Fujitsu Desktop ESPRIMO G9012

Fujitsu Desktop ESPRIMO G9012

  • Windows 11 Pro. Fujitsu recommends Windows 11 Pro for business.
  • High performance in an ultra-compact design
  • Low noise Mini PC
  • Flexible mounting options and wide range of usage scenarios, perfect with AIO Display P2410
  • Perfect fit for modern offices and workplaces of tomorrow

ImgPlaceholder ImgPlaceholder ImgPlaceholder ImgPlaceholder
A smart Mini PC with ultra-compact design
Small in size but grand in performance
Flexibility without limits
Ultimate usability - Perfect fit for modern offices and workplaces

Eye-catching exclusive modern design

High performance in a small Mini PC design

Pleasant working environment due to quiet system

Flexible mounting options and wide range of usage scenarios

  • ImgPlaceholder
    A smart Mini PC with ultra-compact design
    Eye-catching exclusive modern design
  • ImgPlaceholder
    Small in size but grand in performance
    High performance in a small Mini PC design
  • ImgPlaceholder
    Flexibility without limits
    Pleasant working environment due to quiet system
  • ImgPlaceholder
    Ultimate usability - Perfect fit for modern offices and workplaces
    Flexible mounting options and wide range of usage scenarios

Tech Specs

Product ESPRIMO G9012
Operating system Windows 11 Pro. Fujitsu recommends Windows 11 Pro for business.
Windows 11 Home
Windows 10 Pro. Fujitsu recommends Windows 11 Pro for business.
Mainboard D4014-A (base system) resp. D4015-A (Thunderbolt 4 version; available Dec 2022, proprietary )
Chipset Intel® Q670
Processor Intel® Core™ i9-12900 processor, 30 MB, 2.4 GHz
Intel® Core™ i7-12700T processor, 20 MB, 1.4 GHz
Intel® Core™ i7-12700 processor, 25 MB, 2.1 GHz
Intel® Core™ i5-12400T processor, 12 MB, 1.8 GHz
Intel® Core™ i5-12400 processor, 18 MB, 2.5 GHz
Intel® Core™ i5-12500T processor, 12 MB, 2.0 GHz
Intel® Core™ i5-12500 processor, 18 MB, 3.0 GHz
Intel® Core™ i3-12100 processor, 12 MB, 3.3 GHz
Supported capacity RAM (max.) 64 GB, 2 Memory slot(s) DIMM (DDR4), Dual channel support, For dual channel performance, 2 memory modules have to be ordered. Capacity per channel has to be the same. 3200 MHz may be clocked down to 2933/2400MHz depending on processor and memory configuration
Serial ATA total 2
thereof SATA III Serial ATA III (6 Gbit), NCQ, AHCI, RAID 1/0
Drives (optional) DVD Super Multi ultra slim (tray), SATA
BD Triple Writer SATA ultra slim (tray), SATA
Drive bay x 3.5-inch external bay
x 3.5-inch internal bay
1 x 5.25-inch external bay
Slots 1 x PCI-Express 3.0 x4 (mech. x16)
Interfaces 1x USB 3.2 Gen 1 (5 Gbps) Type-A
1x USB 3.2 Gen 2 (10 Gbps) Type-A
1x USB 3.2 Gen 2x2 (20 Gbps) Type-C (provides up to 15W) x USB front
Base system:
1x USB 2.0 Type-A
3x USB 3.2 Gen 2 (10 Gbps) Type-A
1x USB 3.2 Gen 2 Type-C (10 Gbps, supports DisplayPort 1.4 and power delivery sink**)
Thunderbolt version:
5x USB 3.2 Gen 2 (10 Gbps) Type-A
1x Type-C Intel® Thunderbolt™ (40 Gbps, supports DisplayPort 1.4 and power delivery sink**)
see flexible interface options x USB rear
1 x Ethernet (RJ-45)
1 x Kensington Lock support
1 (DisplayPort 1.4) x DisplayPort
1 x HDMI
Graphics Intel® UHD Graphics 770, Intel® UHD Graphics 730, Intel® UHD Graphics 710, Up to half size of total system memory
Audio type Realtek ALC257N
Communication 10/100/1,000 MBit/s Intel® I219LM
optional Integrated WLAN
Weight Small
Min:0.86kg; 1x mem,1xSDD
Max:1.025kg; 2x mem,2xSSD,HDD,Flexi,WLAN
ODD vers.: Min:1.2kg/Max:1.29kg
int. PSU vers.: Min:1.45kg/Max:1.59kg
AC adapt.(0.32kg), power cord(0.175kg) not part of min/max
Dimensions (W x D x H) 146.5 x 164.5 x 36 mm
5.77 x 6.48 x 1.42 inch
Power efficiency note 90 Watt AC adapter: power supply efficiency at 115/230 V: 89% average efficiency
150 Watt internal PLATINUM power supply (optional):
Power supply efficiency in % at 10% / 20% / 50% / 100% load
for 230 V ; 90/93/94/94
for 115 V ; 90/91/93/92
90 Watt AC adapter: power supply efficiency at 115/230V: 89% average efficiency
150 Watt internal PLATINUM power supply (optional):
Power supply efficiency in % at 10% / 20% / 50% / 100% load
for 230V ; 90/93/94/94
for 115V ; 90/91/93/92
Warranty period 3 years
Operating system notes Bring-In / Onsite Service (depending on country)
Windows 11 requires for first device setup:
- Internet connectivity
- Microsoft account for Home editions or organizational account (e.g. ADD) for Pro editions
After product end of life, Fujitsu continues to test and support new Windows releases for max. 5 years, depending on extension of hardware services through warranty top ups.
For more details please visit our Fujitsu Service Statement under https://support.ts.fujitsu.com/IndexProdSupport.asp?lng=com&OpenTab=
The use of Windows Operating System is subject to acceptance of the End User License Agreement of Microsoft as applicable under the relevant Microsoft program.
1 x 2.5-inch internal bay
x 5.25-inch internal bay
Operating system notes Bring-In / Onsite Service (depending on country)
Windows 11 requires for first device setup:
- Internet connectivity
- Microsoft account for Home editions or organizational account (e.g. ADD) for Pro editions
After product end of life, Fujitsu continues to test and support new Windows releases for max. 5 years, depending on extension of hardware services through warranty top ups.
For more details please visit our Fujitsu Service Statement under https://support.ts.fujitsu.com/IndexProdSupport.asp?lng=com&OpenTab=
The use of Windows Operating System is subject to acceptance of the End User License Agreement of Microsoft as applicable under the relevant Microsoft program.
1 x 2.5-inch internal bay
x 5.25-inch internal bay

Accessories

Fujitsu AIO Display P2410

The Fujitsu AIO Display P2410 is the universal display unit for Mini PCs like ESPRIMO Gx012 Small and FUTRO S7011 to be connected via USB Type-C to enables All-in-One like usage. It comes with front and side USB connectors for ergonomic comfort and optional side optical drive for wide range of usage.

Mounting Kit for Height Adjustable Fujitsu Displays
- up to 11th Gen. Display (2022)

The Fujitsu Mounting Kit for Height Adjustable Fujitsu Displays has been specifically (2022) designed for use with ESPRIMO Q/G Mini PCs, FUTRO Thin Clients and Fujitsu Displays. With this solution you can save space on the desk, reduce clutter on desk and realize a clean desk working environment.

Mounting Kit for Height Adjustable Fujitsu Displays
- up to 10th Gen. Display

The Fujitsu Mounting Kit for Height Adjustable Fujitsu Displays has been specifically designed for use with ESPRIMO Q/G Mini PCs, FUTRO Thin Clients and Fujitsu Displays. With this solution you can save space on the desk, reduce clutter on desk and realize a clean desk working environment.

Universal Monitor Stand

Save desk space without compromising productivity with the Universal Monitor Stand that brings together a Desktop ESPRIMO Mini PC (G Series Small and ODD plus Q Series) or Thin Client FUTRO and a VESA compatible Fujitsu Display. For optimum ergonomics the height and tilt angle of the display can be adjusted, whilst hassle-free installation of the devices on the stand makes the life of your IT department easier.
