Fujitsu Workstation CELSIUS M7010

Fujitsu Workstation CELSIUS M7010

  • Run demanding applications with powerful Intel® Xeon® W processors
  • Up to NVIDIA RTX™ A6000 or AMD Radeon™ Pro WX 3200 grpahics cards
  • Ideal for high-end CAD, M&E, rendering and simulation applications
  • Supports NVIDIA® NVLink™ technology for high-speed GPU interconnect

ImgPlaceholder ImgPlaceholder ImgPlaceholder ImgPlaceholder
Perfomance you can count on
Dual GPU, VR ready workstation
Ultimate reliability, usability and innovative design
Robust security

Spectrum of performance due to a wide range of professional grade features

Enjoy a fully immersive and real-time virtual reality experience with low latency at high frame rates

Quality you can trust

Human centric innovation meets security

  • ImgPlaceholder
    Perfomance you can count on
    Spectrum of performance due to a wide range of professional grade features
  • ImgPlaceholder
    Dual GPU, VR ready workstation
    Enjoy a fully immersive and real-time virtual reality experience with low latency at high frame rates
  • ImgPlaceholder
    Ultimate reliability, usability and innovative design
    Quality you can trust
  • ImgPlaceholder
    Robust security
    Human centric innovation meets security

Product Video

Tech Specs

Product CELSIUS M7010
Chipset Intel® C422
Processor Intel® Xeon® processor W-2223, 3.60 GHz, up to 3.9 GHz
Intel® Xeon® processor W-2225, 4.10 GHz, up to 4.6 GHz
Intel® Xeon® processor W-2235, 3.80 GHz, up to 4.6 GHz
Intel® Xeon® processor W-2245, 3.90 GHz, up to 4.5 GHz
Intel® Xeon® processor W-2255, 3.70 GHz, up to 4.5 GHz
Intel® Xeon® processor W-2265, 3.50 GHz, up to 4.6 GHz
Intel® Xeon® processor W-2275, 3.30 GHz, up to 4.6 GHz
Intel® Xeon® processor W-2295, 3.00 GHz, up to 4.6 GHz
Supported capacity RAM (max.) 512 GB, 8 Memory slot(s) DIMM (DDR4) ECC, 4 memory channels supporting up to 2 DIMMs per channel. For quad channel, a minimum of 4 memory modules have to be ordered and the capacity per channel has to be the same.
DDR4 2,933MHz may be clocked down to 2,666 or 2,400 or 2,133 depending on the processor.
Interfaces 1 x Audio: in (rear)
1 x Audio: out (rear)
1 x Audio: in
1 x Audio: out
1 x Internal speakers
2 optional via front panel x USB 2.0 total
2x USB 2.0; 2x USB 3.1 (Gen1); optional: 2x USB 3.1 Type-C (Gen2) instead of 2x USB 2.0 x USB front
3, thereof 1 type A x USB internal
6 x USB rear
1 x Ethernet (RJ-45)
1 (optional) x eSATA
Graphics features Entry 3D: AMD Radeon™ Pro WX 3200, 4 GB, PCIe x16, 4 x miniDP
Midrange 3D: NVIDIA RTX™ A2000, 6 GB, PCIe x16, 4 x DisplayPort
Ultra-high-end 3D: NVIDIA® Quadro® RTX 6000, 24 GB, PCIe x16, 4 x DisplayPort, 1 x Virtual Link
Ultra-high-end 3D: NVIDIA® Quadro® P6000, 24 GB, PCIe x16, 1 x Dual Link DVI-D, 4 x DisplayPort
Ultra-high-end 3D: NVIDIA® Quadro® RTX 5000, 16 GB, PCIe x16, 4 x DisplayPort, 1 x Virtual Link
High-end 3D: NVIDIA® Quadro® RTX 4000, 8 GB, PCIe x16, 3 x DisplayPort, 1 x Virtual Link
Entry 3D: NVIDIA® T1000, 4 GB, PCIe x16, 4 x miniDP
Entry 3D: NVIDIA® Quadro® P1000, 4 GB, PCIe x16, 4 x miniDP
Entry 3D: NVIDIA® T600, 4 GB, PCIe x16, 4 x miniDP
Entry 3D: NVIDIA® T400, 2 GB, PCIe x16, 3 x miniDP
Remote Graphics: CELSIUS RemoteAccess Dual Card, PCIe x1, 2 x miniDP, PCoIP
Remote Graphics: CELSIUS RemoteAccess Quad Card, PCIe x1, 4 x miniDP, PCoIP
Others: DP to DVI-D (single link) Adapter Cable
Others: MiniDP to DP Adapter Cable
Audio codec Realtek ALC671
Weight approx. 18 kg
approx. 39.67 lbs

Accessories

SpaceMouse Pro

Using the SpaceMouse™ Pro 3D mouse to navigate 3D models or environments is as simple as holding them in your hand. A slight movement of the controller cap delivers easy and precise control. SpaceMouse™ Pro is a companion to the traditional mouse and is operated with the free hand. Your traditional mouse hand is free to select, create and edit.
