FUJITSU Workstation CELSIUS W5010

Keyboard shortcuts for the player:
  • F: Fullscreen
  • Esc: Exit fullscreen
  • ↑: Volume up
  • ↓: Volume down
  • ←: 5 sec. back
  • →: 5 sec. forward
  • Space: Play/Pause
  • S: Subtitle On/Off
If you thought you would need to sacrifice performance, expandability, price or energy efficiency in a microtower design – think again. The FUJITSU CELSIUS W5010 desktop workstation goes far and beyond with its innovative design, featuring maximum graphic performance and dual slot full-length graphics card support. With its best-in-class low-noise emissions, it enables a quiet and efficient working environment.
  • Intel Xeon logo - Workstations (except Mobile WS)

Features & Benefits

Features Benefits
  • Windows 10 Pro for Workstations
  • Windows 10 Pro. Fujitsu recommends Windows 10 Pro for business.
  • Windows 10 Home

  • Easy integration into customers’ existing infrastructure
No compromise in terms of performance, expandability and price
  • Choose between the latest 10th generation Intel® Core™ processors or the powerful Intel® Xeon® W-1200 processors
  • Support of Windows 10 Pro
  • Up to 128 GB DDR4 2,933 MHz memory (incl. ECC)
  • Dual slot full-length graphics cards (up to NVIDIA® Quadro® RTX 5000)
  • Broad choice of processors and professional graphics cards
  • Support of 24/7 operation with reliable high-endurance and business critical drives

  • Designed with CAD customers in mind: performance, reliability and flexibility - at an affordable price
VR-ready desktop workstation
  • 21-liter desktop microtower workstation
  • Powered by the NVIDIA® Quadro® RTX 5000 VR-ready graphics
  • Optimized thermal management and cooling solutions
  • Enjoy a silent workplace environment thanks to low noise emission

  • Innovative space-saving design - made in Europe
The smartest microtower workstation
  • Clean, clutter-free interiors with less cables and cold-plug technology for HDDs inside
  • Tool-less access to components for easy access and upgrade
  • High-speed data transfer with SSD NVMe
  • Supports massive amount of data storage with 4 storage slots

  • Ultimate usability, reliability and ease of use
Multiple application scenarios
  • Supports graphics-accelerated applications
  • Advanced CPUs in combination with flash storage for best application performance
  • Up to 8 monitors with the NVIDIA® Mosaic™ technology

  • Ideal for 3D CAD, CAE, design, multimedia, visualization and manufacturing

Technical details

ProductCELSIUS W5010
Operating systemWindows 10 Pro for Workstations
Windows 10 Pro. Fujitsu recommends Windows 10 Pro for business.
Windows 10 Home
Additional software (preinstalled)Adobe® Reader® (pdf reader)
McAfee® LiveSafe™ (provides award-winning antivirus protection for your PC and much more. 30 days trial pre-installed)
Microsoft Office (1 month trial for new Microsoft® Office 365 customers. Buy Microsoft Office.)
MainboardD3817 (proprietary )
ChipsetIntel® W480
Processor Type, Second Level cache, Processor frequencyIntel® Xeon® processor W-1250P, 4.10 GHz, up to 4.8 GHz
Intel® Xeon® processor W-1250, 3.30 GHz, up to 4.7 GHz
Intel® Xeon® processor W-1270P, 3.80 GHz, up to 5.1 GHz
Intel® Xeon® processor W-1270, 3.40 GHz, up to 5.0 GHz
Intel® Xeon® processor W-1290P, 3.70 GHz, up to 5.2 GHz
Intel® Xeon® processor W-1290, 3.20 GHz, up to 5.1 GHz
Intel® Core™ i9-10900 processor, 20 MB, 2.80 GHz
Intel® Core™ i9-10900K processor, 20 MB, 3.70 GHz
Intel® Core™ i7-10700 processor, 16 MB, 2.90 GHz
Intel® Core™ i7-10700K processor, 16 MB, 3.80 GHz
Intel® Core™ i5-10500 processor, 12 MB, 3.10 GHz
Intel® Core™ i5-10600 processor, 12 MB, 3.30 GHz
Intel® Core™ i3-10100 processor, 6 MB, 3.60 GHz
Processor quantity maximum1
Supported capacity RAM (max.)128 GB, 4 Memory slot(s) DIMM (DDR4) ECC/non-ECC, Dual channel support, For dual channel performance, 2 memory modules have to be ordered. Capacity per channel has to be the same. 2933 MHz may be clocked down to 2400MHz depending on processor and memory configuration
Serial ATA6 x Serial ATA total
Controller functionsSerial ATA III (6 Gbit), NCQ, AHCI, RAID 0/1/5/10
Drives (optional)DVD Super Multi, SATA
DVD Super Multi ultra slim (tray), SATA
BD Triple Writer SATA ultra slim (tray), SATA
MultiCard Reader 15in1 USB 3.0 3.5”, USB 3.0
Drive bays1 x 3.5-inch external bays
2 x 3.5-inch internal bays
2 x 5.25-inch external bays
Slots1 x PCI-Express 3.0 x4 (mech. x16)
1 x PCI-Express 3.0 x16
2 x PCI-Express 3.0 x1
Interfaces1 x Audio: line-in
1 x Audio: line-out
1 x Internal speakers
3 x USB 3.2 Gen 1 (5 Gbps) total
5 and 1 optional x USB 3.2 Gen 2 (10 Gbps) total
4 x USB 2.0 total
2x USB 2.0; 2x USB 3.2 Gen 2; 1x USB 3.2 Gen 2 Type-C (supports up to 15W) x USB front
1x USB 2.0 Type A x USB internal
2x USB 2.0; 2x USB 3.2 Gen 1; 2x USB 3.2 Gen 2; optional: additional 1x USB 3.2 Gen 2 Type-C (supports DisplayPort 1.4 and power delivery (PD) up to 15W or 60W (occupies PCIe x16 slot) x USB rear
2 x DisplayPort
1 (optional) x Parallel (25pin with EPP and ECP)
optional x VGA
1 x Ethernet (RJ-45)
optional (DVI-D) x DVI
1 (optional) x eSATA
2 (optional) x Mouse / Keyboard (PS/2)
GraphicsIntel® UHD Graphics P630, Intel® UHD Graphics 630, Up to half size of total system memory
Graphics featuresSupport for up to three independent displays, DirectX® 12, HDCP support, OpenCL™ 2.1, OpenGL® 4.5, For multi monitoring mode, graphics card and integrated graphics run in parallel, DisplayPort interface supports Ver. 1.4 incl. Multi-Stream, Digital audio formats are supported, including Dolby Digital Plus (7.1 channels), DVI-D interface supports audio output if connected to the HDMI interface of a display via suitable adapter cables (not included), Additional I/O connectors configurable, choice of, DVI-D, HDMI™, VGA, USB Type-C™ (supports DisplayPort™ 1.4 and power delivery (PD) up to 15W), USB Type-C™ (supports DisplayPort™ 1.4 and power delivery (PD) up to 60W. Occupies PCIe x16 slot)
Ultra-high-end 3D: NVIDIA® Quadro® RTX 5000, 16 GB, PCIe x16, 4 x DisplayPort, 1 x Virtual Link
High-end 3D: NVIDIA® Quadro® RTX 4000, 8 GB, PCIe x16, 3 x DisplayPort, 1 x Virtual Link
Midrange 3D: NVIDIA® Quadro® P2200, 5 GB, PCIe x16, 4 x DisplayPort
Midrange 3D: AMD Radeon™ Pro WX 5100, 8 GB, 320 stream processors, PCIe x16, 4 x DisplayPort
Entry 3D: NVIDIA® Quadro® P1000, 4 GB, PCIe x16, 4 x miniDP
Entry 3D: NVIDIA® Quadro® P620, 2 GB, PCIe x16, 4 x miniDP
Entry 3D: NVIDIA® Quadro® P400 , 2 GB, PCIe x16, 3 x miniDP
Entry 3D: AMD Radeon™ Pro WX 3100, 4 GB, 320 stream processors, PCIe x16, 1 x DisplayPort, 2 x miniDP
Entry 3D: AMD Radeon™ Pro WX 2100, 2 GB, 320 stream processors, PCIe x16, 1 x DisplayPort, 2 x miniDP
Others: MiniDP to DP Adapter Cable
Audio codecRealtek ALC623
LAN10/100/1,000 MBit/s Intel® I219LM
Facts WLANoptional; Intel® Wi-Fi 6 AX200 (2x2/160) Gig+ and Bluetooth 5.1 x Integrated WLAN
Weightapprox. 10 kg
approx. 30.86 lbs
Dimensions (W x D x H)180 x 304 x 375 mm
7.09 x 11.97 x 14.76 inch
Warranty period3 years (depending on country)


Keyboard KB955
The KB955 is a very flat keyboard with extra low keys and spill-resistant protection. The elegant design and top-quality construction makes the KB955 the ideal input device for any PC or Notebook user. If you accidently spill some water or coffee onto the keyboard, this special construction helps the liquid to flow away.
Blue LED Mouse M960
The Blue LED Mouse M960 comes in a slim design with proven Fujitsu engineering quality. The track on glass Blue LED sensor enables ultra precise switchable resolution at 1,000, 1,600 and 2,000 dpi. Blue LED Mouse M960 makes your life easier because it’s tailor-made for right handed users. It just feels great in your hand.
SpaceMouse™ Pro
SpaceMouse™ ProUsing the SpaceMouse™ Pro 3D mouse to navigate 3D models or environments is as simple as holding them in your hand. A slight movement of the controller cap delivers easy and precise control. SpaceMouse™ Pro is a companion to the traditional mouse and is operated with the free hand. Your traditional mouse hand is free to select, create and edit.
