Powerful server that serves your services

Fujitsu PRIMERGY RX2450 M1

PRIMERGY Server RX2450 M1

Fujitsu PRIMERGY RX2450 M1

Fujitsu PRIMERGY RX2450 M1

  • Dual-socket x86 server (2U) powered by AMD EPYC™ 7002/7003 Series Processors
  • Scale from 8 to 64 cores (16 to 128 threads) per socket, up to 256MB L3 Cache
  • Ideal for virtualized environments, as high-end enterprise server and for data-intensive workloads
  • Drive traditional and emerging workloads with 32 DIMM slots (up to 4 TB memory)
  • Scale to meet demands with up to 24x 2.5” storage drives, M.2 drives for booting, NVIDIA GPU cards and up to 4x PCIe 4.0 expansion slots

ImgPlaceholder ImgPlaceholder ImgPlaceholder ImgPlaceholder
SECURE, HIGH PERFORMANCE COMPUTING
EXPANDABILITY AND DENSITY
AGILE INFRASTRUCTURE MANAGEMENT
SECURITY

The versatile PRIMERGY RX2450 M1 server with AMD EPYC™ 7002/7003 processors shortens time to value for IT organizations running demanding workloads.

Agile and data-driven companies modern platforms that scale easily and are optimized for application performance. The PRIMERGY RX2450 M1 is built upon a scalable system architecture and provides choice and flexibility to meet performance demands.

As you scale your infrastructure, scale your profitability with FUJITSU Software Infrastructure Manager (ISM). ISM enables organizations to have centralized control over the entire data center, which includes servers, storage, networking, cloud management software as well as power and cooling using a single user interface.

Designed with security in mind, AMD EPYC™ 7003 series processors help protect your CPU, applications, and data. And with the range of features you need to power your business, you can adapt your IT infrastructure to match workload challenges you face today and into the future.

  • ImgPlaceholder
    SECURE, HIGH PERFORMANCE COMPUTING
    The versatile PRIMERGY RX2450 M1 server with AMD EPYC™ 7002/7003 processors shortens time to value for IT organizations running demanding workloads.
  • ImgPlaceholder
    EXPANDABILITY AND DENSITY
    Agile and data-driven companies modern platforms that scale easily and are optimized for application performance. The PRIMERGY RX2450 M1 is built upon a scalable system architecture and provides choice and flexibility to meet performance demands.
  • ImgPlaceholder
    AGILE INFRASTRUCTURE MANAGEMENT
    As you scale your infrastructure, scale your profitability with FUJITSU Software Infrastructure Manager (ISM). ISM enables organizations to have centralized control over the entire data center, which includes servers, storage, networking, cloud management software as well as power and cooling using a single user interface.
  • ImgPlaceholder
    SECURITY
    Designed with security in mind, AMD EPYC™ 7003 series processors help protect your CPU, applications, and data. And with the range of features you need to power your business, you can adapt your IT infrastructure to match workload challenges you face today and into the future.

Tech Specs

Chipset System on Chip (SoC)
Mainboard type MBD-H12DSU-IN-P
Product Type Dual Socket Rack Server
Processor AMD EPYC™ 7002 series processor, AMD EPYC™ 7003 series processor
Memory 64 GB - 4 TB, DIMM (DDR4) ECC
Memory slots 32 (16 DIMMs per CPU)
Memory protection Advanced ECC
PCI-Express 4.0 x16 4 x Full height 3x PCIe Gen4 x16 for double-wide GPU, 1x PCIe Gen4 x16
Storage drive bays Up to 24: 16x 2.5-inch SATA only + 4x 2.5-inch SAS/SATA + 4x 2.5-inch NVMe (PCIe Gen3)
There are 4 kinds of storage drive bay configurations.
- PYR2451RAT :16xOnboard SATA, 4xOnboard PCIeSSD
- PYR2451RBT :12xOnboard SATA, 4xSATA under Raid/HBA, 4xSATA/SAS under Raid/HBA, 4xOnboard PCIeSSD
* 1pcs CP503i or 1pcs EP520i controller are required.
- PYR2451RCT :4xOnboard SATA, 12xSATA under Raid/HBA, 4xSATA/SAS under Raid/HBA, 4xOnboard PCIeSSD
* 2pcs CP503i or 2pcs EP520i or 1pcs EP540i or 1pcs EP 580i controller are required.
- PYR2451RDT :16xSATA under Raid/HBA, 4xSATA/SAS under Raid/HBA, 4xOnboard PCIeSSD
* 2pcs EP540i or 2pcs EP 580i controller are required.
LAN Controller 2x 1GbE (Use AOC LAN card)
Remote Management BMC with 256 MB DDR4-800 SRAM for video, IPMI 2.0 compatible
USB ports 2 x USB 3.0 (2x rear)
Graphics 1 x VGA (1x rear)
Management LAN (RJ45) 1x 1GbE (1x rear)
Power supply configuration 2 hot-plug power supplies
Weight up to 32.7 kg
Rack (W x D x H) 437 x 705.3 x 89 mm
DC Infrastructure Management Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
Server Management Infrastructure Manager (ISM)
Essential Edition
Advanced Edition, ServerView RAID Manager
Operating system http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Warranty period 3 years
Warranty type Onsite warranty
Service Lifecycle at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
Service Weblink http://www.fujitsu.com/emeia/products/product-support-services/
Service Weblink http://www.fujitsu.com/emeia/products/product-support-services/
Support Pack Options Globally available in major metropolitan areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)
Recommended Service 24x7, Onsite Response Time: 4h - For locations outside of EMEA please contact your local Fujitsu partner.
Support Pack Options Globally available in major metropolitan areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)
Recommended Service 24x7, Onsite Response Time: 4h - For locations outside of EMEA please contact your local Fujitsu partner.

Press

Components

Fujitsu PRAID EP520i

The Fujitsu RAID Controller PRAID EP520i with 2GB cache and 8x12Gbit/s SAS ports improves performance for storage intensive workloads such as databases and sets new speed and data security standards for internal storage drives. The new PRAID EP520i supports up to 8 SAS/SATA drives or up to 2 NVMe drives. NVMe is an interface with lower overhead, lower latency and drastically increased bandwidth and IOP's. The NVMe drive support will be available at a later date, but the SAS and SATA drives will benefit from the improved performance and higher cache size.The RAID stack is based on the Broadcom MegaRAID® and offers high data throughput, a comprehensive fault tolerance function and user-friendly management options.

Fujitsu PRAID EP540i

The Fujitsu RAID Controller PRAID EP540i with 4GB cache and16x12Gbit/s SAS ports improves performance for storage intensive workloads such as databases and sets new speed and data security standards for internal storage drives. The new PRAID EP540i supports up to 16 SAS/SATA drives, up to 4 NVMe PCIe drives or a mixture of SAS/SATA and NVMe drives. NVMe is an interface with lower overhead, lower latency and drastically increased bandwidth and IOP's. The RAID stack is based on the Broadcom MegaRAID® and offers high data throughput, a comprehensive fault tolerance function and user-friendly management options. Moreover, the Controller management is integrated seamlessly into the Fujitsu server management concept. All controller functions are supported by the Fujitsu ServerView RAID Manager. The PRAID EP540i is designed for 3, 6 and 12Gbit/s SAS as well as for 3 and 6Gbit/s SATA drives. Regardless of the drive speed, it delivers significant performance improvements in both read and write applications.

FUJITSU PFC EP Emulex LPe31000 / LPe31002 Fibre Channel Adapters

The Emulex Gen 6 16 Gb Fibre Channel (FC) Host Bus Adapters (HBA) by Broadcom for PRIMERGY and PRIMEQUEST server systems are optimal Fibre Channel HBAs for virtualized, cloud and mission critical deployments. The PFC EP Emulex Gen 6 Fibre Channel HBAs LPe31000/31002 by Broadcom take performance to a new level with PCIe 3.0 support, data integrity capabilities and cloud scale reliability, and ease of use. Organizations looking to improve performance, protect against data corruption, and simplify operations of FC SANs in cloud or high performance environments can benefit from deploying the PFC EP LPe31000/31002.
