FUJITSU Server PRIMERGY RX4770 M6

ImgPlaceholder ImgPlaceholder ImgPlaceholder ImgPlaceholder
POWER YOUR BUSINESS-CRITICAL WORKLOADS
SCALABLE APPLICATION PERFORMANCE
FLEXIBLE EXPANDABILITY AND RELIABILITY
SECURE AND RELIABLE

PRIMERGY RX4770 M6 server provides 4 processor computing in a 3U form factor, accelerates business insights and delivers maximum performance per node with highest memory bandwidth and IO lanes for your most demanding applications. Moreover, a flexible processor tray allows to start with two CPU’s and scale to four processors in the future saving on upfront costs.

Address large data sets with up to 48 DIMMs (24 of which can be Intel® Optane™ PMem) and up to 15 TB of memory. Intel® Optane™ persistent memory provide fast, high capacity and cost effective memory for memory intensive workloads such as AI and data analytics.

The flexible drive cage design supports up to 24x 2.5” SAS/SATA/NVMe storage drives. Sufficient expandability for future requirements is guaranteed by PCIe 3.0 expansion slots for graphical processing units (GPUs) and all kinds of networking cards offering increased I/O bandwidth and to be able to cope with graphic-intensive applications. Choice of DynamicLoM adapters offers range of networking bandwidth (1GbE to 25GbE) to be able to adapt and grow to changing business needs.

The integrated Platform Firmware Resilience (PFR) feature provides a platform root of trust and thus helps to protect platform firmware, detect corruptions, and restore back to a known-good state.

  • ImgPlaceholder
    POWER YOUR BUSINESS-CRITICAL WORKLOADS
    PRIMERGY RX4770 M6 server provides 4 processor computing in a 3U form factor, accelerates business insights and delivers maximum performance per node with highest memory bandwidth and IO lanes for your most demanding applications. Moreover, a flexible processor tray allows to start with two CPU’s and scale to four processors in the future saving on upfront costs.
  • ImgPlaceholder
    SCALABLE APPLICATION PERFORMANCE
    Address large data sets with up to 48 DIMMs (24 of which can be Intel® Optane™ PMem) and up to 15 TB of memory. Intel® Optane™ persistent memory provide fast, high capacity and cost effective memory for memory intensive workloads such as AI and data analytics.
  • ImgPlaceholder
    FLEXIBLE EXPANDABILITY AND RELIABILITY
    The flexible drive cage design supports up to 24x 2.5” SAS/SATA/NVMe storage drives. Sufficient expandability for future requirements is guaranteed by PCIe 3.0 expansion slots for graphical processing units (GPUs) and all kinds of networking cards offering increased I/O bandwidth and to be able to cope with graphic-intensive applications. Choice of DynamicLoM adapters offers range of networking bandwidth (1GbE to 25GbE) to be able to adapt and grow to changing business needs.
  • ImgPlaceholder
    SECURE AND RELIABLE
    The integrated Platform Firmware Resilience (PFR) feature provides a platform root of trust and thus helps to protect platform firmware, detect corruptions, and restore back to a known-good state.

Product Video

Tech Specs

Chipset Intel® C621A
Mainboard type D3892
Product Type Quad Socket Rack Server
Processor Intel® Xeon® Gold 53xxH processors, Intel® Xeon® Gold 63xxH processors, Intel® Xeon® Platinum 83xxH processors
2 or 4
Memory 16 GB - 15 TB, DIMM (DDR4 RDIMM, LRDIMM and Intel® Optane™ PMem)
Memory slots 48 (12 DIMMs per CPU, 6 channels with 2 slots per channel)
Memory protection ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
Drives (optional) DVD supermulti, ultraslim, SATA I
PCI-Express 3.0 x16 11 x whereas 4x full height and 7x low profile
Optional accessible drives 1 x 5.25/9.5mm for DVD-RW/Blu-ray
All possible options described in relevant system configurator.
Storage drive bays 2.5-inch hot-plug SAS/SATA/PCIe
2 x M.2 slots
8 x 2.5-inch hot-plug SAS/SATA/PCIe
16 x 2.5-inch hot-plug SAS/SATA/PCIe
24 x 2.5-inch hot-plug SAS/SATA/PCIe
LAN Controller Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s QSFP28, 2x 100 Gbit/s QSFP28
Remote Management Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible
USB ports 5 x USB 3.0 (2x front, 2x rear, 1x internal)
Graphics 2 x VGA (1 x front, 1 x rear)
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s)
Trusted Platform Module (TPM) Infineon / TPM 2.0 module; TCG compliant (option)
Power supply configuration 2 hot-plug power supplies (standard)
Active power (max. configuration) 2,518 W
Weight max. 40 kg
Rack (W x D x H) 482.7 mm (Bezel) / 435 mm (Body) x 800 x 129.4 mm
Mounting Depth Rack 830.7 mm
DC Infrastructure Management Infrastructure Manager (ISM)
Essential
Advanced
Server Management Infrastructure Manager (ISM)
Essential
Advanced, ServerView Suite
Operating system http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe
Warranty period 3 years
Warranty type Onsite warranty
Service Lifecycle 5 years after end of product life
Service Weblink http://www.fujitsu.com/emeia/products/product-support-services/
Support Pack Options Globally available in major business areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)
Recommended Service 24x7, Onsite Response Time: 4h - For locations outside of EMEIA please contact your local Fujitsu partner.
Support Pack Options Globally available in major business areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)
Recommended Service 24x7, Onsite Response Time: 4h - For locations outside of EMEIA please contact your local Fujitsu partner.
