Thunderbolt™ 4 Port Replicator

Thunderbolt™ 4 Port Replicator

First Thunderbolt™ Port Replicator on the market providing enhanced security and full support of Intel® AMT (vPro®).
With this universal port you can easily connect almost everything with a single cable and high speed-data transfer. The smart workspace solution keeps your desk clean and tidy.

More Details
ImgPlaceholder ImgPlaceholder ImgPlaceholder
Reliability
Ease of Use
Usability

High quality and stability
Everything you need from one source

On/off button (switching on dedicated FUJITSU devices)
Full support of Intel® AMT (vPro®)
USB charging LED
2x USB Type-C with Thunderbolt™ 4, 2x USB Type-C and 3x USB Type-A interfaces
DisplayPort 2x (up to 4,096 x 2,160, 60 Hz), DP 1.4++ and HDMI 2.0b
PXE boot
MAC address path through (MAPT)
WoL (Wake on LAN)
Supporting dedicated FUJITSU devices from 10th gen.
Downwards compatible supporting dedicated FUJITSU devices with Thunderbolt™ 3 and Type-C

Gain instant access to your almost all kind of devices with one Type-C plug supporting Thunderbolt™ 4 for Windows devices
Keep your peripherals plugged-in and charged
Having a clean desk and save space with a single cable connected to your client
  • ImgPlaceholder
    Reliability
    High quality and stability
    Everything you need from one source
  • ImgPlaceholder
    Ease of Use
    On/off button (switching on dedicated FUJITSU devices)
    Full support of Intel® AMT (vPro®)
    USB charging LED
    2x USB Type-C with Thunderbolt™ 4, 2x USB Type-C and 3x USB Type-A interfaces
    DisplayPort 2x (up to 4,096 x 2,160, 60 Hz), DP 1.4++ and HDMI 2.0b
    PXE boot
    MAC address path through (MAPT)
    WoL (Wake on LAN)
    Supporting dedicated FUJITSU devices from 10th gen.
    Downwards compatible supporting dedicated FUJITSU devices with Thunderbolt™ 3 and Type-C
  • ImgPlaceholder
    Usability
    Gain instant access to your almost all kind of devices with one Type-C plug supporting Thunderbolt™ 4 for Windows devices
    Keep your peripherals plugged-in and charged
    Having a clean desk and save space with a single cable connected to your client

Tech Specs

Product Thunderbolt™ 4 Port Replicator
Color Black
DC-in 1 (20V/170W required)
Power on switch 1
USB 3.2 Gen2 (10 Gbps) total 1x Type-A - 5 V/ 2.4 A, 12 W
2x Type-A - 5 V/ 0.9 A, 4.5 W
2x Type-C - 5 V/ 1.5 A, 4.5 W charging port
USB 4.0 Gen3 (20 Gbps) total 1x Type-C - TBT4 up to 60 W (PD v2.0-1.1), 5-20 V/3.0 A upstream (PC)
1x Type-C - TBT4 up to 15 W (PD v2.0-1.1), 5 V/3.0 A downstream, power output to client
DisplayPort 2 (up to 4,096 x 2,160, 60 Hz), DP 1.4++
Possible resolution:
- using 1x DP (5,120 x 2,880, 60 Hz)
- using 2x DP (4,096 x 2,160, 60 Hz or 3,840 x 2,160, 60 Hz)
Ethernet (RJ-45) 1 (10/100/1000)
WoL from S0 to S5 state depending on Fujitsu mobile client
PXE launching depending on Fujitsu mobile client
Intel AMT (vPRO)
User MAC address setting
MAPT from 10th gen
Downwards compatible to Thunderbolt™ 3 and Type-C (the client needs to have a Thunderbolt™ 3 or Type-C interface)
Kensington Lock support 1
Package content Thunderbolt™ 4 Port Replicator
including 170 W 3-pin AC adapter
including TBT4 cable 70 cm
w/o AC cable
Weight 440 g
Dimensions (W x D x H) 239 x 80 x 26 mm
Order information Order information
Acc order code SAP FPCPR401BP
Warranty Terms & Conditions http://www.fujitsu.com/warranty

Read full specs
