Overview
Takes document scanning just about anywhere
At nearly 350g (12 ounces), the ScanSnap S1100i is the lightweight companion for front-side document scanning at home or on the road. Whether scanning receipts, contracts, recipes, or plastic cards, ScanSnap takes scanning beyond the desktop and into your world.
- One touch scanning
- Scan paper as small as an inch up to 863 mm (34 in.) long
- Dual Scan for scaning two small documents at the same time
- Auto two page stitching for scanning documents larger than A4
- USB powered
- Compatible with PC and Mac
- Best experience with ScanSnap Home
Features
Mobile Scanning
The ScanSnap S1100i is designed to bring full size document scanning productivity out into the world, wherever you go.
Scan to:
- PDF
- Searchable PDF
- JPEG
- Word (editable)
- Excel (editable)
- Business Cards
Compact, Sleek and Portable
At nearly 350g (12 ounces), the ScanSnap S1100i provides ultimate scanning portability. Whether you're always on the run or need discrete technology for a space conscious lifestyle, the S1100i is the perfect companion.
More Efficiency with Dual scan
Scan two small sized documents, such as business cards or receipts at the same time.
Automatically Stitch a Two-Page Spread
Even charts and diagrams larger than A4 can be scanned. Just fold it in half, scan both sides and the S1100i will automatically stitch it back together.
USB Bus Power for Ultimate Portability
The ScanSnap S1100i is powered from your PC or Mac's USB port.
Best experience with ScanSnap Home
ScanSnap Home combines all your favorite functions into one and is the ultimate platform to utilize scanned data in various ways. Easily manage, edit and utilize data from documents, business cards, receipts and photos with the software. You can scan large volumes of various types of documents from color photos to double-sided landscape documents with a host of intelligent automatic image processing functions.
*Data can be transferred to ScanSnap Home from ScanSnap Organizer, ScanSnap Receipt and CardMinder.
Specifications
| Product Name |
ScanSnap S1100i |
| General Technical Specifications |
| Scanner Type |
Single fed (Straight / U-turn path), CDF (Continuous Document Feeding), Simplex |
| Scanning Modes |
Color, Grayscale, Monochrome, Automatic (Color / Grayscale / Monochrome detection) |
| Image Sensor |
CIS (Color Image Sensor) x 1 |
| Light Source |
3 color LED (Red / Green / Blue) |
| Optical Resolution |
600 dpi |
Scanning Speed(1)
(A4 portrait / AC adapter) |
Auto Mode(2) |
7.5 seconds per page |
| Normal Mode |
7.5 seconds per page |
| Better Mode |
7.5 seconds per page |
| Best Mode |
7.5 seconds per page |
| Excellent Mode |
35 seconds per page |
| Document Size |
Normal Mode |
Maximum: 216 x 360 mm (8.5 in. x 14.17 in.)
279 x 431.7 mm (11 in. x 17 in.) with Carrier Sheet
Minimum: 25.4 x 25.4 mm (1 in. x 1 in.) |
| Long Paper Scanning(3) |
863 mm (34 in.) |
| Paper Weight (Thickness) |
52 to 209 g/m2 (14 to 56 lb) (Straight path), 52 to 80 g/m2 (14 to 20 lb) (U-turn path)
Cards: 0.76 mm or less (Non-embossed), 0.76 + 0.48 mm (Embossed) (ISO7810 Conforming) |
| Paper Setting |
Front-side up |
| Interface(4) |
USB 2.0 / USB 1.1 |
| Power Requirement |
5 V / 0.5 A |
| Power Consumption |
Operating Mode |
2.5 W or less |
| Sleep Mode |
1 W or less |
| Auto Standby (Off) Mode |
Less than 0.5W |
| Operation Environment |
Temperature |
5 to 35 °C (41 to 95 °F) |
| Relative Humidity |
20 to 80 % (Non-condensing) |
| Dimensions (W x D x H)(5) |
273 x 47.5 x 34 mm (10.74 x 1.87 x 1.33 in.) |
| Device Weight |
350 g (0.77 lb) |
| Environmental Compliance |
ENERGY STAR® / RoHS |
| Driver |
ScanSnap specific driver
· Windows®: Does not support TWAIN/ISIS®
· Mac OS: Does not support TWAIN |
| Inbox Contents |
Getting started, Set-up DVD-ROM, USB cable |
- Scanning speeds may vary due to the system environment used. The time is measured between start of document feeding to finish of document output.
- Scans will be made in "Best mode" if shorter sides are less than 148 mm (5.8 in.) and in "Better mode" if not.
- Capable of scanning documents that exceed A4 size in length except for “Excellent Mode”.
- Computer with USB 3.0 will work as USB 2.0 guaranteed only with USB cable provided with product.
- When chute is closed.
System Requirements for PC
| Compatible Operating Systems |
Windows |
10 / 8.1
(32-bit / 64-bit)(1) |
7
(32-bit / 64-bit) |
| Driver / Applications(2) |
ScanSnap Home(4) |
Supported |
Supported |
| ABBYY FineReader for ScanSnap™ |
Supported |
Supported |
| Hardware Requirements(3) |
CPU(5) |
Intel® Corelon 1.8 GHz (2 core) or higher (Recommended: Intel® Core™ i5 2.5 GHz or higher) |
| Memory Capacity(5) |
2 GB or more (Recommended: 4 GB or more) |
| Display Resolution |
1,024 × 768 pixels or more |
| Disk Capacity(6) |
3.8 GB or more of the free hard disk space |
- Operate Windows in desktop mode.
- Operating systems listed in this table are the only ones supported. Please refer to the ScanSnap Support site for the latest support information.
- The ScanSnap device may not work if the connected computer does not meet these requirements.
- Installation requires a computer and Internet. Activation is also necessary for software use. Please visit the ScanSnap Support site for download information.
- Scanning speeds may drop if recommended CPU, memory capacity and USB 1.1 requirements are not met.
- .NET Framework 4.7 or later must be installed. If it is not installed, it is installed with ScanSnap Home. Up to 4.5 GB of disk space is required for the installation.
*The system requirements may change depending on the duration of support and the support policy of the companies that make the software listed in the table above.
System Requirements for Mac
| Compatible Operating Systems |
macOS v10.14 |
macOS v10.13 |
macOS v.10.12(1) |
| Driver / Applications(2) |
ScanSnap Home(4) |
Supported |
Supported |
Supported |
| ABBYY FineReader for ScanSnap™ |
Supported |
Supported |
Supported |
| Hardware Requirements(3) |
CPU(5) |
Intel® Core i5 1.4 GHz or higher (Recommended: Intel® Core™ i5 2.5 GHz or higher) |
| Memory Capacity(5) |
2 GB or more (Recommended: 8 GB or more) |
| Display Resolution |
1,024 x 768 pixels or more |
| Disk Capacity |
2.0 GB or more of the free hard disk space |
- macOS v10.12.4 or later is required.
- Operating systems listed in this table are the only ones supported. Please refer to the ScanSnap Support site for the latest information.
- The ScanSnap device may not work if the connected computer does not meet these requirements.
- Installation requires a computer and Internet. Activation is also necessary for software use. Please visit the ScanSnap Support site for download information.
- Scanning speeds may drop if the recommended CPU, memory capacity and USB 1.1 requirements are not met.
*The system requirements may change depending on the duration of support and the support policy of the companies that make the software listed in the table above.
