FUJITSU Desktop ESPRIMO K558/24

Features & Benefits

Features	Benefits
Windows Windows 10 Pro. Fujitsu recommends Windows 10 Pro. Windows 10 Home	Easy integration into customers’ existing infrastructure
Human-Centric Setup 60.5 cm (23.8-inch) anti-glare Full HD display with wide viewing angle screen for exceptional sensory experience. Ergonomic design that includes four-stage height adjustment, a large swivel range and low noise. The keyboard can be placed between the screen and the bottom plate for additional desk space. Wall mounting in accordance with the VESA standard.	Tidy and convenient desk with ergonomic working position to help enhance working experience and efficiency
Unrivalled Usability Easy to access and flexible interfaces, microphone and camera option for instant office communication and anytime USB charge functionality	Wide range of features designed to ease your working experience
Manageability and Ease of Use Easy to integrate into existing IT landscapes and reliable DeskView manageability tools	'"Plug & work" PC that ensures smooth system administration
Excellent Performance and Energy Efficiency 8th generation Intel^® Core™ processor family and a highly efficient power supply	Best-in-class regarding low power consumption combined with new levels of performance
Robust Security Cable cover with lock option at the back to protect ports, cables and components from theft. Embedded Trusted Platform Module (TPM), Fujitsu Workplace Protect software with full disk encryption and system-level passwords. EraseDisk software and SmartCard are available as options	Designed to protect data and hardware components against manipulation and theft

Technical details

Product	ESPRIMO K558/24
Operating system	Windows 10 Pro. Fujitsu recommends Windows 10 Pro. Windows 10 Home
Operating system notes	Certified for SUSE Enterprise Desktop (pending), Windows 10 Support: After the end of the product life FUJITSU will continue to test and support all upcoming Window 10 releases for a period of maximum 5 years – depending on the available extension of hardware services through FUJITSU Warranty top ups. For details please see “FUJITSU Service Statement for Windows 10 Semi-Annual-Channel Support” at http://support.ts.fujitsu.com.
Diagonal Size	60.5 cm (23.8-inch)
Resolution (native)	1,920 x 1,080 pixel
Viewing angle (h/v) - typical	178°/178° CR10:1
Brightness - typical	250 cd/m2
Mainboard	D3674 (proprietary )
Chipset	Intel^® H310
Processor	Intel^® Core™ i7-8700T processor, 12 MB, 2.40 GHz, up to 4.0 GHz Intel^® Core™ i5-8500T processor, 9 MB, 2.10 GHz, up to 3.5 GHz Intel^® Core™ i5-8400T processor, 9 MB, 1.70 GHz, up to 3.3 GHz Intel^® Core™ i3-8100T processor, 6 MB, 3.10 GHz Intel^® Core™ i5-8500 processor, 9 MB, 3.00 GHz Intel^® Core™ i5-8400 processor, 9 MB, 2.80 GHz Intel^® Core™ i3-8100 processor, 6 MB, 3.60 GHz Intel^® Pentium^® processor G5400T processor, 4 MB, 3.10 GHz Intel^® Pentium^® Gold G5400 processor, 4 MB, 3.70 GHz Intel^® Celeron^® processor G4900, 2 MB, 3.10 GHz
Supported capacity RAM (max.)	32 GB, 2 Memory slot(s) DIMM (DDR4), Dual channel support, For dual channel performance, 2 memory modules have to be ordered. Capacity per channel has to be the same. 2666 MHz may be clocked down to 2400 or 2133 depending on used processor
Serial ATA total	2
thereof SATA III	Serial ATA III (6 Gbit), NCQ, AHCI
Drives (optional)	DVD Super Multi ultra slim (tray), SATA BD Triple Writer SATA ultra slim (tray), SATA
Hard disk drive	HDD SATA II, 5,400 rpm, 1,000 GB, 2.5-inch HDD SATA III, 5,400 rpm, 500 GB, 2.5-inch HDD SATA III, 7,200 rpm, 500 GB, 2.5-inch SSD PCIe, 256 GB M.2 NVMe module SSD PCIe, 256 GB M.2 NVMe module, SED SSD PCIe, 512 GB M.2 NVMe module SSD PCIe, 512 GB M.2 NVMe module, SED SSD PCIe, 1024 GB M.2 NVMe module SSD PCIe, 1024 GB M.2 NVMe module, SED SSD SATA III, 128 GB, 2.5-inch SSD SATA III, 256 GB, 2.5-inch SSD SATA III, 512 GB, 2.5-inch SSD SATA III, 1024 GB, 2.5-inch
Drive bay	1 x 5.25-inch internal bay
Interfaces	1 x Audio: line-in / microphone 1 x Audio: line-out / headphone 1 x Front audio: headphone 1 x Front audio: microphone optional with multimedia module (camera and microphone) x Internal microphones 4 x USB 3.1 Gen1 (USB 3.0) total 3 x USB 2.0 total 2x USB 3.0 x USB front 3x USB 2.0, 2x USB 3.0 x USB rear 1 x Serial (RS-232) optional 1 x Ethernet (RJ-45) 1 x Kensington Lock support 1 x DisplayPort 2 x Mouse / Keyboard (PS/2)
Graphics	Intel^® UHD Graphics 610, Intel^® UHD Graphics 630, Up to half size of total system memory
Audio type	Realtek ALC255
Communication	10/100/1,000 MBit/s Realtek RTL8111G 1 (optional with Bluetooth together) x Integrated WLAN
Weight	app. 9.7 kg 14.33 lbs
Dimensions (W x D x H)	560 x 93 x 368 mm 22.1 x 3.67 x 14.5 inch
Power efficiency note	power supply efficiency (at 230V; 10% / 20% / 50% / 100% load) : 85% / 90% / 93% / 93%
Special features	Adjustable display, Made in Germany, Space saving design, TPM, USB and Audio in front
Warranty type	Bring-In / Onsite Service (for countries within region EMEIA, for all other countries depending on local regulations)

Accessories

FUJITSU Display B24-9 TS
	The FUJITSU Display B24-9 TS is a widescreen display with 1920 x 1080 Full HD resolution with a ultra-thin bezel housing. The monitor has a wide viewing angle that delivers consistent picture quality and DisplayView™ manageability software for further enhancing monitor features with a range of connectivity options ideal for medium- and large-sized businesses.
FUJITSU Display E24-9 TOUCH
	The FUJITSU Display E24-9 TOUCH is a 10 point projected capacitive touch (PCT) ergonomic display with 1920 x 1080 Full HD resolution. The monitor screen has anti-glare that helps prevent smudges, spots and blurs owing to touch-intensive tasks. The monitor also has powerful built-in speakers and a range of interfaces for easy connectivity and maximum flexibility.
Keyboard KB951 PalmM2
	The KB951 palm vein keyboard is a modern, slim line USB keyboard featuring Fujitsu PalmSecure™ technology with an integrated palm vein sensor. PalmSecure™ is a cutting-edge authentication system using biometric technology that authenticates users based on vein pattern recognition rather than iris scanners or fingerprint readers. As veins are internal and have a wealth of differentiating features, attempts at identity theft are extremely difficult, enabling a high level of security. This extremely reliable, high-speed input device is the best choice when you don’t have a PC or notebook with an integrated palm vein sensor.
Wireless Mouse Touch WI910
	The Fujitsu Wireless Mouse Touch WI910 has a special touch sensitive surface that recognizes when your hand touches the mouse even before you move it. This provides nearly instantaneous wake-up from the intelligent energy saving sleep mode. Unbeatable responsiveness combines with features like switchable resolution, and three programmable buttons for a unique user experience.
