  4. FUJITSU Storage ETERNUS AB6100


The ETERNUS AB6100 end-to-end NVMe midrange array delivers high performance in a midrange AB series all-flash array. AB6100 accelerates access to data, so you get value from it faster. The AB6100 doubles the performance of currently available all-flash arrays that use the serial-attached SCSI (SAS) protocol. You can accelerate write IOPS and read/write throughput with an end-to-end NVMe storage platform that is purpose-built for high-performance workloads. The ETERNUS AB6100 all-flash array combines extreme IOPS, response times of less than 100 microseconds, and up to 44GBps of bandwidth with leading, enterprise-proven availability features

Features & Benefits

Features Voordelen
Accelerates Business Applications

    • Accelerate write IOPS and read/write throughput with an end-to-end NVMe storage platform that’s purpose-built for high-performance
    • Get twice the performance for your high-performance workloads, such as Oracle and BeeGFS, compared to SAS-based all-flash arrays.
    Continuous availability

      • ETERNUS AB6100 storage systems enable you to achieve greater than 99.9999% availability and provide data integrity and security
      • Extensive capturing of diagnostic data provides comprehensive fault isolation and simplifies analysis of unanticipated events
      • Drive rebuild continues even when an unreadable sector or second failure is encountered
      Flexible configuration Options

        • Enables the automation and agility that are needed in the DevOps-based IT revolution,
        • A Linux-based Docker Container service to embed applications on the ETERNUS AB6100. It enables cost-effective converged infrastructure for targeted workloads. Examples include applications related to analytics, video surveillance, and HPC workloads.
        • Protects investments in storage networks, the ultradense ETERNUS AB6100 easily addresses ever-changing requirements. Helps meet future demands without forklift upgrades.

        Technical details

        Host InterfacesFC (8,16,32Gbit/s)
        NVMe over FC (32Gbit/s)
        NVMe over InfiniBand (100Gbit/s)
        NVMe over RoCE (100Gbit/s)
        Maximum Disk Drives24
        Maximum Storage Capacity367 TB
        No. of host interfaces16 Port [FC (8,16,32Gbit/s)]
        16 Port [NVMe over FC (32Gbit/s)]
        8 Port [NVMe over InfiniBand (100Gbit/s)]
        8 Port [NVMe over RoCE (100Gbit/s)]
        Max. no. of hosts512
        Supported RAID levels0, 1, 1+0, 3, 5, 6, DDP
        Drive interface100G NVMe

        For further information, please see

        ETERNUS AB6100
