Servers for the data-driven world
PRIMERGY Servers
In der heutigen, sich schnell weiter entwickelnden Geschäftslandschaft spielt die IT für Unternehmen eine immer wichtigere Rolle, um wettbewerbsfähig bleiben und die Wünsche ihrer Kundschaft erfüllen zu können. Um mit den neusten IT-Trends Schritt zu halten, müssen Unternehmen über die richtige Infrastruktur verfügen, einschließlich Servern, die ein breites Spektrum von Workloads und geschäftlichen Anforderungen bewältigen.
Fujitsu PRIMERGY Serversysteme sind eine ideale Lösung für diesen Zweck, denn sie bieten workload-optimierte x86-Industriestandardserver, die den Erfordernissen jedes Unternehmens gerecht werden. Fujitsu hat erkannt, dass es keine Einheitslösung gibt, und bietet daher ein umfassendes Serverportfolio mit erweiterbaren Tower-Servern, vielseitigen Rack-Servern, dichteoptimierten Multi-Node-Servern sowie GPU-Servern, die speziell für KI und VDI entwickelt wurden.
All diese Systeme wurden für die Bewältigung vielfältiger und rechenintensiver Workloads konzipiert, aber jeder Server ist für bestimmte Anwendungsfälle optimiert. Ganz gleich, ob es sich bei Ihrem Unternehmen um ein großes, über mehrere Standorte verteiltes oder um ein kleines oder mittleres Unternehmen mit begrenztem Platzangebot und Budget handelt, Fujitsu PRIMERGY Server können Ihrer IT dabei helfen, zu jenem Business Enabler zu werden, den Sie sich immer gewünscht haben. Mit der richtigen Wahl des Servers können Sie sicherstellen, dass Ihre Infrastruktur mit den neuesten IT-Trends Schritt hält und für alle künftigen Anforderungen gerüstet ist.
Finden Sie den richtigen Server
Form Factor
Height Units
Processor Quantity
Processor Type
Memory Slots
Memory Capacity
max. Storage Drive Bays
PCIe slots
FUJITSU Server PRIMERGY RX1330 M5 | FUJITSU Server PRIMERGY RX2520 M5 | Fujitsu PRIMERGY RX2530 M7 | Fujitsu Server PRIMERGY RX2530 M6 | Fujitsu Server PRIMERGY RX2540 M6 | Fujitsu Server PRIMERGY RX2540 M7 | Fujitsu Server PRIMERGY RX4770 M6 | FUJITSU Server PRIMERGY RX4770 M5 | Fujitsu PRIMERGY TX1310 M5 | Fujitsu PRIMERGY TX1320 M5 | Fujitsu Server PRIMERGY TX1330 M5 | Fujitsu PRIMERGY TX2550 M7 | FUJITSU Server PRIMERGY TX2550 M5 | Fujitsu PRIMERGY CX400 M6 | Fujitsu PRIMERGY CX400 M7 | Fujitsu PRIMERGY CX2550 M6 | Fujitsu PRIMERGY CX2550 M7 | FUJITSU Server PRIMERGY CX2560 M6 | Fujitsu Server PRIMERGY CX2560 M7 | FUJITSU Server PRIMERGY CX2550 M5 | FUJITSU Server PRIMERGY CX2560 M5 | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chipset | Intel® C256 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Intel® C741 | - | - | - | - |
Mainboard type | D3929 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | D 3988 | - | - | - | - |
Product Type | Mono Socket Rack Server | - | - | - | - | - | - | - | - | - | - | - | - | - | Multi-Node Server Chassis | - | Dual Socket 1U Server Node | - | - | - | - |
Processor | Intel® Xeon® E-2300 processor family, Intel® Pentium® processor | - | - | - | - | - | - | - | - | - | - | - | - | - | Intel® Xeon® Silver 43xx processor, Intel® Xeon® Gold 53xx processor | - | Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Silver 4xxx processor | - | - | - | - |
Memory | 8 GB - 128 GB, UDIMM (DDR4) | - | - | - | - | - | - | - | - | - | - | - | - | - | 12 TB | - | 8 GB - 4 TB, DIMM (DDR5)8 GB - 4096 GB | - | - | - | - |
Memory slots | 4 | - | - | - | - | - | - | - | - | - | - | - | - | - | 96 | - | 16 (8 DIMMs per CPU, 8 channels with 1 slot per channel) | - | - | - | - |
Memory protection | ECC | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ECC, Memory Scrubbing, SDDC | - | - | - | - |
Drives (optional) | DVD supermulti, ultraslim, SATA I | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
PCI-Express 3.0 x4 | 1 x Low profile | - | - | - | - | - | - | - | 2 x Volle Höhe, bis zu 215 mm Länge | 2 x Low-Profile | 2 x Volle Höhe | - | - | - | - | - | - | - | - | - | - |
PCI-Express 4.0 x8 | 2 x Low profile | - | - | 1 x Low-Profile | 3 x Low-Profile (2. Prozessor für Steckplatz 4 erforderlich) | - | - | - | - | 2 x Low-Profile (2 x PCIe 4.0 x8-Steckplätze können zu 1 x PCIe 4.0 x16 geschaltet werden) | 2 x Volle Höhe (2 x PCIe 4.0 x8-Steckplätze können zu 1 x PCIe 4.0 x16 geschaltet werden) | 8 x Volle Höhe Hinweis: Siehe Hinweise zu Steckplätzen. | - | - | - | - | - | - | - | - | - |
Accessible drive bays | 1 x 5.25/9.5mm for DVD-RW/Blu-ray | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Optional accessible drives | Not for 10x 2.5-inch HDD base unit. All possible options described in relevant system configurator. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Storage drive bays | 4/8 x 2.5-inch hot-plug SATA/SAS (Up to 4x NVMe PCIe SSD supported) or 4x 3.5-inch hot-plug or 10 x 2.5-inch hot-plug SATA/SASMax. 4x 3.5-inchMax. 8x 2.5-inchMax. 10x 2.5-inch4x 2.5-inch | - | - | - | - | - | - | - | - | - | - | - | - | - | 24x 2.5" drive or HDD less configuration x 2.5-inch hot-plug | - | up to 2x 2.5-inch drive bay per node (in the PRIMERGY CX400 M7 chassis), and 2x M.2 device (in the CX2550 M7 node) | - | - | - | - |
LAN Controller | Intel® i210 onboard2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | BCM5727 (On board LAN) (on D3893-Axx)10/100/1000 Mbit/s Ethernet | - | - | - | - |
Remote Management | Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller) | - | - | - | - |
USB ports | 5 (Rear: 2x 3.2 Gen1 for all base units, Front (except 10x 2.5" base unit): 2x USB 3.2 Gen1, 1x USB 3.2 Gen2(20 Gb, Type C) , Front (for 10x 2.5" base unit): 2x USB 3.2 Gen1) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 2 x USB 3.0 (rear) with high density connector | - | - | - | - |
Graphics | 1 x VGA (15-pin) / optional 1 x front VGA (not for 10x 2.5 base unit) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 x VGA (1x rear) with high density connector | - | - | - | - |
Management LAN (RJ45) | 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Trusted Platform Module (TPM) | TPM 2.0 module (option) | Infineon / TPM 1.2 oder TPM 2.0 (Modul); TCG-konform (Option) | Infineon / TPM 2.0 (Modul); TCG-konform (Option) | Infineon / TPM 2.0 (Modul); TCG-konform (Option) | Infineon / TPM 2.0 (Modul); TCG-konform (Option) | Infineon / TPM 2.0 (Modul); TCG-konform (Option) | Infineon / TPM 2.0 (Modul); TCG-konform (Option) | Infineon / TPM 1.2 oder TPM 2.0 (Modul); TCG-konform (Option) | TPM 2.0-Modul (optional) | TPM 2.0-Modul (optional) | TPM 2.0-Modul (optional) | optionales TPM | optionales TPM | - | - | - | - | optionales TPM | optionales TPM | optionales TPM | optionales TPM |
Power supply configuration | 1x standard power supply or 1x hot-plug power supply or 2x hot-plug power supplies for redundancy depending on model | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Weight | Std: max.13 kg / Short depth: max. 10 kg | - | - | - | - | - | - | - | - | - | - | - | - | - | approx. 28-43 kg | - | 5.1 kg | - | - | - | - |
Rack (W x D x H) | 482.6 mm (Bezel) / 435.4 mm (Body) x 612 x 43 mm | - | - | - | - | - | - | - | - | - | - | - | - | - | 480 mm (w/ bezel) / 443.5 mm (body) x 860 x 86.5 mm | - | - | - | - | - | - |
DC Infrastructure Management |
Infrastructure Manager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Weitere Informationen finden Sie im Abschnitt Management-Hinweise |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastructure Manager (ISM) |
Infrastrukturmanager (ISM) |
Infrastructure Manager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Operating system | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | - | - | - | - |
Warranty period | 1 year | - | - | - | - | - | - | - | - | - | - | - | - | - | 3 years | - | 3 years | - | - | - | - |
Warranty type | Onsite warranty | - | - | - | - | - | - | - | - | - | - | - | - | - | Onsite warranty | - | Onsite warranty | - | - | - | - |
Service Lifecycle | 5 years after end of product life | - | - | - | - | - | - | - | - | - | - | - | - | - | 5 years | - | at least 5 years after shipment, for details see https://support.ts.fujitsu.com/ | - | - | - | - |
Service Weblink | http://www.fujitsu.com/emeia/products/product-support-services/ | - | - | - | - | - | - | - | - | - | - | - | - | - | https://www.fujitsu.com/emeia/support/ | - | https://www.fujitsu.com/emeia/support/ | - | - | - | - |
Chipsatz | - | Intel® C624 | Intel® C741 | Intel® C621A | Intel® C621A | Intel® C741 | Intel® C621A | Intel® C624 | Intel® C256 | Intel® C256 | Intel® C256 | Intel® C741 | Intel® C624 | - | - | Intel® C621A | - | Intel® C621A | Intel® C741 | Intel® C621 | Intel® C624 |
Mainboard-Typ | - | D3386-B | D3982 | D3890 | D3891 | D3983 | D3892 | D3753 | D3930 | D3931 | D3931 | D3985-A | D3386-B | - | - | D 3893 | - | D 3894 | D 3989 | D 3853 | D 3853 |
Produkttyp | - | Dual-Socket-Rack-Server | Dual-Socket-Rack-Server | Dual-Socket-Rack-Server | Dual-Socket-Rack-Server | Dual-Socket-Rack-Server | Quad-Socket-Rack-Server | Quad-Socket-Rack-Server | Mono-Socket-Tower-Server | Mono-Socket-Tower-Server | - | Dual-Socket-Tower-Server | Dual-Socket-Tower-Server | Multinode-Servergehäuse | - | Dual-Socket-Serverknoten (1 HE) | - | Dual-Socket-Serverknoten (1 HE) | Dual-Socket-Serverknoten (1 HE) | Dual-Socket-Serverknoten (1 HE) | Dual-Socket-Serverknoten (1 HE) |
Prozessor | - | Intel® Xeon® Bronze 3xxx-Prozessor, Intel® Xeon® Silver 4xxx-Prozessor, Intel® Xeon® Gold 5xxx-Prozessor1 - 2 | Intel® Xeon® Bronze 3xxx-Prozessor, Intel® Xeon® Silver 4xxx-Prozessor, Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor, Intel® Xeon® Platinum 8xxx-Prozessor | Intel® Xeon® Silver 43xx-Prozessor, Intel® Xeon® Gold 53xx-Prozessor, Intel® Xeon® Gold 63xx-Prozessor, Intel® Xeon® Platinum 83xx-Prozessor | Intel® Xeon® Silver 43xx-Prozessor, Intel® Xeon® Gold 53xx-Prozessor, Intel® Xeon® Gold 63xx-Prozessor, Intel® Xeon® Platinum 83xx-Prozessor1 - 2 x Intel® Xeon® Prozessor der Scalable-Familie | Intel® Xeon® Bronze 3xxx-Prozessor, Intel® Xeon® Silver 4xxx-Prozessor, Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor, Intel® Xeon® Platinum 8xxx-Prozessor1 - 2 x Intel® Xeon® Prozessor der Scalable-Familie | Intel® Xeon® Gold 53xxH-Prozessoren, Intel® Xeon® Gold 63xxH-Prozessoren, Intel® Xeon® Platinum 83xxH-Prozessoren, Intel® Xeon® Platinum 83xxHL-Prozessoren2 oder 4 | Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor, Intel® Xeon® Platinum 8xxx-Prozessor2 oder 44 | Intel® Xeon® E-2300 Prozessorfamilie, Intel® Pentium®-Prozessor1 x Intel® Xeon® E-2300 Prozessorfamilie, Intel® Pentium®-Prozessor | Intel® Xeon® E-2300 Prozessorfamilie, Intel® Pentium®-Prozessor | Intel® Xeon® E-2300 Prozessorfamilie, Intel® Pentium®-Prozessor | Intel® Xeon® Bronze 3xxx-Prozessor, Intel® Xeon® Silver 4xxx-Prozessor, Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor, Intel® Xeon® Platinum 8xxx-Prozessor | Intel® Xeon® Bronze 3xxx-Prozessor, Intel® Xeon® Silver 4xxx-Prozessor, Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor | Intel® Xeon® Silver 43xx-Prozessor, Intel® Xeon® Gold 53xx-Prozessor | - | Intel® Xeon® Gold 53xx-Prozessor, Intel® Xeon® Silver 43xx-Prozessor | - | Intel® Xeon® Silver 43xx-Prozessor, Intel® Xeon® Gold 53xx-Prozessor | Intel® Xeon® Silver 4xxx-Prozessor, Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor | Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor, Intel® Xeon® Platinum 8xxx-Prozessor | Intel® Xeon® Bronze 3xxx-Prozessor, Intel® Xeon® Silver 4xxx-Prozessor, Intel® Xeon® Gold 5xxx-Prozessor, Intel® Xeon® Gold 6xxx-Prozessor |
Arbeitsspeicher | - | 8 GB - 768 GB, DIMM (DDR4) | 16 GB - 8 TB, DIMM (DDR5) | 8 GB - 10 TB, DIMM (DDR4 RDIMM, LRDIMM und Intel® Optane PMem) | 8 GB - 12 TB, DIMM (DDR4 RDIMM, LRDIMM und Intel® Optane PMem) | 16 GB - 8 TB, DIMM (DDR5) | 16 GB - 15 TB, DIMM (DDR4 RDIMM, LRDIMM und Intel® Optane PMem) | 16 GB - 15 TB, DIMM (DDR4 / DDR-T für nichtflüchtige Speichermodule) | 8 GB - 128 GB, UDIMM (DDR4)8 GB - 32 GB, DIMM (DDR4) | 8 GB - 128 GB, UDIMM (DDR4) | 8 GB - 128 GB, UDIMM (DDR4) | 16 GB - 4,0 TB, DIMM (DDR5) | 8 GB - 1,5 TB, DIMM (DDR4 / DDR-T für nichtflüchtige Speichermodule) | 12 TB | - | 8 GB - 2 TB, DIMM (DDR4)8 GB - 4096 GB | - | 8 GB - 3 TB, DIMM (DDR4 RDIMM, LRDIMM und Intel® Optane PMem) | 8 GB - 6 TB, DIMM (DDR5)8 GB - 6144 GB | 8 GB - 3,5 TB, DIMM (DDR4 / DDR-T für nichtflüchtige Speichermodule)8 GB - 2048 GB | 8 GB - 3,5 TB, DIMM (DDR4 / DDR-T für nichtflüchtige Speichermodule) |
Speichersteckplätze | - | 12 (6 DIMMs pro CPU, 6 Kanäle mit 1 DIMM pro Kanal) | 32 (16 DIMMs pro CPU, 8 Kanäle mit 2 Steckplätzen pro Kanal) | 32 (16 DIMMs pro CPU, 8 Kanäle mit 2 Steckplätzen pro Kanal) | 32 (16 DIMMs pro CPU, 8 Kanäle mit 2 Steckplätzen pro Kanal) | 32 (16 DIMMs pro CPU, 8 Kanäle mit 2 Steckplätzen pro Kanal) | 48 (12 DIMMs pro CPU, 6 Kanäle mit 2 Steckplätzen pro Kanal) | 48 (12 DIMMs pro CPU, 6 Kanäle mit 2 Steckplätzen pro Kanal) | 4 | 4 | 4 | 16 (8 DIMMs pro CPU, 8 Kanäle mit 1 DIMM pro Kanal) | 12 (6 DIMMs pro CPU, 6 Kanäle mit 1 DIMM pro Kanal) | 96 | - | 16 (8 DIMMs pro CPU, 8 Kanäle mit 1 Steckplatz pro Kanal) | - | 24 (12 DIMMs pro CPU, 8 Kanäle mit 2 Steckplätzen pro Kanal) | 24 (12 DIMMs pro CPU, 8 Kanäle mit 2 Steckplätzen pro Kanal) | 16 (8 DIMMs pro CPU, 6 Kanäle mit 2 Steckplätzen pro Kanal) | 16 (8 DIMMs pro CPU, 6 Kanäle mit 2 Steckplätzen pro Kanal) |
Speicherschutz | - | Erweitertes ECC, Memory Scrubbing, SDDC | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | Erweitertes ECC, Memory Scrubbing, SDDC, Unterstützung von Memory Mirroring, Unterstützung von Rank-Sparing-Speicher | ECC | ECC | ECC | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | Erweitertes ECC, SDDC | - | - | ECC, Memory Scrubbing, SDDC | - | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Unterstützung von Memory Mirroring | Erweitertes ECC, SDDC | Erweitertes ECC, SDDC |
Laufwerke (optional) | - | DVD supermulti, ultraslim, SATA IRDX-Laufwerk, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/sLTO7HH Ultrium, 300 MB/s, SAS 6Gb/s | DVD supermulti, ultraslim, SATA I | DVD supermulti, ultraslim, SATA I | LTO7HH Ultrium, 300 MB/sDVD supermulti, ultraslim, SATA IRDX-Laufwerk, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/sLTO7HH Ultrium, 300 MB/s, SAS 6Gb/s | DVD supermulti, ultraslim, SATA IRDX-Laufwerk, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 | DVD supermulti, ultraslim, SATA I | DVD supermulti, ultraslim, SATA I | - | DVD supermulti, ultraslim, SATA IRDX-Laufwerk, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0 | LTO7HH Ultrium, 300 MB/sDVD-ROM, Halbe Höhe, SATA IDVD Super Multi, Halbe Höhe, SATA IDVD supermulti, ultraslim, SATA IBlu-ray Disc Triple Writer, Ultraslim, SATA IRDX-Laufwerk, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/sLTO7HH Ultrium, 300 MB/s, SAS 6Gb/s | CD-RW/DVD-Combo, Ultraslim, SATA IIIDVD-ROM, Ultraslim, SATA IIILTO7HH Ultrium, 300 MB/sDVD-ROM, Halbe Höhe, SATA IDVD Super Multi, Halbe Höhe, SATA IDVD supermulti, ultraslim, SATA IBlu-ray Disc Triple Writer, Ultraslim, SATA IRDX-Laufwerk, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/sLTO7HH Ultrium, 300 MB/s, SAS 6Gb/s | DVD-ROM, Halbe Höhe, SATA IDVD Super Multi, Halbe Höhe, SATA IDVD supermulti, ultraslim, SATA IBlu-ray Disc Triple Writer, Ultraslim, SATA IRDX-Laufwerk, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0LTO6HH Ultrium, 160 MB/s, 2,500 GB, SAS 6Gb/sLTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/sLTO7HH Ultrium, 300 MB/s, SAS 6Gb/s | - | - | - | - | - | - | - | - |
PCI-Express 3.0 x8 | - | 3 x Low-Profile | - | - | - | - | - | - | - | - | - | - | 5 x Volle Höhe Hinweis: 2 der Steckplätze stehen über eine optionale Riser-Karte zur Verfügung. Einzelheiten finden Sie im Konfigurator | - | - | - | - | - | - | - | - |
PCI-Express 4.0 x16 | - | 1 x (190 mm) Low-Profile | 1 x Low-Profile | 3 x Low-Profile (2. Prozessor für Steckplatz 3 erforderlich); 1x16 wenn der FH-Steckplatz gewählt wird | 4 x Low-Profile (2. Prozessor für Steckplatz 6 und 8 erforderlich) | 1 x Low-Profile | - | - | 1 x Volle Höhe | - | - | 4 x Volle Höhe Hinweis: Siehe Hinweise zu Steckplätzen. | - | - | - | 2 x Low-Profile (über Riser-Karte) | 2 x low profile (via riser card) | 2 x x Low-Profile-PCIe 4.0 x16 Steckplätze (über Riser-Karte) | - | - | - |
Bedienbare Laufwerkschächte | - | 1 x 5,25/0,5 Zoll für ODD, 1 x 5,25/1,6 Zoll für Backup-Laufwerke1 x 5.25/1.6-Zoll für 1 x backup Drive oder 1 x ODD | 1 x 5,25/9,5 mm für DVD-RW/Blu-ray | 1 x 5,25/9,5 mm für DVD-RW/Blu-ray | 1 x 5,25/9,5 mm für DVD-RW/Blu-ray1 x 5,25/0,4 Zoll für CD-RW/DVD | 1 x 5,25/9,5 mm für DVD-RW/Blu-ray1 x 5,25/0,4 Zoll für CD-RW/DVD | - | - | 1 x 5,25/9,5 mm für DVD-RW/Blu-ray, 1 x 5,25/1,6 Zoll für Backup-Laufwerke | 1 x 3,5/1,6 Zoll für Backup-Laufwerke, 1 x 5,25/9,5 mm für DVD-RW/Blu-ray1 x 3,5/1,6 Zoll für Backup-Laufwerke, 1 x 5,25/0,4 Zoll für CD-RW/DVD | 3 x 5,25/1,6 ZollBedienbare Laufwerkschächte nicht verfügbar bei maximaler Konfiguration der Speicherlaufwerke3 x 5,25/1,6 Zoll für 1 x Backup-Laufwerk + 1 x ODD | 3 x 5,25/1,6 Zoll | 3 x 5,25/1,6 Zoll | - | - | - | - | - | - | - | - |
Optionale bedienbare Laufwerke | - | 1 x optisches Laufwerk, 1 x Backup-Laufwerkoptisches 5,25"-Laufwerk möglich1 x optisches LaufwerkAlle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | 2 x 2,5 Zoll für optionale Hot-plug-SAS/SATA hintenUltraschlankes optisches 9,5 mm Laufwerk (optional)n/aNicht für die 10 x 2,5-Zoll-Basiseinheit. Alle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | 2 x 2,5 Zoll für optionale Hot-plug-SAS/SATA hintenUltraschlankes optisches Laufwerk mit 9,5 mm (optional)n/aNicht für die 10 x 2,5 Zoll/32 x EDSFF Basiseinheit. Alle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | ODD 5,25 Zoll möglichODD 5,25 Zoll NICHT möglichAlle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | Optisches 5,25"-Laufwerk möglichoptisches 5,25"-Laufwerk NICHT möglichoptisches 5,25"-Laufwerk möglichAlle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | 1 x 5,25/9,5 mm für DVD-RW/Blu-ray Alle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | 1 x 5,25/9,5 mm für DVD-RW/Blu-ray Alle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | - | - | Alle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | 3 x 1,6 x 5,25"-Schächte für optische und/oder Backup-LaufwerkeAlle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | 3 x 1,6 x 5,25 Zoll-Schächte für optische und/oder Backup-Laufwerke3 x 1,6 x 5,25 Zoll Schächte für optische und/oder Backup-LaufwerkeAlle möglichen Optionen sind im relevanten Systemkonfigurator beschrieben. | - | - | - | - | - | - | - | - |
Speicherlaufwerksschächte | - | 2,5-Zoll-Basiseinheiten (max. 24 x 2,5) oder 3,5-Zoll-Basiseinheiten (max. 12 x 3,5)12 x 2,5 Zoll Hot-plug-SAS/SATA16 x 2,5 Zoll Hot-plug-SAS/SATA24 x 2,5 Zoll Hot-plug-SAS/SATA4 x 3,5 Zoll Hot-plug-SAS/SATA12 x 3,5 Zoll Hot-plug-SAS/SATASAS-Expander nicht erforderlich mit PRAID EP5xxinicht erweiterbar, inkl. SAS-Expanderoptional erweiterbar auf 8 x 3,5 mit SAS-Expander | bis zu 4 x 3,5 Zoll, 8 x 2,5 Zoll, 10 x 2,5 Zoll Basiseinheitbis zu 8 x 2,5 Zoll (SFF) Hot-Plug-Laufwerke (SAS/SATA)bis zu 4 x hot-plug-fähige 3,5" (LFF) Laufwerke (SAS/SATA)bis zu 10 x 2,5 Zoll (SFF) Hot-Plug-Laufwerke (SAS/SATA)bis zu 10 x 2,5 Zoll (SFF) Hot-Plug-Laufwerke (SAS/SATA/PCIe-SSD)bis zu 10 x 2,5 Zoll (SFF) Hot-Plug-Laufwerke (SATA/PCIe-SSD) | bis zu 4 x 3,5 Zoll, 8 x 2,5 Zoll, 10 x 2,5 Zoll oder 32 x EDSFF Basiseinheitbis zu 8 x 2,5 Zoll (SFF) Hot-Plug-Festplatten (SAS/SATA)bis zu 4 x 3,5 Zoll (LFF) Hot-Plug-Festplatten (SAS/SATA)bis zu 32 x EDSFF Hot-Plug-Festplatten (PCIe SSD)bis zu 10 x 2,5 Zoll (SFF) Hot-Plug-Festplatten (SAS/SATA/PCIe SSD) | bis zu 64 x EDSFF, 16 x 2,5 Zoll, 24 x 2,5 Zoll, 10 x 3,5 Zoll oder 12 x 3,5 Zoll Basiseinheiten16 x 2,5 Zoll Hot-plug-SAS/SATA10 x 3,5 Zoll Hot-plug-SAS/SATA6412 x 3,5 Zoll Hot-plug-SAS/SATA24 x 2,5 Zoll Hot-plug-SAS/SATA | bis zu 16 x 2,5 Zoll, 24 x 2,5 Zoll, 10 x 3,5 Zoll oder 12 x 3,5 Zoll Basiseinheiten10 x 3,5 Zoll Hot-plug-SAS/SATA12 x 3,5 Zoll Hot-plug-SAS/SATA16 x 2,5 Zoll Hot-plug-SAS/SATA16 x 2,5 Zoll Hot-plug-SAS/SATA/PCIe24 x 2,5 Zoll Hot-plug-SAS/SATA |
2,5 Zoll Hot-plug-SAS/SATA/PCIe 2 x M.2-Steckplätze8 x 2,5 Zoll Hot-plug-SAS/SATA/PCIe16 x 2,5 Zoll Hot-plug-SAS/SATA/PCIe24 x 2,5 Zoll Hot-plug-SAS/SATA/PCIe |
2,5 Zoll Hot-plug-SAS/SATA/PCIe 2 x M.2-Steckplatz, wobei Steckplatz 1 80 mm oder 110 mm und Steckplatz 2 42 mm oder 80 mm unterstützt16 x 2,5 Zoll Hot-plug-SAS/SATA/PCIe8 x 2,5 Zoll Hot-plug-SAS/SATA/PCIe |
4 x 3,5 Zoll Cold-plug-SATA | 3,5 Zoll nicht hot-plug-fähige oder 2,5 Zoll hot-plug-fähige SAS/SATA- oder 2,5 Zoll NVMe-LaufwerkeMax. 8 x (4 x + 4 x) x 2,5 Zoll Hot-plugMax. 8x (4x + 4x) x 2,5 Zoll Hot-plugMax. 2 x 3,5 Zoll Nicht-Hot-plug-SATA | 3,5 Zoll oder 2,5 Zoll hot-plug-fähige SAS/SATA- oder 2,5 Zoll NVMe-LaufwerkeMax. 12x 3.5-inch or 24x 2.5-inchMax. 4x 3.5-inch or 8x 2.5-inch | 3,5 Zoll oder 2,5 Zoll Hot-plug-SAS/SATA8 x 2,5 Zoll Hot-plug-SAS/SATA8 x 3,5 Zoll Hot-plug-SAS/SATA24 x 2,5 Zoll Hot-plug-SAS/SATA4 x 3,5 Zoll Hot-plug-SAS/SATAOptional erweiterbar auf bis zu 24 SpeicherlaufwerkeOptional erweiterbar auf bis zu 12 SpeicherlaufwerkeOptional erweiterbar auf bis zu 32 Speicherlaufwerkenicht erweiterbaroptional erweiterbar auf bis zu 8 Speicherlaufwerkeoptional erweiterbar auf bis zu 12 Speicherlaufwerkeoptional erweiterbar auf bis zu 24 Speicherlaufwerkeoptional erweiterbar auf bis zu 32 Speicherlaufwerke | 3,5 Zoll oder 2,5 Zoll Hot-plug-SAS/SATA4 x 3,5 Zoll Hot-plug-SAS/SATA8 x 3,5 Zoll Hot-plug-SAS/SATA8 x 2,5 Zoll Hot-plug-SAS/SATA16 x 2,5 Zoll Hot-plug-SAS/SATA24 x 2,5 Zoll Hot-plug-SAS/SATAoptional erweiterbar auf bis zu 8 Speicherlaufwerkeoptional erweiterbar auf bis zu 12 Speicherlaufwerkenicht erweiterbaroptional erweiterbar auf bis zu 24 Speicherlaufwerkeoptional erweiterbar auf bis zu 32 Speicherlaufwerke | 24 x 2,5-Zoll-Laufwerk oder Konfiguration ohne Festplatten x 2,5 Zoll Hot-plug | - | Bis zu 2x 2,5-Zoll-Laufwerkschächte pro Node (im Gehäuse des PRIMERGY CX400 M6) und 2x M.2-Geräte (in der CX2550 M6-Node) | - | Bis zu 6x 2,5-Zoll-Laufwerkschächte pro Node (im Gehäuse des PRIMERGY CX400 M6) und 2x M.2-Geräte (in der CX2560 M6-Node) | Bis zu 6 x 2,5-Zoll-Laufwerkschächte pro Knoten (im Gehäuse des PRIMERGY CX400 M7) und 2 x M.2-Geräte (im CX2560 M7 Knoten) | bis zu 2 x 2,5 Zoll (im PRIMERGY CX400 M4-Chassis)bis zu 2 x 2,5"-HDD/SSD-Geräte können in CX400 M4 und 2 x M.2-Geräte im CX2550 M5-Knoten installiert werden | bis zu 6 x 2,5 Zoll (im PRIMERGY CX400 M4-Chassis)bis zu 6 x 2,5"-HDD/SSD-Geräte können in CX400 M4 und 2 x M.2-Geräte im CX2550 M5-Knoten installiert werden |
LAN-Controller | - | 2 x 1 Gbit/s onboard | Dynamic LoM via OCP-Steckplatz; kompatibel mit OCPv3, Optionale OCP-Adapter:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2 x 100 Gbit/s QSFP28 | Dynamic LoM via OCP-Steckplatz; kompatibel mit OCPv3, Optionale OCP-Adapter:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 2 x 100 Gbit/s QSFP28 | Dynamic LoM via OCP-Steckplatz; kompatibel mit OCPv3, Optionale OCP-Adapter:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 2 x 100 Gbit/s QSFP28 | Dynamic LoM via OCP-Steckplatz; kompatibel mit OCPv3, Optionale OCP-Adapter:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2 x 100 Gbit/s QSFP28 | Dynamic LoM via OCP-Steckplatz; kompatibel mit OCPv3, Optionale OCP-Adapter:, 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s QSFP28, 2 x 100 Gbit/s QSFP28 | DynamicLoM basierend auf Intel® C624 (Intel® X722)Optionale DynamicLoM OCP-Adapter:, 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 1 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s SFP+ | Intel® i210 Onboard2 x 1 Gbit/s Ethernet (RJ45) | Intel® i210 Onboard2 x 1 Gbit/s Ethernet (RJ45) | Intel® i210 Onboard2 x 1 Gbit/s Ethernet (RJ45) | 2 x 1 Gbit/s onboard | 2 x 1 Gbit/s onboard | - | - | BCM5727 (Onboard LAN) (on D3893-Axx)10/100/1000 Mbit/s Ethernet | - | Intel X550 (Onboard LAN) (on D3894-A1x)10/100/1000/10000 Mbit/s Ethernet | Intel X550 (Onboard LAN) (on D3989-A1x)10/100/1000/10000 Mbit/s Ethernet | Intel® i210 Onboard10/100/1000 Mbit/s Ethernet | Intel® i210 Onboard10/100/1000 Mbit/s Ethernet |
Remote-Management | - | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller) | Integrierter Remote Management Controller (iRMC S6, 1024 MB angeschlossener Speicher einschl. Grafikcontroller), IPMI 2.0-kompatibel | Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller), IPMI 2.0-kompatibel | Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller), IPMI 2.0-kompatibel | Integrierter Remote Management Controller (iRMC S6, 1024 MB angeschlossener Speicher einschl. Grafikcontroller), IPMI 2.0-kompatibel | Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller), IPMI 2.0-kompatibel | Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller), IPMI 2.0-kompatibel | - | - | - | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S6, 1024 MB angeschlossener Speicher einschl. Grafikcontroller) | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller) | - | - | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller) | - | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller) | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S6, 1024 MB angeschlossener Speicher einschl. Grafikcontroller) | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller) | IPMI 2.0-kompatibel, Integrierter Remote Management Controller (iRMC S5, 512 MB angeschlossener Speicher einschl. Grafikcontroller) |
USB-Anschlüsse | - | 7 x USB 3.0 (2 x vorne, 4 x hinten, 1 x intern Typ A) | 5 x USB 3.0 (2 x vorne, 2 x hinten) | 5 x USB 3.0 (2 x vorne, 2 x hinten, 1 x intern) | 6 x USB 3.0 (2 x vorne, 2 x hinten, 2 x intern) | 6 x USB 3.0 (2 x vorne, 2 x hinten, 2 x intern) | 5 x USB 3.0 (2 x vorne, 2 x hinten, 1 x intern) | 5 x USB 3.0 (2 x vorne, 2 x hinten, 1 x intern) | 5 (Vorne: 1 x USB 3.2 Gen2x2 (20 Gbit/s) Typ C, 1 x USB 3.2 Gen1x1 (5 Gbit/s)/ Hinten: USB 3.2 Gen2x1 (10 Gbit/s)/ Intern: 1 x USB 3.2 Gen1x1 (5 Gbit/s)) | 6 (Vorne: 1 x USB 3.2 Gen2x2 (20 Gbit/s) Typ C, 1 x USB 3.2 Gen1x1 (5 Gbit/s)/ Hinten: 2 x USB 3.2 Gen2x1 (10 Gbit/s)/ Intern: 2 x USB 3.2 Gen1x1 (5 Gbit/s)) | 6 (Vorne: 1 x USB 3.2 Gen2x2 (20 Gbit/s) Typ C, 1 x USB 3.2 Gen1x1 (5 Gbit/s)/ Hinten: 2 x USB 3.2 Gen2x1 (10 Gbit/s)/ Intern: 2 x USB 3.2 Gen1x1 (5 Gbit/s)) | 8 x USB 3.1 Gen1 (USB 3.0) (2 x vorne, 4 x hinten, 1 x USB 3.1 Gen1 für Backup-Geräte) | 7 x USB 3.0 (2 x vorne, 4 x hinten, 1 x intern (Typ A)) | - | - | 2 x USB 3.0 (hinten) mit High-Density-Anschluss | - | 2 x USB 3.0 (hinten) mit High-Density-Anschluss | 2 x USB 3.0 (hinten) mit High-Density-Anschluss | 2 x USB 3.0 (hinten) mit High-Density-Anschluss | 2 x USB 3.0 (hinten) mit High-Density-Anschluss |
Grafik | - | 1 x VGA hinten | 2 x VGA (davon 1 x vorne optional - nicht für Basiseinheit mit 10 x 2,5"-Geräten) | 2 x VGA (davon 1 x vorne optional - nicht für Basiseinheit mit 10 x 2,5 Zoll und 32 x EDSFF Laufwerken) | 2 x VGA (davon 1 x vorne optional - nicht für Basiseinheit mit 12 x 3,5 Zoll und 24 x 2,5 Zoll und 24 x NVMe und 64 x EDSFF Laufwerken) | 2 x VGA (davon 1 x vorne optional - nicht für Basiseinheit mit 12 x 3,5 Zoll und 24 x 2,5 Zoll Laufwerken) | 2 x VGA (1 x vorne, 1 x hinten) | 2 x VGA (1 x vorne, 1 x hinten) | 1 x Display Port (integrierte Prozessorgrafik) | 2 (1 x Display Port (integrierte Prozessorgrafik)/ 1 x VGA (15-polig)/ kann ausschließlich verwendet werden) | 2 (1 x Display Port (integrierte Prozessorgrafik)/ 1 x VGA (15-polig)/ kann ausschließlich verwendet werden) | 1 x VGA (1 x hinten, 1 x vorne (optional)) | 1 x VGA | - | - | 1 x VGA (1 x hinten) mit High-Density-Anschluss | - | 1 x VGA (1 x hinten) mit High-Density-Anschluss | 1 x VGA (1 x hinten) mit High-Density-Anschluss | 1 x VGA (1 x hinten) mit High-Density-Anschluss | 1 x VGA (1 x hinten) mit High-Density-Anschluss |
Management-LAN (RJ45) | - | 1 x dedizierter Management-LAN-Port für iRMC S5 (10/100/1000 Mbit/s), Management-LAN-Verkehr kann auf Shared Onboard Gbit-LAN-Port geleitet werden | 1 x dedizierter Management-LAN-Port für iRMC S6 (10/100/1000 Mbit/s) | 1 x dedizierter Management-LAN-Port für iRMC S5 (10/100/1000 Mbit/s) | 1 x dedizierter Management-LAN-Port für iRMC S5 (10/100/1000 Mbit/s) | 1 x dedizierter Management-LAN-Port für iRMC S6 (10/100/1000 Mbit/s) | 1 x dedizierter Management-LAN-Port für iRMC S5 (10/100/1000 Mbit/s) | 1 x dedizierter Management-LAN-Port für iRMC S5 (10/100/1000 Mbit/s), Management-LAN-Verkehr kann auf Shared Onboard-LAN-Port geleitet werden, Geschwindigkeit und Anschluss hängen von der installierten Schnittstellenkarte ab. | - | 1 x dedizierter Management-LAN-Port für iRMC S6 (10/100/1000 Mbit/s), Management-LAN-Verkehr kann auf Shared Onboard Gbit-LAN-Port geleitet werden | 1 x dedizierter Management-LAN-Port für iRMC S6 (10/100/1000 Mbit/s), Management-LAN-Verkehr kann auf Shared Onboard Gbit-LAN-Port geleitet werden | Management-LAN-Verkehr kann auf Shared Onboard-LAN-Port geleitet werden, 1 x dedizierter Management-LAN-Port für iRMC S6 (10/100/1000 Mbit/s) | 1 x dedizierter Management-LAN-Port für iRMC S5 (10/100/1000 Mbit/s), Management-LAN-Verkehr kann auf Shared Onboard-LAN-Port geleitet werden | - | - | - | - | Management-LAN-Verkehr kann auf Shared Onboard Gbit-LAN-Port geleitet werden | Management-LAN-Verkehr kann auf Shared Onboard Gbit-LAN-Port geleitet werden | Management-LAN-Verkehr kann auf Shared Onboard Gbit-LAN-Port geleitet werden | Management-LAN-Verkehr kann auf Shared Onboard Gbit-LAN-Port geleitet werden |
Netzteilkonfiguration | - | 1 x Nicht-Hot-plug-Netzteil oder 2 x Hot-plug-Netzteile für Redundanz | 1 x Hot-Plug-Netzteil oder 2 x Hot-Plug-Netzteile für Redundanz | 1 x Hot-Plug-Netzteil oder 2 x Hot-Plug-Netzteile für Redundanz | 1 x Hot-Plug-Netzteil oder 2 x Hot-Plug-Netzteile für Redundanz | 1 x Hot-Plug-Netzteil oder 2 x Hot-Plug-Netzteile für Redundanz | 2 Hot-Plug-Netzteile (Standard) | 2 hot-plug-fähige Netzteile (standardmäßig), Konfiguration mit einem einzigen Netzteil möglich | 1 x Standardnetzteil |
1 x Standard, 1 x hot-plug-fähig, 2 x hot-plug-fähig redundant (abhängig vom Modell) |
1 x Standard, 1 x hot-plug-fähig, 2 x hot-plug-fähig redundant (abhängig vom Modell) |
1 x nicht hot-plug-fähiges Netzteil oder 2 x Hot-plug-Netzteile für Redundanz oder 2 x nicht hot-plug-fähige Netzteile | 1 x Nicht-Hot-plug-Netzteil oder 2 x Hot-plug-Netzteile für Redundanz | - | - | - | - | - | - | - | - |
Wirkleistung (max. Konfiguration) | - | 643 W | 2.608 W | 1.848 W | 2.544 W | 2.608 W | 2.518 W | 2.335 W | 284 W | 613 W | 1.088 W | 2.758 W | 748 W | - | - | - | - | - | - | - | - |
Gewicht | - | bis zu 25 kg | Standard: max. 19,2 kg/ Geringe Tiefe: max. 16,6 kg | max. 18.2 kg | max. 32 kg | max. 32 kg | max. 40 kg | max. 29,7 kg | bis zu 11 kg | bis zu 11,1 kg | bis zu 26,4 kg | Bis zu 41,9 kg | Bis zu 35,5 kg | ca. 28 - 43 kg | - | 5,1 kg | - | 4,9 kg | 4,9 kg | 4,5 kg | 4,5 kg |
Rack (B x T x H) | - | 482,4 mm (Blende) / 445 mm (Gehäuse) x 770 x 86.6 mm | 483 mm (Blende) / 435 mm (Gehäuse) x 808 x 43 mm | 482,2 mm (Blende) / 435 mm (Gehäuse) x 807.45 x 42.7 mm | 482,5 mm (Blende) / 435 mm (Gehäuse) x 800 x 86.9 mm | 482,5 mm (Blende) / 435 mm (Gehäuse) x 800 x 86.9 mm | 482.7 mm (Bezel) / 435 mm (Body) x 800 x 129.4 mm | 482,6 mm (Blende) / 434,8 mm (Gehäuse) x 724.8 x 86.9 mm | - | - | 482,6 x 495.3 x 174.7 mm | 483 (Blende); 448 mm (Gehäuse) x 772 x 175 mm | 483 (Blende); 448 mm (Gehäuse) x 736 x 177 mm | 480 mm (mit Blende) / 443,5 mm (Gehäuse) x 860 x 86.5 mm | - | - | - | - | - | - | - |
Einbautiefe, Rack | - | 740 mm | Std: 836.95 mm / Short depth: 756.95 mm | 836.95 mm | 873.1 mm | 873.1 mm | 830.7 mm | 741.3 mm | - | - | - | - | - | 812.8 mm | - | - | - | - | - | - | - |
Serververwaltung | - |
Infrastrukturmanager (ISM) |
ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
- | - | - | ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME) |
Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
- |
Infrastrukturmanager (ISM) |
- |
ServerView Suite, Infrastrukturmanager (ISM) |
ServerView Suite, Infrastrukturmanager (ISM) |
Infrastrukturmanager (ISM) |
ServerView Suite, Infrastrukturmanager (ISM) |
Betriebssystem | - | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | - | - | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | - | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 |
Garantiedauer | - | 3 Jahre | 3 Jahre | 3 Jahre | 3 Jahre | 3 Jahre | 3 Jahre | 3 Jahre | 1 Jahr | 1 Jahr | 1 Jahr | 3 Jahre | 3 Jahre | 3 Jahre | - | 3 Jahre | - | 3 Jahre | 3 Jahre | 3 Jahre | 3 Jahre |
Garantieart | - | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie Gewährleistungsbedinungen noch nicht bekannt | On-Site-Garantie Gewährleistungsbedinungen noch nicht bekannt | On-Site-Garantie | - | On-Site-Garantie | - | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie | On-Site-Garantie |
Servicelebenszyklus | - | 5 Jahre nach Ende der Produktlebensdauer | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | 5 Jahre nach Ende der Produktlebensdauer | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | 5 Jahre nach Ende der Produktlebensdauer | 5 Jahre | - | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | - | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | mindestens 5 Jahre nach Versand, weitere Informationen finden Sie unter https://support.ts.fujitsu.com/ | 5 Jahre nach Ende der Produktlebensdauer | 5 Jahre nach Ende der Produktlebensdauer |
Service-Weblink | - | http://www.fujitsu.com/emeia/products/product-support-services/ | http://www.fujitsu.com/emeia/products/product-support-services/ | http://www.fujitsu.com/emeia/products/product-support-services/ | http://www.fujitsu.com/emeia/products/product-support-services/ | http://www.fujitsu.com/emeia/products/product-support-services/ | http://www.fujitsu.com/emeia/products/product-support-services/ | http://www.fujitsu.com/emeia/products/product-support-services/ | http://www.fujitsu.com/fts/products/product-support-services/ | http://www.fujitsu.com/fts/products/product-support-services/ | http://www.fujitsu.com/fts/products/product-support-services/ | http://www.fujitsu.com/fts/products/product-support-services/ | http://www.fujitsu.com/fts/products/product-support-services/ | https://www.fujitsu.com/emeia/support/ | - | https://www.fujitsu.com/emeia/support/ | - | https://www.fujitsu.com/emeia/support/ | https://www.fujitsu.com/emeia/support/ | https://www.fujitsu.com/emeia/support/ | https://www.fujitsu.com/emeia/support/ |
PCI-Express 3.0 x16 | - | - | - | - | - | - | 11 x davon 4 x volle Höhe und 7 x Low-Profile | 8 x davon 4 x volle Höhe und 4 x Low-Profile mit bis zu 167 mm Länge | - | - | - | - | 3 x Volle Höhe Hinweis: Ein x16 PCIe-Steckplatz steht mit der ersten CPU zur Verfügung und kann mit der optionalen Riser-Karte belegt werden. Mit der zweiten CPU stehen zwei weitere x16 PCIe-Steckplätze zur Verfügung. Einzelheiten finden Sie im Konfigurator. | - | - | - | - | - | - | - | - |
Floorstand (B x T x H) | - | - | - | - | - | - | - | - | 180 x 313 x 379 mm | 98 x 400 x 340 mm | 177.2 x 521.7 x 456.2 mm | 177 x 776 x 456 mm | 177 x 777 x 456 mm | - | - | - | - | - | - | - | - |
PCI-Steckplätze | - | - | - | - | - | - | - | - | - | - | - | - | 1 x PCI 32 Bit, verfügbar über optionale Riser-Karte. Einzelheiten finden Sie im Konfigurator | - | - | - | - | - | - | - | - |
Mounting Depth Rack | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 812.8 mm | - | - | - | - | - | - |
Server Management | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Infrastructure Manager (ISM) |
- |
Infrastructure Manager (ISM) |
- | - | - | - |
