FUJITSU Server PRIMERGY RX4770 M6

Keyboard shortcuts for the player:
  • F: Fullscreen
  • Esc: Exit fullscreen
  • ↑: Volume up
  • ↓: Volume down
  • ←: 5 sec. back
  • →: 5 sec. forward
  • Space: Play/Pause
  • S: Subtitle On/Off
The FUJITSU Server PRIMERGY RX4770 M6 server provides powerful, four-socket performance featuring the 3rd Generation Intel® Xeon® Scalable Processors in a new 3U form factor. The system enables to address large data sets with up to 48 DIMMs (24 of which can be non-volatile memory) and up to 18 TB of memory. Beside the enhanced DDR4 modules, it is also possible to combine them with new Intel® Optane™ persistent memory 200 series that provide fast, high capacity and cost effective memory for memory intensive workloads such as data analytics and in-memory databases. Moreover, the server enables to scale capacity and performance with up to 24x 2.5” SAS/SATA/NVMe storage drives, up to two double width, full-length GPU cards, choice of DynamicLoM adapters via OCP V3 as well as 11 PCI-Express Gen3 slots.

Features & Benefits

Features Benefits
POWER YOUR BUSINESS-CRITICAL WORKLOADS
  • Wide choice of different available types of 3rd Generation Intel® Xeon® Scalable processors. Each processor offers up to 28 cores, 12 memory channels, up to 6 Intel® Ultra Path Interconnect (Intel® UPI) and PCI Express 3 with up to 48 lanes (per socket) enabling a significantly higher performance and efficiency.

  • PRIMERGY RX4770 M6 server provides 4 processor computing in a 3U form factor, accelerates business insights and delivers maximum performance per node with highest memory bandwidth and IO lanes for your most demanding applications. Moreover, a flexible processor tray allows to start with two CPU’s and scale to four processors in the future saving on upfront costs.
SCALABLE APPLICATION PERFORMANCE
  • New Intel® Optane™ persistent memory 200 series improves workload performance and power efficiency while reducing data loss and downtime with enhanced error handling. The modules revolutionizes the data center memory-storage hierarchy of the past and bring massive data sets closer to the CPU for faster time to insight. In total, up to 18 TB GB main memory in a mixed mode (non-volatile memory + DDR4 @ 3,200 MT/s) are available.

  • Address large data sets with up to 48 DIMMs (24 of which can be Intel® Optane™ PMem) and up to 18 TB of memory. Intel® Optane™ persistent memory provide fast, high capacity and cost effective memory for memory intensive workloads such as AI and data analytics.
FLEXIBLE EXPANDABILITY AND RELIABILITY
  • PRIMERGY RX4770 M6 comes with DynamicLoM via OCP V3 as well as flexible PCIe riser cards with support for up to 11 x PCIe Gen3 slots. Different available base units with 8x 2.5-inch, 16x 2.5-inch or up to 24x 2.5-inch storage drive bays provide massive expandability. In addition, it is possible to equip the system with up to 2 double width full length GPU cards. Built-in redundancy and hot-pluggable components, Advanced ECC, Memory Scrubbing and SDDC ensure reliable and fail-safe operation.

  • The flexible drive cage design supports up to 24x 2.5” SAS/SATA/NVMe storage drives. Sufficient expandability for future requirements is guaranteed by PCIe 3.0 expansion slots for graphical processing units (GPUs) and all kinds of networking cards offering increased I/O bandwidth and to be able to cope with graphic-intensive applications. Choice of DynamicLoM adapters offers range of networking bandwidth (1GbE to 25GbE) to be able to adapt and grow to changing business needs.
AGILE INFRASTRUCTURE MANAGEMENT
  • Infrastructure Manager (ISM) provides seamless, holistic management ensuring that IT infrastructures retain the dynamic flexibility required to support ever-changing business demands. Two versions of ISM are available. ISM Advanced is a powerful, fully featured version offering comprehensive infrastructure management capabilities such as support for multiple hardware configurations, physical and virtual network connection indicators and firmware baseline updates. A free entry-level version, ISM Essential, provides essential monitoring and firmware update of all supported devices, including servers, storage and network switches.

  • Infrastructure Manager (ISM) enables organizations to have centralized control over the entire data center that includes servers, storage, networking, cloud management software as well as power and cooling using a single user interface.
SECURE AND RELIABLE
  • PRIMERGY servers are equipped with beneficial features to protect against, detect and recover from security breaches (UEFI Secure Boot, TPM 2.0, signed firmware updates, agent-free device management, secure authorization and authentication, alerting and logging, secure Out of Band Management with iRMC S5, …).

  • PRIMERGY servers come with a wide variety of robust security features to protect, detect and recover from cyber-attacks and combine these capabilities with the best quality and efficiency, and more agility in daily operations helps to turn IT into a business advantage faster.

Technical details

ChipsetIntel® C621A
Mainboard typeD3892
Product TypeQuad Socket Rack Server
ProcessorIntel® Xeon® Gold 53xxH processors, Intel® Xeon® Gold 63xxH processors, Intel® Xeon® Platinum 83xxH processors
Memory16 GB - 18 TB, DIMM (DDR4 RDIMM, LRDIMM and Intel® Optane™ PMem)
Memory protectionECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
PCI-Express 3.0 x1611 x whereas 4x full height and 7x low profile
Slot NotesImportant note: 7 PCIe slots are supported with the first and second processor. Additional 4 PCIe slots are supported with the third and forth processors.
Slot 1&2: PCIe Gen3 x16 @CPU4 for full height profile cards
Slot 3&4: PCIe Gen3 x8/Slot 5: PCIe Gen3 x16 @CPU1 for low profile cards
Slot 6&7&8&9: PCIe Gen3 x16 @CPU2 for low profile cards
Slot 10&11: PCIe Gen3 x16 @CPU3 for full height cards
Optional accessible drives1 x 5.25/9.5mm for DVD-RW/Blu-ray
All possible options described in relevant system configurator.
Storage drive bays2.5-inch hot-plug SAS/SATA/PCIe
2 x M.2 slots
I/O controller onboardIntel® C621A, 1x SATA channel for ODD, 2x SATA channel for M.2 and 8x SATA channel for HDD/SSD
All hardware storage controller options are described under Components
Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP+
Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller), IPMI 2.0 compatible
Trusted Platform Module (TPM)Infineon / TPM 2.0 module; TCG compliant (option)
Power supply configuration2 hot-plug power supplies (standard)
Active power (max. configuration)0 W
Weightmax. 40 kg
Rack (W x D x H)435 x 800 x 129.4 mm
Mounting Depth RackTBD mm
Server ManagementInfrastructure and Server Management
DC Infrastructure ManagementInfrastructure Manager (ISM)
Essential
Advanced
Infrastructure Manager (ISM)
Essential
Advanced, ServerView Suite
Warranty period3 years
Warranty typeOnsite warranty
Service Lifecycle5 years after end of product life
