Features & Benefits
Features | Benefits |
---|---|
Efficient performance
|
|
Best-in-class transfer rates
|
|
Management for constant usage
|
|
Never overloaded
|
|
NOTE: this is an archived page and the content is likely to be out of date.
Features | Benefits |
---|---|
Efficient performance
|
|
Best-in-class transfer rates
|
|
Management for constant usage
|
|
Never overloaded
|
|
Active power (max. configuration) | 150 W |
---|---|
Weight | 3.3 kg |
Connection type | InfiniBand Connection Blade 36-port IB CB 18 ports internal, 18 ports external up to 40Gb per port QSFP connectors for external ports included |
Supported system units | PRIMERGY BX400 S1, PRIMERGY BX900 S1, PRIMERGY BX900 S2 |
Max. number per system unit | Up to 3 |
Supported Server Blades | PRIMERGY BX9xx Server Blades w. IB mezzanine card |
Supported Server Blade I/O Solutions | PRIMERGY BX IB Mezz Card 40 Gbit/s 2 port |
Down-link ports | 18 x 40 Gbit/s IB |
Up-link ports | 18 x 40 Gb (QSFP) |
Recommended Service | 24x7 Onsite Service with 4h Onsite Response Time |
