Overview
If a solid, lightweight and fully-equipped notebook for mobile or office-based working is what you require, the S792 should be your first choice. This 1.58kg* notebook provides the right balance between mobility and ease of use with its small form factor, and robust magnesium lid. The modular bay options allow for increased battery runtime, a second hard disk drive and Fujitsu’s optional patented bay projector guarantee you maximum flexibility on business trips.
 |
- Enhanced productivity and work performance with new Intel® 3rd Generation Core™ processors. Intel® VPro™ technology provides better security and IT assets management.
- Windows 7 Professional makes your everyday computing easier on your LIFEBOOK S792.
- Extended usage of 11hrs and 30mins with the standard 72Wh battery; Slimmer and lighter at approximately 1.58kg* with the magnesium alloy LCD cover; Vibrant display with the 300 nits WXGA (1366x768) LCD.
- Lower total cost of ownership with modular bay accessories: Bay Battery, Weight Saver, Blu-Ray writer, or Bay Projector. Port replicator further increases the convenience when working interchangeably at desk and on the move.
- Unique Fujitsu Green IT features - 0 watt AC adaptor, ECO mode. 0 watt AC adaptor consumes up to 99% less power compared to standard AC adaptors. ECO mode allow S792 to adjust the power consumption of hardware and LCD backlight according to the working environment.
- Speed up your everyday work by improving the boot up and response performance with the secondary optional mSATA 32GB SSD drive. Alternatively, choose the ExpressCard option for more expandability or choose the SmartCard option to suit the security needs.
- Enjoy high quality videos with the NVIDIA® GeForce® GT 640M LE with Optimus™ technology with 2GB dedicated video memory and DTS Boost™ sound system.
- Human-centric design with the 1080p Full HD webcam. S792 senses your face to resume / pause video playback with the Face Sense utility, in addition to recording high resolution, 1080p Full HD videos.
- Stays connected to the internet and achieve faster data transfer with the new 4G/LTE module option.
|
*with Hard Disk Drive (HDD) and Weight Saver option
Detailed Specs
| Specifications |
| Platform |
Intel® Core™ i7-3632QM (6MB cache, up to 3.20GHz) with Intel® Turbo BoostTechnology17
Intel® Core™ i7-3540M (4MB cache, up to 3.70GHz) with Intel® Turbo Boost Technology17
Intel® Core™ i5-3340M (3MB cache, up to 3.40GHz) with Intel® Turbo Boost Technology17
Intel® Core™ i5-3230M (3MB cache, up to 3.20GHz) with Intel® Turbo Boost Technology17
Intel® Core™ i3-3120M (3MB cache, 2.50 GHz)
Intel® Core™ i3-3110M (3MB cache, 2.40 GHz)
- Intel® QM77 Express Chipset |
| OS Supported |
Windows 7 Professional
Windows 7 Home Premium
Windows 7 Home Basic
Windows 8
|
| Display |
13.3" Anti-Glare HD LED Backlit (1366 x 768 pixels, 300nits brightness) |
| Modular Bay Device |
Dual Layer DVD Super Multi Writer2
Dual Layer Blu-Ray Writable Drive2 |
| Memory |
2GB DDR3 1600MHz
4GB DDR3 1600MHz
8GB DDR3 1600MHz
Max. Memory Supported8 - 2x8GB DDR3 1600MHz, Dual Channel |
| Hard Disk |
1TB (5,400rpm)
750GB (5,400rpm)
500GB (5,400rpm / 7,200rpm)
256GB SSD
128GB SSD |
| Bluetooth® |
v4.0 |
| Battery |
Up to 11hrs 30mins (6cells Li-ion 72Wh)1 |
| Weight |
Approx. 1.58kg (with weight saver and HDD) |
| Detailed Specifications |
| Hard Disk Drive |
SATA-300 5400/7200rpm, S.M.A.R.T support, Two Partitions - 50/507, protected by Fujitsu 3D Shock Sensor11 |
| Graphics |
Intel® HD Graphics 4000 |
| High Definition (HD) Audio |
Realtek ALC269 HD audio codec with Dual Built-in DTS Boost Stereo Speakers
HD Audio-in: External Mic-in, Digital Built-in Microphone
HD Audio-out: Headphone-out |
| Communication |
1000/100/10Mbps3 Gigabit Ethernet
Intel® Centrino® Ultimate-N 6300 Dual Band ABGN network connection
Intel® Centrino® Advanced-N 6205 Dual Band ABGN network connection
Intel® Centrino® Wireless-N 2230 BGN + BT network connection
Separate ON/OFF switch for wireless network connection.
1080p FHD camera
Built-in modem |
| 4G13(Optional) |
Embedded 4.0G (LTE) WWAN connectivity with dual antenna. Up to 100 Mbps peak downlink and 50Mbps peak uplink speed14
- Supports LTE 800/900/1800/2100/2600 MHz
- Supports WCDMA 900/2100 MHz
- Supports triband EDGE/GPRS/GSM: 900/1800/1900MHz
- Supports GPS
Embedded 3.5G (HSPA+) WWAN connectivity with dual antenna. Up to 14.4Mbps downlink and 5.76Mbps uplink speed14
- Supports UMTS (HSPA): 850/900/1900/2100 MHz/AWS
- Supports WCDMA 850/900/1900/2100 MHz/AWS
- Supports quadband EDGE/GPRS/GSM: 850/900/1800/1900MHz
- Supports GPS |
| User Interface |
Spill-resistant Keyboard6: 84-key, 19mm key pitch, 2.7mm key stroke
Intelligent Touch Pad with configurable vertical and horizontal scroll functions
Circular Scroll Wheel |
| Card Slots |
SD/SDHC/SDXC
ExpressCard™ 54/34 support / Smart Card Slot / mSATA 32GB SSD |
| Connector Interface |
USB3.0 w/ Anytime USB Charge plus x 1
USB3.0 x 1
USB2.0 x 1
eSATA Combo
RJ45 (LAN)
Modem
VGA (External display)
Display port
HDA-in, HDA-out
Power Adapter DC-in
Port Replicator Interface |
| Quick Launch Panel |
Five Programmable Application Launch Buttons Security Panel |
| Security4 |
BIOS Lock
Hard Disk Lock
LifeBook Lock
Anti-theft Lock Slot
RF Fingerprint Sensor
Trusted Platform Module v1.2 (optional) |
| Dimensions |
321mm(W) x 228.5mm(L) x 24.7mm-32.3mm(H) |
| Bundled Accessories |
| AC Adapter |
Input AC 100~240V, Output DC 19V 100W
0-Watt AC Adapter Input AC 100~240V, Output DC 19V 80W12 |
| Bundled Software |
Adobe AIR Adobe Reader Cyberlink PowerDirector™ CyberLink PowerDVD™ CyberLink YouCam™ Fujitsu 3D Shock Sensor Utility Fujitsu Anytime USB Charge Utility Fujitsu Application Panel Fujitsu Battery Utility Fujitsu Display Manager Fujitsu FaceSense Utility Fujitsu Hotkey Utility Fujitsu MyRecovery Fujitsu Power Saving Utility Fujitsu Security Panel Fujitsu Support Center Fujitsu UpdateNavi10 Intel Rapid Start15 Microsoft Silverlight Microsoft® Office Starter: reduced-functionality Word and Excel® only, with advertising. No PowerPoint® or Outlook® Mobility Center Extension Utility Oracle Java Roxio Creator LJ Sierra AirCard Watcher Softex Omnipass Norton Internet Security 60 days trial TPM Utility Windows Live Essentials (Windows Live Messenger, Windows Live Photo Gallery, Windows Live Mail, Windows Live Writer, Windows Live Mesh, Windows Live Movie Maker) |
| Optional |
| Port Replicator |
Connector Interface:
USB 2.0 x 4
DVI-D
VGA (external display)
RJ45 (LAN)
Serial
Parallel
eSATA
Audio-out
Power Adapter DC-in
Anti-theft lock |
| Modular Bay Options |
Replaceable with
- Bay Projector
- Bay Battery, 3-cell Li-ion 28Wh, up to 15hrs50mins1 battery life (Standard + Bay Batteries)
- Blu-ray writable drive
- Dual Layer DVD Super Multi writer
- 2nd HDD Fitting Kit (w/o SATA HDD)
- Weight Saver
|
The above information shows the general technical specifications of the product and does not represent actual configuration. For specific configurations and their availability, please check with your local distributors.
Disclaimer
1 Results obtained from BAPCo MobileMark 2007(Productivity Workload) performed on systems with maximum battery life settings under laboratory testing environment. Actual battery life will vary based on screen brightness, sound volume settings, running applications, connected peripherals, power management settings, battery conditioning, and other customer preferences in the real life situation. Built-in bay device or hard drive usage may also have a significant impact on battery life. Note: Approx. 11hrs30mins battery life is based on Intel® Core™ i5-3320 with standard 72Wh battery. Approx. 15hrs50mins battery life is based on Intel® Core™ i5-3320 with standard 72Wh battery + 28Wh bay battery.
2 Supports DVD multi formats such as DVD-RAM, DL DVD±R, DVD±RW, DVD±R, CD-RW, DVD-ROM, CD-R and CD-ROM.
3 This term does not represent actual data rate of 1000/100/10Mbps and simply indicates compliance with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab standards. Actual maximum data rate depends on network configurations, cable conditions as well as connected devices.
4 BIOS Lock needs a supervisor/user password to access BIOS setup. BIOS settings can be configured to prompt for password at every first bootup or all bootup sequences. Access to BIOS setup is needed to configure Hard Disk Lock. Hard Disk Lock requires an access key to retrieve data on the hard disk. This is a Data Confidentiality security feature. LIFEBOOK Lock requires a supervisor/user password to bootup the LIFEBOOK when it powers up or resumes last session from suspend/hibernate mode. Anti-theft Lock Slot allows the use of a lock to physically secure the LIFEBOOK. Full security unlock sequence - LIFEBOOK Lock, Bootup Lock (BIOS Lock), Hard Disk Lock, Fingerprint Windows Logo.It is the customer's responsibility to ensure the safekeeping of password for data retrieval.
5 RoHS (Restriction on Hazardous Substances) compliance means the system and its internal components comply with the EU RoHS directive (2002/95/EC) on the restricted use of six hazardous substances in the production of the system and its internal components.
6 Spill-resistant keyboard does not imply the system is water-proof. If liquid is spilt onto the keyboard, power off the system immediately and turn the notebook upside down to drain off the liquid.
7 This refers to Windows 7® hard disk drives C:\ and D:\. 50/50 refers to approximate 50% allocation of user accessible hard disk storage to C:\ and D:\ drives. For Windows 7® hard disk drives, 32GB will be reserved for internal recovery usage which is not shown.
8 2x8GB DDR3 1600MHz maximum memory is supported when Fujitsu recommended 8GB DDR3 1600MHz memory module is made available. 2x8GB option is only valid in 64-bit platform
9 Customer may select between 32-bit and 64-bit upon initial startup.
10 UpdateNavi is a Fujitsu Proprietary application that updates LifeBook drivers by connecting automatically to Fujitsu's server. This will help update your LifeBook with the latest software drivers and utilities to ensure compatibility between hardware and software, maintaining smooth operation anytime, anywhere.
11 Fujitsu 3D Shock Sensor of a powered-up unit retracts hard disk read-write head to a secured zone upon detection of excessive vibrations or shocks. This greatly reduces the possibility of damage to the hard disk and its content - example in the event of a sudden drop or impact. The sensor monitors movement from three axes and its sensitivity can be adjusted by user to accommodate different working environments using the Fujitsu 3D Shock Sensor Utility.
12 0-Watt feature is switched off when user has software or hardware that requires constant activity and thus power. For example, when connected to a Port Replicator, Wake up on LAN is enabled or USB charging features is enabled.
13 4G configuration availability varies from countries. Please check with actual bundling of local distributor. 4G module comes with a 1 year local carry-in warranty.
14 Subjected to network and SIM capabilities. Data rates refer to download or upload speed which is also dependent on network capabilities and conditions.
15 Intel Rapid Start is only available when equipped with HDD and mSATA SSD.
16 Intel Smart Response is only available when equipped with QM77 or above, and 2nd HDD kit or SSD.
It is natural for all thin-film transistor (TFT) liquid crystal displays (LCD) to show a small number of missing or discolored dots. These are commonly known as non-conforming pixels. This is a technology limitation of TFT LCD and does not represent a defect. Fujitsu warranty does not cover limitations in technology such as non-conforming pixels.
Specifications reflected above are engineering and hardware specifications. They do not represent actual usage or operating dimensions, sizes, performances and weights as these are dependent on factors such as operating temperature, type of operating system and application used, connected devices and accessories as well as hardware configurations of the notebook. Please check the compatibility of 3rd party accessories before purchase. Please note that GB = billion bytes. 1GB is equivalent to 1,073,741,824 bytes.
