Fujitsu Server PRIMERGY TX1320 M5

Fujitsu Server PRIMERGY TX1320 M5

  • Supports the latest Intel® Xeon® E-2300 processor family plus up to 128GB DDR4 RAM at 3,200 MT/s
  • Designed for standard small & medium business workloads: infrastructure (file, print, web), collaborative (email), or industry applications
  • Ultra-compact, silent design with dust protection – fits anywhere and ideal for offices or showrooms or industrial environments
  • Full-fledged server for your business needs – up to 8x storage devices, 4x PCIe Gen4/3 slots and a range of controllers, OS, device options

ImgPlaceholder ImgPlaceholder ImgPlaceholder ImgPlaceholder
ADVANCED TECHNOLOGY TO DRIVE WORKLOADS

FLEXIBLE, FUTURE-READY PLATFORM

EFFICIENT AND RELIABLE BY DESIGN

DEPLOY ANYWHERE, SERVICE AND MANAGE EASILY

Powerful mono-socket compute and memory accelerate performance across both individual and virtualized business and industry workloads. Full-featured base units (with 8x 2.5-inch or 2x 3.5-inch storage drives, dual Gigabit LAN standard) to meet diverse SME storage needs.

Versatile 4x PCIe Gen4/3 slots (2x Gen4) to enable upgrades, with advanced options (RAID, networking, and graphics). Secure storage features protect data while M.2, dual microSD devices support flexible software boot and new high data rate USB ports enable the latest peripheral devices.

Designed to be good for both the business and the environment. Choose from amongst a 3.5-inch drive base unit with a value-oriented standard power supply, or the 2.5-inch drive base units which offer either a standard power supply or dual, hot-plug 500W power supplies for enhanced reliability and with high energy-efficiency.

Ultra-compact, low noise, easy to maintain, with Fujitsu’s Cool-safe® technology, and a new dust-protection kit enabling wide-spread deployment. The server's iRMC S6 and Fujitsu Infrastructure Manager (ISM) software suite enable efficient server remote management and infrastructure control.

  • ImgPlaceholder
    ADVANCED TECHNOLOGY TO DRIVE WORKLOADS
    Powerful mono-socket compute and memory accelerate performance across both individual and virtualized business and industry workloads. Full-featured base units (with 8x 2.5-inch or 2x 3.5-inch storage drives, dual Gigabit LAN standard) to meet diverse SME storage needs.
  • ImgPlaceholder

    FLEXIBLE, FUTURE-READY PLATFORM
    Versatile 4x PCIe Gen4/3 slots (2x Gen4) to enable upgrades, with advanced options (RAID, networking, and graphics). Secure storage features protect data while M.2, dual microSD devices support flexible software boot and new high data rate USB ports enable the latest peripheral devices.
  • ImgPlaceholder

    EFFICIENT AND RELIABLE BY DESIGN
    Designed to be good for both the business and the environment. Choose from amongst a 3.5-inch drive base unit with a value-oriented standard power supply, or the 2.5-inch drive base units which offer either a standard power supply or dual, hot-plug 500W power supplies for enhanced reliability and with high energy-efficiency.
  • ImgPlaceholder

    DEPLOY ANYWHERE, SERVICE AND MANAGE EASILY
    Ultra-compact, low noise, easy to maintain, with Fujitsu’s Cool-safe® technology, and a new dust-protection kit enabling wide-spread deployment. The server's iRMC S6 and Fujitsu Infrastructure Manager (ISM) software suite enable efficient server remote management and infrastructure control.

Product Video

Tech Specs

Chipset Intel® C256
Mainboard type D3931
Product Type Mono Socket Tower Server
Processor Intel® Xeon® E-2300 processor family, Intel® Pentium® processor
Memory 8 GB - 128 GB, UDIMM (DDR4)
Memory slots 4
Memory protection ECC
Drives (optional) DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
PCI-Express 3.0 x4 2 x Low profile
PCI-Express 4.0 x8 2 x Low profile (2x PCIe 4.0 x8 slots can be switched to 1x PCIe 4.0 x16)
Accessible drive bays 1 x 3.5/1.6-inch for backup devices, 1 x 5.25/9.5mm for DVD-RW/Blu-ray
1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.4-inch for CD-RW/DVD
Storage drive bays 3.5-inch non hot-plug or 2.5-inch hot-plug SAS/SATA or 2.5-inch NVMe drives
Max. 8x (4x + 4x) x 2.5-inch hot-plug
Max. 2 x 3.5-inch non hot-plug SATA
LAN Controller Intel® i210 onboard
2 x 1 Gbit/s Ethernet (RJ45)
USB ports 6 (Front: 1x USB 3.2 Gen2x2(20 Gbps) Type C, 1x USB 3.2 Gen1x1(5 Gbps) / Rear:, 2x USB 3.2 Gen2x1(10 Gbps) / Internal: 2x USB 3.2 Gen1x1(5 Gbps))
Graphics 2 (1x Display Port (Integrated processor graphics) / 1x VGA (15-pin) / can be used exclusively)
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
Trusted Platform Module (TPM) TPM 2.0 module (option)
Power supply configuration 1 x standard, 1 x hot-plug, 2 x hot-plug redundant (depending on
Model)
Active power (max. configuration) 613 W
Weight up to 11.1 kg
Floor-stand (W x D x H) 98 x 400 x 340 mm
DC Infrastructure Management Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
Operating system http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Warranty period 2 years
Warranty type Onsite warranty
Service Lifecycle 5 years after end of product life
Service Weblink http://www.fujitsu.com/fts/products/product-support-services/
Recommended Service 24x7 Onsite Service with 4h Onsite Response Time
Recommended Service 24x7 Onsite Service with 4h Onsite Response Time

Press

Components

FUJITSU PACC EP QAT8970

The Fujitsu PLAN EP Intel X710-DA2 SFP+ Server Adapter is the most flexible and scalable Ethernet adapter for the current demanding data center environments.
The X710 adapter family addresses the demanding needs of the next-generation agile data center by providing unmatched features for both server and network virtualization, flexibility for LAN and SAN networks and proven, reliable performance.

FUJITSU PLAN EP MCX4-LX 25GbE SFP28

The FUJITSU PLAN EP MCX4-LX 25GbE is based on Mellanox’s ConnectX®-4 Lx EN (Dual port) Network Interface Card. ConnectX-4 Lx EN Network Controller with 10/25Gb/s Ethernet connectivity addresses virtualized infrastructure challenges, delivering best-in-class and highest performance to various demanding markets and applications. Providing true hardware-based I/O isolation with unmatched scalability and efficiency, achieving the most cost-effective and flexible solution for Web 2.0, Cloud, data analytics, database, and storage platforms. 25Gb Ethernet (25GbE) enables network bandwidth to be cost-effectively scaled in support of next-generation server and storage solutions residing in Cloud and Web-scale data center environments. The 25GbE results in a single switch lane connection similar to existing 10GbE technology—but it delivers 2.5 times greater bandwidth.

Compared to 40GbE solutions, 25GbE technology provides superior switch port density by requiring just a single switch lane compared to the 40GbE with four lanes. FUJITSU PLAN EP MCX4-LX 25GbE Dual-Port 10/25GbE Network Interface Cards deliver advanced Ethernet solutions designed for FUJITSU Server PRIMERGY and PRIMEQUEST systems with Microsoft Windows Server 2016 and 2012 R2, Red Hat Enterprise Linux 7, SuSE Linux Enterprise Server 12, VMware ESXi 6.5. Designed for SUSE Linux Enterprise Server 12 SP2 operating system supporting use cases such as SAP HANA®, and for Microsoft Windows Server 2016 operating system supporting use cases such as Storage Spaces Direct certified with Premium and Standard SDDC (Software Defined Data Center) qualifiers.

FUJITSU PLAN CP 2x1Gbit Cu Intel® I350-T2

Trust the network communication of the new Ethernet LAN adapter. The new Intel® I350-T2 Ethernet LAN Adapter, based on the latest Intel® 1GbE chip technology, offers two Gigabit Ethernet ports for 10/100/1000BaseT.
