Overview
Basic SP Series model for professional use
- Efficient document scanning software for higher productivity
- PaperStream IP for SP Series - Automatically creates the most suitable image data for hassle-free scanning
- ABBYY™ FineReader™ Sprint – Creates searchable files from your paper documents, allowing you at a later date to find your information easier
- PaperStream Capture Lite (NEW) - Realizes batch capturing and works smoothly with business workflow. (available here)
- Ideal for desktop placement
- Compact design
- 30 ppm scanning speed model
- Support plastic card scanning
- Simple and easy-to-use design
- Availability of this model may vary depending on region.
Features
Efficient document scanning software for higher productivity
- PaperStream IP for SP Series - Automatically creates the most suitable image data for hassle-free scanning
The PaperStream IP driver, which supports TWAIN / ISIS, saves the hassle of fine tuning the document for the OCR process. It not only automatically detects the document size, single / double sided and rotation, but also automatically converts the images into exceptionally clean images, accelerating OCR even when scanning wrinkled or soiled documents or documents with a background pattern.
By applying the Service Update 7, the user will gain even more control over batch scanning settings. (available here) - ABBYY™ FineReader™ Sprint(1) – Creates searchable files from your paper documents, allowing you at a later date to find your information easier
The scanned data can be converted to searchable PDF or office documents such as Microsoft® Word to be utilized in day to day work tasks. The OCR processing is able to handle 190 languages, which means it is an especially valuable feature in a mixed-language environment. - Presto!™ PageManager™ - Making it easy to scan, share, and organize your documents and files.
Everybody in an office can quickly learn and use it. Presto!™ PageManager™ works with your SP Series scanners to turn paper documents into organized digital documents. You can create, write, and open PDF files without file conversion or other applications. You can split multiple page PDF files into separate files or merge several PDF files into one. You can group your files, stack your files, or spread them out. - PaperStream Capture Lite(5) - Realizes batch capturing and works smoothly with business workflow(NEW)
By configuring and saving batch-profile settings in advance, PaperStream Capture Lite will immensely improve the productivity of the capturing operation within the business workflow. This is the lite version of "PaperStream Capture", the renowned batch capturing software made for the "fi Series". (6)
Ideal for desktop placement
Compact design
The SP-1130 is compact in size, so it can be used at the desk or at reception where space is limited. Even with its compact size, it is equipped with a brake roller to accurately separate each page, and an ultra-sonic sensor to accurately detect multifeed, so the user can scan without worrying about potential problems.- 30 ppm scanning speed model
The SP-1130 helps users finish scanning tasks in a short time without stress, with its 30 ppm (A4 color, duplex 200 / 300 dpi) performance. The automatic document feeder (ADF) holds up to 50 sheets(2) at a time, and the scanning speed is maintained even at 300 dpi. - Support plastic card scanning
The SP-1130 is able to handle various documents from thin to thick paper (50-209 g/㎡), as well as plastic cards(3) for various tasks and applications. In the case of over-the-counter services, application forms and plastic ID cards can be scanned at the same time to avoid customers waiting.
Simple and easy-to-use design
The simple and easy-to-use design can minimize the scanning procedures and reduce human-error. The SP-1130 has a simple operation panel with only 2 buttons (Scan / Stop and Power), and after presetting the bundled Presto!™ PageManager™(4), only one push of the scan button is necessary to store document image data instantly.
- OCR application developed by ABBYY Ltd.
- The user can feed additional documents during scanning.
- Plastic cards compatible with ISO7810 with a thickness of 0.76 mm or less (Embossed plastic cards with total thickness of 1.24 mm or less). One landscape card scanning at a time.
- Image data management / editing application developed by NewSoft Technology Corporation.
- Available here.
- For more information, please refer to the comparison chart.
Specifications
| Description | SP-1130 | |
|---|---|---|
| Supported operating systems | Windows® 11, Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Linux (Ubuntu) | |
| Scanner Type | ADF (Automatic Document Feeder) | |
| Scanning modes | Simplex / Duplex, Color / Grayscale / Monochrome | |
| Image Sensor Type | Single line CMOS-CIS x 2 (Front x 1, Back x 1) | |
| Light Source | R, G, B LED x 2 (Front x 1, Back x 1) | |
| Document size | Maximum: A4 Portrait (210 x 297 mm) or Legal (8.5 x 14 in.) or 8.5 x 34 in. (215.9 x 863.6 mm) (long page scanning: 3,048 mm (120 in.))
Minimum: A8 Portrait / Landscape (52 x 74 mm) | |
| Paper weight
(Thickness) | Paper | 50 to 209 g/m2 (0.06 to 0.26 mm)
* A8 size: 127 to 209 g/m2 (0.15 to 0.26 mm) |
| Plastic Card | ISO7810 ID-1 type compliant (0.76 mm or less, embossed plastic cards with total thickness of 1.24 mm or less) | |
| Scanning speed
(A4, Portrait) (2) | Color (3) | Simplex: 30 ppm (200 dpi / 300 dpi)
Duplex: 60 ipm (200 dpi / 300 dpi) |
| Grayscale (3) | ||
| Monochrome | ||
| Paper chute capacity (A4 Landscape) (4) | 50 sheets (A4: 80 g/m2 or 20 lb) | |
| Expected Daily Volume | 4,500 sheets | |
| Background colors | White (Hardware, scanned background is gray) | |
| Optical Resolution | 600 dpi | |
| Output Resolution (5) | Color (24-bit) | 50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (6) |
| Grayscale (8-bit) | ||
| Monochrome (1-bit) | ||
| Output format | Color: 24-bit, Grayscale: 8-bit, Monochrome:1-bit | |
| Internal video processing | 65,536 levels (16-bit) | |
| Interface | USB2.0 | |
| Connector shape | B type | |
| Image processing function | Auto color detection, Automatic page size detection, De-Skew, Multi-image, Blank page skip, Error diffusion, Dropout color (R, G, B, Saturation), Image emphasis, Advanced DTC, sRGB, Halftone, Smoothing, Split image, Vertical streaks reduction, Digital endorser, Edge correction, Dynamic threshold(iDTC) | |
| Power requirement | AC 100 V to 240 V ± 10% | |
| Power consumption | Operating: 18 W or less
Sleep mode: 1.6 W or less Auto standby (OFF) mode: 0.4 W or less | |
| Operating environment | Temperature: 5 to 35 °C (41 to 95 °F)
Relative humidity: 20 to 80% (Non-condensing) | |
| Dimensions: Width x Depth x Height (7) | 298 mm x 135 mm x 133 mm (11.7 in. x 5.3 in. x 5.2 in.) | |
| Weight | 2.5 kg | |
| Included software / drivers | PaperStream IP for SP Series driver (TWAIN/TWAIN x64/ISIS), WIA Driver(8), PaperStream Capture Lite, Software Operation Panel, Error Recovery Guide, Presto!™ PageManager™(9), ABBYY™ FineReader™ Sprit(9) Scanner Central Admin | |
| Environmental compliance | ENERGY STAR® and RoHS | |
| Others | Multifeed detection | Yes (Standard) ultrasonic multifeed detection sensor x 1 |
| Long page scanning (10) | 3,048 mm (120 in.) | |
| Included items | AC adapter, USB cable, Setup DVD-ROM | |
[Note]
- Availability of support may vary depending on region. Some functions may not be available with the Image Scanner Driver for Linux.
- Actual scanning speeds are affected by data transmission and software processing times.
- Indicated speeds are from using JPEG compression.
- Maximum capacity depends on paper weight and may vary.
- Selectable maximum density may vary depending on the length of scanned document.
- Some limitations may apply to the size of documents that can be scanned, depending on system environment, when scanning at high resolution (over 600 dpi).
- Excluding the ADF paper chute and stacker.
- Functions equivalent to those offered by PaperStream IP may not be available with the WIA Driver.
- Software can be downloaded from the website designated in the Setup DVD-ROM.
- Capable of scanning documents that exceed Legal sheets in length. However, the scanning of documents that exceed 863 mm (34 in.) in length will be limited to 200 dpi or less.
Accessories
| Part Number | Description | |
|---|---|---|
| SP-1130 Consumables | ||
| Roller set
(Brake roller / Pick roller)  | PA03708-0001 | Lifetime: Every 100,000 sheets or one year. |
| SP-1130 Cleaning Kits | ||
Cleaner F1
 | PA03950-0352 | 100 ml
Moisten a cloth or Cleaning Paper with this liquid to wipe the scanner clean. It may take a long time to dry if an excessive amount is used. Use it in small quantity. Wipe off the cleaner completely to leave no residue on the cleaned parts. |
Cleaning Paper
 | CA99501-0012 | 10 sheets
Use this non-woven sheet with Cleaner F1. |
Cleaning Wipe
 | PA03950-0419 | 24 packets
Pre-moistened with Cleaner F1. It can be used instead of moistening a cloth with Cleaner F1. |
