FUJITSU Desktop ESPRIMO P7010

Features & Benefits

Features	Benefits
Windows Windows 10 Home Windows 10 Pro. Fujitsu recommends Windows 10 Pro for business.	Easy integration into customers’ existing infrastructure
Powerful performance with latest Intel^® technology Latest 10th generation Intel^® Core™ processor family Higher memory speed, higher clock frequency, improved integrated graphics	Powerful performance for smooth running of office applications
Easy serviceability and usability Tool-less access to components and interfaces for ease of use USB Type-C (USB 3.2 Gen2) front connector which supports power delivery up to 15W	Features designed for easy access, control and use of the system
Best-in-Class connectivity Flexible graphics connector options: VGA, DVI-D, HDMI, Type-C Type C option supporting 60 Watt output power to run a display w/o extra power supply Legacy connectors as option: PS/2, serial port, parallel port	Be flexible and stay productive in a hyper-connected world
Robust Security Cable cover with lock option at the back to protect ports, cables and components from theft. Embedded Trusted Platform Module (TPM), passwords and EraseDisk software on system-level. SmartCard reader available as option	Designed to protect data and hardware components against manipulation and theft
Ultimate Expandability 4 memory bay and 3 display outputs , Full-height slots for special purpose cards, DVD bay in horizontal position for convenient access Two 3.5” hard disk bay for huge mass storage capacity	Most expandable microtower business PC with rich configuration options

Technical details

Product	ESPRIMO P7010
Operating system	Windows 10 Home Windows 10 Pro. Fujitsu recommends Windows 10 Pro for business.
Operating system notes	Windows 10 Support: After the end of the product life FUJITSU will continue to test and support all upcoming Window 10 releases for a period of maximum 5 years – depending on the available extension of hardware services through FUJITSU Warranty top ups. For details please see “FUJITSU Service Statement for Windows 10 Semi-Annual-Channel Support” at http://support.ts.fujitsu.com.
Mainboard	D3823-A2 (proprietary )
Chipset	Intel^® B460
Processor	Intel^® Core™ i9-10900 processor, 20 MB, 2.80 GHz Intel^® Core™ i7-10700 processor, 16 MB, 2.90 GHz Intel^® Core™ i5-10400 processor, 12 MB, 2.90 GHz Intel^® Core™ i5-10500 processor, 12 MB, 3.10 GHz Intel^® Core™ i5-10600 processor, 12 MB, 3.30 GHz Intel^® Core™ i3-10100 processor, 8 MB, 3.60 GHz Intel^® Celeron^® processor G5905, 4 MB, 3.50 GHz Intel^® Pentium^® Gold G6400, 4 MB, 4.00 GHz
Supported capacity RAM (max.)	128 GB, 4 Memory slot(s) DIMM (DDR4), Dual channel support, For dual channel performance, 2 memory modules have to be ordered. Capacity per channel has to be the same. 2933 MHz may be clocked down to 2400MHz depending on processor and memory configuration
Serial ATA total	4
thereof SATA III	Serial ATA III (6 Gbit), NCQ, AHCI
Drives (optional)	DVD Super Multi, SATA DVD Super Multi ultra slim (tray), SATA BD Triple Writer SATA ultra slim (tray), SATA MultiCard Reader 15in1 USB 3.0 3.5”, USB 3.0
Drive bay	1 x 3.5-inch external bay 2 x 3.5-inch internal bay 2 x 5.25-inch external bay
Slots	1 x PCI-Express 3.0 x4 (mech. x16) 1 x PCI-Express 3.0 x16 1 x PCI-Express 3.0 x1
Interfaces	1 x Audio: line-in 1 x Audio: line-out 6 and 1 optional USB 3.2 Gen 1 (5 Gbps) total 2 x USB 3.2 Gen 2 (10 Gbps) total 4 x USB 2.0 total 2x USB 2.0; 1x USB 3.2 Gen 1; 1x USB 3.2 Gen 2; 1x USB 3.2 Gen 2 Type-C (supports up to 15W) x USB front 2x USB 2.0; 4x USB 3.2 Gen 1; optional: additional 1x USB 3.2 Gen 1 Type-C (supports DisplayPort 1.4 and power delivery (PD) up to 15W or 60W (occupies PCIe x16 slot) x USB rear 1x USB 2.0 or 1x USB 3.2 Gen 1 Type A x USB internal optional VGA 1 (optional) x Parallel (25pin with EPP and ECP) 1 x Ethernet (RJ-45) 1 x Kensington Lock support optional (DVI-D) x DVI 2 x DisplayPort 2 (optional) x Mouse / Keyboard (PS/2)
Graphics	Intel^® UHD Graphics 610, Intel^® UHD Graphics 630, Up to half size of total system memory
Audio type	Realtek ALC623
Communication	10/100/1,000 MBit/s Realtek RTL8111H
Weight	approx. 10 kg approx. 10 kg lbs
Dimensions (W x D x H)	180 x 304 x 375 mm 7.09 x 11.97 x 14.76 inch
Power efficiency note	Power supply efficiency in % at 10% / 20% / 50% / 100% load 80Plus GOLD: for 230V ; 87/90/92/91 for 115V ; 86/89/91/88 80Plus PLATINUM: for 230V ; 88/92/94/93 for 115V ; 87/91/92/91
Warranty period	1 year
