Fujitsu and Denali Software Collaborate to Develop DFI Compatible DDR PHY Macro

-Seamless integration with DFI compatible DDR controllers streamlines memory system design-

Fujitsu Limited,Denali Software, Inc.

Tokyo and Palo Alto, U.S., September 19, 2007

Fujitsu Limited and Denali Software, Inc. today announced their co-development of a DDR DRAM physical interface (DDR PHY)(1)product compatible with the recently announced DDR-PHY Interface (DFI) version 1.0 specification. The DDR PHY utilizes the DFI specification which defines a common interface between the conventional proprietary memory controller logic and DDR PHY designs, which reduces design and integration costs for developing DDR DRAM memory systems, and reduces overall time-to-market.

"DDR DRAM memory system design has emerged as a significant design challenge that affects a wide range of applications, spanning communications, computing, networking, and consumer electronics such as digital audio-videos," said Brian Gardner, vice president of IP products at Denali Software. "A key part of the solution involves decoupling the DDR PHY design, which is highly process dependent and timing sensitive, from the DDR controller logic design, which is driven by system performance requirements. The DFI specification provides a clean boundary between these two memory system components, and enables developers to use best-in-class PHY and memory controller designs. Fujitsu's new DFI compatible DDR PHY designs are a demonstration of state-of-the-art solutions for ASIC development, and provide customers with a significant advantage in DDR memory system development."

Figure 1: DDR Memory System

Larger View (162 KB)

The DFI compatible DDR PHY product, co-developed with Fujitsu VLSI Limited(2), is delivered as a macro to customers using Fujitsu's 90-nm process technology or further advanced technologies. In addition to 90-nm, Fujitsu is planning to utilize this DDR PHY product for other Fujitsu proprietary process technologies including generations previous to 90-nm. Furthermore, Fujitsu's DDR PHY macro has been verified with Denali's DFI compatible Databahn™ DDR controllers, enabling customers with a complete memory system solution.

"Denali Software is not only a leader in preparing the DFI specification, but also has a good track record for releasing many high-quality DDR controllers. Collaborating to verify the interface between Fujitsu's DDR PHY and Denali's DDR controllers shows a significant achievement in terms of providing customers with high-quality and interoperable DDR systems with low risk," said Yoshio Watanabe, General Manager of the IP Platform Solutions Division, Electronic Devices Business Unit of Fujitsu Limited.

About the DDR PHY Interface (DFI) Specification

The DFI specification was developed by expert contributors from recognized leaders in the semiconductor, IP, and electronic design automation (EDA) industries. The DFI specification defines an interface protocol between memory controller logic and PHY interfaces, with the goal of reducing costs for integrating DDR memory controller logic and DDR PHY interface while increasing performance and data throughput efficiency. The protocol defines the signals, timing, and functionality required for efficient communication across the interface. This enables reducing design and verification cost and time-to-market while increasing the potential for reusing the individual components that compose the memory system. The DFI Specification version 1.0 was released for production development in January 2007 and is available online at

Time of Release

The DFI compatible DDR1 IF PHY up to 400 Mbps and the DFI compatible DDR2 IF PHY beyond 400 Mbps will be released at the end of September, 2007, and the end of November, 2007 for ASIC and COT using Fujitsu's 90 nm or further advanced process technologies, respectively.

  • [1] DDR PHY

    Refers to DDR DRAM physical interface. Located between the DDR controller and SSTL I/O, the DDR PHY is a circuit that performs parallel-to-serial conversion of data from the DDR controller via the I/O and transmits the data to the SDRAM, and also performs serial-to-parallel conversion for data received from the SDRAM via the I/O and transmits the data to the DDR controller.

  • [2] Fujitsu VLSI Limited

    A subsidiary of Fujitsu Limited that offers SoC, MCU, ASIC, methodology, and macro for LSI design.

About Fujitsu

Fujitsu is a leading provider of customer-focused IT and communications solutions for the global marketplace. Pace-setting device technologies, highly reliable computing and communications products, and a worldwide corps of systems and services experts uniquely position Fujitsu to deliver comprehensive solutions that create infinite possibilities for its customers' success. Headquartered in Tokyo, Fujitsu Limited (TSE:6702) reported consolidated revenues of 5.1 trillion yen (US$43.2 billion) for the fiscal year ended March 31, 2007. For more information, please see:

About Denali Software

Denali Software, Inc. is a world-leading provider of electronic design automation (EDA) software and intellectual property (IP) for system-on-chip (SoC) design and verification. Denali delivers the industry's most trusted solutions for deploying PCI Express, NAND Flash and DDR DRAM subsystems. Developers use Denali's EDA, IP and services to reduce risk and speed time-to-market for electronic system and chip design. Denali is headquartered in Palo Alto, California and has offices around the world to serve the global electronics industry. More information about Denali, its products and services is available at
