Mainboard type |
up to 4 x System boards |
| Product Type |
Octo Socket Rack Server |
| Processor |
Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor |
| Memory |
32 GB - 36 TB, DIMM (DDR4 / DDR-T for non-volatile memory modules) |
| Memory protection |
ECC, Advanced ECC, Memory Mirroring support, Address Range Memory Mirroring support, Rank sparing memory support, Memory Scrubbing, SDDC+1, ADDDC-MR |
| PCI-Express 3.0 x8 |
12 x Low profile (3slots / IOU, Max. 4 IOUs / Chassis) |
| PCI-Express 3.0 x16 |
4 x Low profile (1slot / IOU, Max. 4 IOUs / Chassis) |
| Storage drive bays |
2.5-inch hot-plug SAS Max. 24 x 2.5-inch |
| I/O controller onboard |
Intel® X540-AT2 2 x 10 Gbit/s Ethernet PQ3000 Management Board (MMB) |
| Power supply configuration |
Up to 4 hot-plug power supplies. Minimum 2 power supplies, redundancy as option. |
| Active power (max. configuration) |
5,940 W |
| Weight |
Up to 110 kg |
| Rack (W x D x H) |
445 x 820 x 308 mm |
| Server Management |
Infrastructure and Server Management |
| DC Infrastructure Management |
Infrastructure Manager (ISM) Infrastructure Manager (ISM) |
| Warranty period |
3 years (depending on country) |
| Warranty type |
Onsite Service |
| Service Lifecycle |
5 years after end of product life |
| Service Weblink |
www.fujitsu.com/support |
