Looking Back on Supercomputer Fugaku Development Project
Release date: November 11, 2020
For the purpose of leading the resolution of various social and scientific issues surrounding Japan and contributing to the promotion of science and technology, strengthening industry, and building a safe and secure nation, RIKEN (The Institute of Physical and Chemical Research), and Fujitsu have worked on the research and development of the supercomputer Fugaku (hereafter, Fugaku) since 2014. The installation of the hardware was completed in May 2020 and, in June, the world’s top performance was achieved in terms of the results of four benchmarks: Linpack, HPCG, Graph500, and HPL-AI. At present, we are continuing to make adjustments ahead of public use in FY2021.
This article looks back on the history of the Fugaku development project from the preparation period and the two turning points that had impacts on the entire project plan.
1. Introduction
The supercomputer Fugaku (hereafter, Fugaku) is one of the outcomes of the Flagship 2020 Project (commonly known as the Post-K development), initiated by the Ministry of Education, Culture, Sports, Science and Technology (MEXT) starting in FY2014. This project consists of two parts: development of a successor to the K computer and application development for social and scientific issues (priority issues) on which to focus by using the developed computer. At the start of the project, the name of the successor had not yet been decided, so Post-K name used (this alias is used in this article). The development of the Post-K was carried out for the purpose of leading the resolution of various social and scientific issues surrounding Japan and contributing to the promotion of science and technology, strengthening industry, and building a safe and secure nation. In order to realize a supercomputer with comprehensive capabilities combining system features including the world’s highest-level performance per power consumption, computing capability, user-friendliness and convenience, and creation of breakthrough results, two performance targets to achieve were set for the system: system power consumption of 30 to 40 MW, and 100 times higher performance than the K computer in some actual applications.
This article looks back on the history of the Post-K project since the preparation period and the two turning points that had impacts on the entire project plan.
2. Conditions before start of project
The development of the Post-K can be traced back to the Workshop on Strategic Direction/Development of High Performance Computers (SDHPC), which the author started as a grass-roots activity in 2010, four years before the start of the project, together with the University of Tokyo, University of Tsukuba, Tokyo Institute of Technology, and Kyoto University. At that time, after the budget screening in autumn 2009, the MEXT positioned supercomputers such as those at various university information technology centers as the innovative High-Performance Computing Infrastructure (HPCI) centering on the K computer and started the building of the computing environment to meet the needs of various users. Also, supercomputers based on the T2K Open Supercomputer specification, which was formulated as a result of joint research by the University of Tsukuba, University of Tokyo, and Kyoto University, were in operation at that time. Meanwhile, the International Exascale Software Project (IESP) [1] launched in 2008, and discussions started on the technical issues for exascale machines and the roadmap.
The following is the author’s explanation of the aim made at the first SDHPC Workshop:
“We will discuss with application developers and developers of numerical computing libraries, programming languages, middleware, system software, and hardware what kind of system specifications are possible for high-performance parallel computer systems that can be operated at the center in five years and what research and development should be done for them. All participants will have about 10 minutes to express their opinions and discuss using the projector. We look forward to the personal opinions of researchers and engineers independent of the organizations to which they belong. We welcome participation by young researchers and engineers.”
The following two points were ground-breaking in this workshop.
- It provided an opportunity for young researchers and developers of applications, system software, and hardware to gather together for discussions.
- They could discuss not from the standpoint of the organizations to which they belong but from an individual perspective.
Subsequently, the Working Group on the Study of Future HPC Technology R&D was launched under the HPCI Plan Promotion Committee [2] of the MEXT, under which the Application Working Group and the Computer Architecture/Compiler/System Software Working Group were established [3] . SDHPC was integrated with the activities of the latter working group and, with the Workshop held 11 times in total, the White Paper on the HPCI Technology Roadmap was organized as part of the Report on the Future HPC Technology Development, which was submitted to the HPCI Plan Promotion Committee in 2012.
In addition, applications were publicly invited for the MEXT’s Feasibility Study on Future HPC Systems (hereafter, Feasibility Study) and, for two years from July 2012 to March 2014, the Information Technology Center, the University of Tokyo, of which the author served as the Director, acted as the representative organization to carry out the Feasibility Study on Advanced and Efficient Latency Core‐based Architecture for Future HPCI System together with companies such as Fujitsu. The results of this study provided the basis of Fugaku.
3. Project background
While the Feasibility Study made progress, RIKEN proposed in 2013 a system composed of a general-purpose CPU and acceleration unit for the computation node based on the idea of the following three system design concepts as the Post-K.
- Design in a science-driven manner. That is, design shall be advanced for the purpose of providing computing resources necessary for resolving social and scientific issues based on the Computational Science Roadmap (Ver. 2) in the Report on the Future HPC Technology Development.
- Sustainable system. The system shall be one that inherits the assets of the K computer as a successor of the K computer in view of trends in development of future computer systems.
- System with total cost of ownership (TCO) taken into consideration. A system shall be designed with low power consumption, high software portability, and high fault tolerance.
As stated in the materials [4] of the Council for Science and Technology (the present Council for Science, Technology and Innovation), this system was specified to have a 1 exaFLOPS-class theoretical computing performance with a power consumption of 30 to 40 MW. The development goals set were to aim at an effective application performance 100 times higher than that of the K computer and to carry out application and hardware cooperative design (hereafter, co-design) together with application and hardware developers for the purpose of realizing an exascale machine operable starting in 2020 with excellent performance-power ratio and wide-ranging application execution environments.
The first turning point came in early 2014, when the project was officially started. RIKEN closely examined the development and production costs, including the acceleration unit, and consulted the MEXT’s Feasibility Study on Future HPCI System. The result of the assessment was that, regarding the development of the acceleration unit, there was sufficient feasibility for the technology itself but the development and production costs were estimated to be high and applicability to wide-range applications was limited. This led to the conclusion that the development in this development project had to be abandoned. As an alternative, we considered the use of a GPU as the acceleration unit, but we decided that the adoption of a GPU was not appropriate to carry out the Post-K development without delay because of the uncertainty as to when a GPU satisfying the required performance would appear.
Given these circumstances, it was necessary to make the system capable of utilizing a wide range of applications with high effective performance within the range of the total project cost. Accordingly, we chose to use the relevant resources for the extension of the general-purpose CPU without adopting the computing acceleration unit. This is where the value of the theoretical computing performance of 1 exaFLOPS class, the original system target, posed an issue.
In the Feasibility Study together with Fujitsu, eight types of architectures were assessed. The use of one as the basis provided a possibility to achieve the original theoretical performance target. However, although this architecture provided the expectations for performance of 1 exaFLOPS in Linpack, it was not accepted in terms of providing a wide range of application execution environments, the project goal, and we did not adopt this architecture. We proposed to the MEXT’s System Study Working Group on the Next Flagship System a system that does not hinder the provision of computing resources required for resolving social and scientific issues, aims for an effective performance at the application level up to 100 times higher than the K computer by co-design, and is composed only of a general-purpose CPU. This proposal was discussed and organized into the Report of the System Study Working Group on the Next Flagship System [5].
The research and development contract between RIKEN and Fujitsu started in October 2014 through public invitation. The co-design of hardware and software was carried out together with the nine priority issue implementation organizations selected by the MEXT. Applications were selected from each priority issue implementation organization, and hardware and software were designed to improve the execution efficiency of those target applications. We established 13 working groups (WGs) for the development of hardware and system software and nine WGs for applications. At the beginning, multiple WG sessions were held every day to vigorously carry out the design. Thanks to the close cooperation with application developers on the design and development of hardware and system software from the initial period of the development, the system developers could understand the features of the applications and the application developers could recognize the structure and performance limits of the hardware and system software [6]. It also enabled the application developers to implement software tuning at an early date.
The other turning point was the delay in semiconductor manufacturing technology. The research and development plan for this project was decided on the basis of future trends in semiconductor manufacturing technology investigated around 2012 during the Feasibility Study period. At that time, we expected that the Post-K CPU could be implemented using a 10 nm process technology. In 2016, however, this 10 nm process technology had a degree of uncertainty, and it was found out that the technology would fail to achieve the performance we needed. There were two alternatives—to proceed by lowering the target performance without changing the development deadline, or to delay the development with the next 7 nm process technology as the target. After various discussions, we decided to extend the development period for one to two years and include new added values.
Around the end of May 2016, RIKEN approached Fujitsu on the possibility of the implementation of half-precision floating point arithmetic as one of the added values. Fujitsu was apprehensive about further delays in the development process and the idea was initially denied. However, as half-precision floating point arithmetic instructions were defined in the final specification of Arm V8 scalable vector extension (SVE), Fujitsu implemented the instructions in the A64FX. Half-precision floating point arithmetic is used in the AI application field, and Fugaku is now posed to be used in the AI application field as well. I am grateful to Fujitsu for making such a bold decision at that time.
In summer 2018, the Post-K prototype started operation at the Fujitsu Numazu Plant. A performance as designed was achieved, and the Linux kernel and tools such as the emacs editor also worked. This made me recognize anew Fujitsu’s high technological capabilities. Outside Japan, even the OS kernel often fails to function properly with the first version of a CPU and most CPUs can only be put to practical use after three modifications. Fujitsu subsequently brought the final version to tape-out (design completion).
Based on the evaluation results of the Post-K prototype, production was approved subject to deliberation by the MEXT HPCI Plan Promotion Committee and the Council for Science, Technology and Innovation, and the production of the real machine was started. Transportation of the real machine to RIKEN started on December 3, 2019 and ended on May 13, 2020. Installation adjustments by Fujitsu will then continue until the end of December 2020.
4. Conclusion
This article looked back on the history of the Fugaku development project since the preparation period, including two turning points that had impacts on the entire project plan.
At the time of writing in July 2020, part of the machine is offered while in the period of installation adjustment to the respective users of the Gordon Bell Prize Challenge, the MEXT’s Program for Promoting Researches on the Supercomputer Fugaku, and the development of applications for measures against COVID-19. I would like to express my gratitude to the people of Fujitsu who are working together with RIKEN on the management of computing resources. I also appreciate the assistance given in all-night benchmarking for the TOP500, HPCG, Graph500, and HPL-AI benchmarks beginning in late May 2020. Fugaku ranked number one in these four performance benchmarks in June 2020. While the goal of this development project is not to attain the first place in benchmarks, I am very pleased to hear that the people have felt cheered and encouraged.
During the development of Fugaku, some problems occurred that were not mentioned here. These were overcome every time together with Fujitsu. We must continue to work on stabilization and performance improvements ahead of the official start of operation in the spring of 2021.
All company and product names mentioned herein are trademarks or registered trademarks of their respective owners.
