Interactive Panel IW652 Pro

Interactive Panel IW652 Pro

Fujitsu Interactive Panel is the essential hub for modern meeting spaces as well as digitize classrooms. Compared to projector-based systems, the Fujitsu Interactive Panel offers unparalleled visual performance and fosters collaboration to elevate meeting and teaching efficiency.

Features and Benefits

Interactive display with 4K resolution

  • Available In 65", offers big viewing experience

High accuracy touch experience

  • Intuitive 20 points of touch
  • Resistant to optical interference (use as usual under direct sunlight)
  • Rapid response, fluent in writing & demonstration

Durable whiteboard surface

  • AG tempered glass Mohs level 7

Multi OS + multi modules

  • Seamless switching between OS
  • Built-in Android + Pluggable PC module
  • Concealed WIFI module, compatible with WIFI 6 networks

Technical Details

Product NameInteractive Panel IW652 Pro
Picture Performance
Panel and backlitDLED
Screen Surface TreatmentAG tempered glass Mohs level 7
Contrast – typical1200:1
Viewing angle (h/v) - typical178°
Color performance1.07 Billion Colors
Brightness – typical350 cd/m²(Typ)
Size and Resolution
Aspect ratio16:09
Resolution (native)3840(H) x 2160(V)
Picture Size (H x V)1,428.48 x 803.52 mm
Pixel Pitch0.37 2mm
Response Time8ms(Typ)
Refreshing Frequency60Hz
Connectivity
VGA/D-SUB1 x D-SUB
HDMI1 x HDMI OUT (4K), 3 x HDMI IN (HDMI 2.0)
USB1 x USB 2.0
4 x USB 3.0 (including 2 USB ports in front)
USB Type-C™1 x USB Type-C™
Audio In1 x 3.5 mm stereo phone jack
Audio output1 × Audio out
Built-in SpeakerYes, 2 x 16 W
RS232 Control1 x RS232
LAN IN1 x GIGABIT LAN (RJ45)
LAN OUT1 x GIGABIT LAN (RJ45)
TOUCH OUT2 x TOUCH OUT (USB 3.0)
SPDIF1 × SPDIF
BluetoothYes
Touch System
Sensing TypeInfrared recognition
Touch point20 points touches, 10 points writing
Touch ToolFinger / Passive infrared pen / Active infrared pen
Response Time<10ms
Accuracy±1 mm (over 90% area)
Communication ModeFull-speed USB (driver free)
Wireless Screen Mirroring
Wireless Screen MirroringSupports
Self-Hotspot Screen MirroringSupports
Native AirPlay protocol for screen
mirroring
Supports
Native Chromecast protocol for
screen mirroring
Supports
Power consumption (Typical)
Soft switch off≤0.5W
Overall Power(nominal power)450 W
Electrical values
Rated voltage range100 V – 240 V
Rated frequency range50 Hz – 60 Hz, 4.5 A
Quality and Reliability
MTBF (demonstrated)50,000h
Dimensions / Weight / Environmental
Key Location & NumberFront physical keys, 1
Dimension (L x H x D)1,488.4 x 896.6 x 86.4 mm
Dimension(package) LxWxH1,628 x 208 x 1,005 mm
Net Weight38 kg
Gross Weight48.5 kg
Thickness of machine and wall mount116.4 mm (9,060G)
Wall-hanging Screw SpecM8 x 25 mm
VESA600 x 400 mm
Miscellaneous
ColorBlack
Clock & TimeManual/ automatically synchronize with server
Accessories
AC Power CableBritish Standard Power Cord (3 meters), EU Power Cord (3 meters)
USB Cable1, 5 meters, USB 2.0
HDMI cable1, 3 meters
Writing Pen2
Remote Control1
Operation Instruction1
Warranty
Standard warranty1 year (depending on country)

Options

Product NameOrder Number
Mobile StandHLTWB0001A-01
