FUJITSU Server PRIMERGY TX1320 M4

Supports the latest Intel^® Xeon^® E-2200/ E-2100 product family processors plus 2,666 MT/s 128 GB DDR4 RAM
Designed for standard small & medium business workloads: infrastructure (file, print, web), collaborative (email), or industry applications
Ultra-compact, silent design – fits anywhere and ideal for offices or showrooms
Full-fledged server for your business needs - 8x drives, 4x PCIe and a range of controllers, OS, device options
Enhanced reliability by design including redundant power supplies, plus the latest management software including iRMC S5, Fujitsu software ISM

Meer details


Ultra-compact server with advanced technology to drive workload performance	Investment protection and flexibility by design	Improved economics with energy efficiency and reliability	Deploy anywhere, manage and service easily
With the latest compute and memory technology the server can handle appropriately sized, individual or virtualized standard business workloads (file/ print, web, email, messaging, ERP/CRM), or more demanding industry specific applications. The new Intel^® Xeon^® E-2200 product range’s higher core counts and speeds, plus the doubled memory capacity, extends the growth potential of the mono-socket form factor. The flexible storage lets the server handle low-latency storage applications or offer cost-effective storage with backup capability. With up to 8 storage devices, the server can handle most small office dataset or data consolidation requirements. Dual LAN support offers reliable data connectivity for standard requirements right out of the box, while advanced higher data-rate options can support virtualized environments or centralized data sharing over the network.	The PCI slots ensure your server grows with your business. You can add advanced Fujitsu RAID controllers for reliable data handling (high grade SAS 3.0 with up to 4/8 GB cache) or networking options (including 10/25Gb Ethernet controllers) for high-speed data transmission. The security features protect valuable enterprise data from unauthorized access - ideal for institutions with legal requirements for high-security data storage. M.2 devices are designed for flexible boot requirements – they offer the option of cost-effective and reliable mirrored SATA modules or deploying high-speed NVMe, while Dual microSD modules offer mirrored support for VMware ESXi. New high data rate USB is suited for the latest generation peripheral devices.	Good for the environment, and your business economics – the high efficiency, redundant power supplies offer enhanced reliability and lower energy expenditure. A cost optimized alternative to power supply redundancy, the Battery Backup Unit protects your valuable investment by supporting safe power down and expanded time of operation in case of power loss.	The design fits almost everywhere, saves space - ideal for space constrained environments. Low noise emissions, expanded range of operation (5 °C to 45 °C) with Fujitsu’s Cool-safe^® Advanced Thermal Design technology make it ideal for offices, showrooms and even industrial environments –without expensive cooling. The iRMC S5, Fujitsu ServerView suite simplify the IT administrator’s burden, which enable installation and deployment, permanent status monitoring and control. ISM Essential offers converged infrastructure monitoring, server management free of cost. For easy serviceability, the server has a screw-less chassis with hot-plug 2.5-inch devices, hot-plug power supplies and “Easy Rails” for 3.5-inch disks.

Ultra-compact server with advanced technology to drive workload performance
With the latest compute and memory technology the server can handle appropriately sized, individual or virtualized standard business workloads (file/ print, web, email, messaging, ERP/CRM), or more demanding industry specific applications. The new Intel^® Xeon^® E-2200 product range’s higher core counts and speeds, plus the doubled memory capacity, extends the growth potential of the mono-socket form factor. The flexible storage lets the server handle low-latency storage applications or offer cost-effective storage with backup capability. With up to 8 storage devices, the server can handle most small office dataset or data consolidation requirements. Dual LAN support offers reliable data connectivity for standard requirements right out of the box, while advanced higher data-rate options can support virtualized environments or centralized data sharing over the network.
Investment protection and flexibility by design
The PCI slots ensure your server grows with your business. You can add advanced Fujitsu RAID controllers for reliable data handling (high grade SAS 3.0 with up to 4/8 GB cache) or networking options (including 10/25Gb Ethernet controllers) for high-speed data transmission. The security features protect valuable enterprise data from unauthorized access - ideal for institutions with legal requirements for high-security data storage. M.2 devices are designed for flexible boot requirements – they offer the option of cost-effective and reliable mirrored SATA modules or deploying high-speed NVMe, while Dual microSD modules offer mirrored support for VMware ESXi. New high data rate USB is suited for the latest generation peripheral devices.
Improved economics with energy efficiency and reliability
Good for the environment, and your business economics – the high efficiency, redundant power supplies offer enhanced reliability and lower energy expenditure. A cost optimized alternative to power supply redundancy, the Battery Backup Unit protects your valuable investment by supporting safe power down and expanded time of operation in case of power loss.
Deploy anywhere, manage and service easily
The design fits almost everywhere, saves space - ideal for space constrained environments. Low noise emissions, expanded range of operation (5 °C to 45 °C) with Fujitsu’s Cool-safe^® Advanced Thermal Design technology make it ideal for offices, showrooms and even industrial environments –without expensive cooling. The iRMC S5, Fujitsu ServerView suite simplify the IT administrator’s burden, which enable installation and deployment, permanent status monitoring and control. ISM Essential offers converged infrastructure monitoring, server management free of cost. For easy serviceability, the server has a screw-less chassis with hot-plug 2.5-inch devices, hot-plug power supplies and “Easy Rails” for 3.5-inch disks.

Product Video

Tech Specs

Chipset	Intel^® C246
Mainboard type	D3673
Product Type	Mono Socket Tower Server
Processor	Intel^® Xeon^® E-2200 processor family, Intel^® Xeon^® E-2100 processor family, Intel^® Pentium^® processor, Intel^® Core™ i3 processor
Memory	4 GB - 128 GB, DIMM (DDR4)
Memory slots	4
Memory protection	ECC
Drives (optional)	DVD supermulti, ultraslim, SATA I RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
PCI-Express 3.0 x4	1 x Low profile notched
PCI-Express 3.0 x8	2 x Low profile notched
PCI-Express x1	1 x Low profile PCI-Express 3.0
Accessible drive bays	1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.5-inch for CD-RW/DVD 1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.4-inch for CD-RW/DVD
Storage drive bays	3.5-inch non hot-plug or 2.5-inch hot-plug SAS/SATA or 2.5-inch NVMe drives Max. 8x (4x + 4x) x 2.5-inch hot-plug Max. 2 x 3.5-inch non hot-plug SATA Not upgradeable in the field.
LAN Controller	Intel^® i210 onboard 2 x 10/100/1000 Mbit/s Ethernet
Remote Management	Integrated Remote Management Controller (iRMC S5), IPMI 2.0 compatible
USB ports	4 (2x internal, 2x external front, USB 3.0 is now known as USB 3.1 Gen 1). Server also has 2x external rear USB 3.1 Gen 2 ports
Graphics	1 analog graphics interface derived from iRMC (up to 1600x1200 or 1920x1080 at 16bpp)
Management LAN (RJ45)	1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
Trusted Platform Module (TPM)	TPM 2.0 module (option)
Power supply configuration	1 x standard, 1 x hot-plug, 2 x hot-plug redundant, 1 x hot-plug + 1 x Fujitsu FJBU internal battery backup unit (depending on Model)
Active power (max. configuration)	231 W
Weight	up to 10 kg
Floor-stand (W x D x H)	98 x 399 x 340 mm
DC Infrastructure Management	Infrastructure Manager (ISM) Essential Advanced
Server Management	Infrastructure Manager (ISM) Essential Advanced, ServerView Suite
Operating system	http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Warranty period	1 year
Warranty type	Onsite Service
Service Lifecycle	5 years after end of product life
Service Weblink	http://www.fujitsu.com/fts/products/product-support-services/

Support Pack Options

Globally available in major business areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)

Recommended Service

24x7 Onsite Service with 4h Onsite Response Time

Support Pack Options	Globally available in major business areas: 9x5, Next Business Day Onsite Response Time 9x5, 4h Onsite Response Time (depending on country) 24x7, 4h Onsite Response Time (depending on country)
Recommended Service	24x7 Onsite Service with 4h Onsite Response Time

Read full specs
