Relay Applications for Alternative Energy Systems
Development of alternative energy systems to achieve a more sustainable society and prevent global warming.
Relays by load
| Applications | Relay | ||||
|---|---|---|---|---|---|
| Rated power | Series | Contact configuration | |||
| Solar power generation | AC output | Micro inverter | 5A-250VAC | FTR-F4G | 2a |
| Power conditioner | 5A-250VAC | FTR-F4G | 2a | ||
| 25A-250VAC | FTR-K3
(wide gap) | 1a | |||
| FTR-K3L
(wide gap) | 1a (latch) | ||||
| 32A-250VAC | FTR-K3
(wide gap) | 1a | |||
| FTR-K3L
(wide gap) | 1a (latch) | ||||
| DC output | 10A- 450VDC | FTR-J2(*1) | 1a x 2 | ||
| 20A/30A-450VDC | FTR-E1 | 1a | |||
| DC power supply system | DC power supply line | 10A- 450VDC | FTR-J2(*1) | 1a × 2 | |
| 20A/30A-450VDC | FTR-E1 | 1a | |||
| UPS | DC power supply line | 30A- 60VDC | FTR-K2W | 1a | |
| 20A/30A-450VDC | FTR-E1 | 1a | |||
| Smart meter | Power supply control | 32A- 250VAC | FTR-K3L | 1a (latch) | |
(*1) 2 coils in series
