LIFEBOOK E734

LIFEBOOK E734 - Great Usability in a Small Body

The Fujitsu LIFEBOOK E734 gives you the right balance of portability and functionality for mobile or office-based computing. With a bright 33.8cm (13.3-inch) display, it is lightweight at only 1.69 kg. Packed with premium features and a small form factor, it provides you ultimate ease of use.

Core2Duo
  • Extreme Durability - The LIFEBOOK E Series is made with excellent materials that guarantee maximum durability*, such as the thin and solid magnesium lid and strong hinges. Having undergone rigorous tests like the Qfinity standard tests and MIL-STD-810G test , it is perfect for businessmen who frequently travel or those in industries that demand work outdoors.
  • Enhanced Productivity – The LIFEBOOK E Series is loaded with the latest Intel® technology to ensure high performance and mobile productivity.
  • Family Concept – Besides sharing a uniform design, the LIFEBOOK E Series offers the same accessories like the modular bay elements and port replicator, thus allowing sharing of accessories between multiple users in the workplace.

Detailed Specs

Operating System
Operating System Windows 8 Pro 64-bit
Windows 8 64-bit
Windows 7 Professional 32/64-bit
Specifications
Chipset Intel QM87 Express Chipset
Processor1 Dual Cores
Intel® Core™ i3-4000M Processor(3M Cache, 2.40 GHz)
Intel® Core™ i5-4200M Processor(3M Cache, up to 3.10 GHz)
Intel® Core™ i5-4300M Processor(3M Cache, up to 3.30 GHz)
Intel® Core™ i7-4600M Processor(4M Cache, up to 3.60 GHz)
Quad Cores
Intel® Core™ i7-4702MQ Processor(6M Cache, up to 3.20 GHz)
Supported capacity RAM (max.) 16GB, 2 Memory slots, DDR3 1600MHz DIMM
Hard disk drive SATA, 5400 rpm, 320GB/500GB/1TB, 2.5-inch
SSHD, 5400 rpm, 320GB/500GB, 8GB SSD Cache, 2.5-inch
SSD SATA III, 128GB/256GB/512GB, 2.5-inch
SSD SATA III FDE, 256GB, 2.5-inch
SATA, 7200rpm, 500GB, 2.5-inch
Display 13.3" HD LED Backlit, Anti-glare display, 1366 x 768 pixels, 200 cd/m2
Graphics
Graphics brand name Intel® HD Graphics 4600
Graphic notes Shared memory depending on main memory size and operating system
Connectivity
Antennas 2 Dual band WLAN antennas, 2 UMTS/LTE antennas optional
WLAN (optional) Intel Wireless-N 7260 (a/b/g/n) with Bluetooth
Intel Wireless-N 7260 (b/g/n) with Bluetooth
3G/4G (Optional)2,3 3G/UMTS: Sierra Wireless EM8805
4G/LTE: Sierra Wireless EM7305
LAN4 Built-in 10/100/1000 MBit/s (Intel 1217LM, w/ AMT)
Modular bay options Bay Projector, Bay Battery, Blu-ray writable drive, DVD SuperMulti, 2nd HDD Kit (w/o SATA HDD), Weight Saver
Multimedia
Audio codec Realtek ALC3233
Audio features High Definition Audio with with DTS Boosts, stereo speakers
Camera Optional: Built-in Full HD webcam w/LED, Support Microsoft® Lync™
Interfaces
Memory card slots 1 (SD up to 2GB, SDHC up to 32GB, SDXC up to 64GB)
SIM card slot (only with 3G/4G) 1
SmartCard slot (Optional) 1
USB 3.0 total 3
USB 2.0 total 0
Anytime USB Charge Yes, Share with 1x USB 3.0
VGA 1
DisplayPort 1
HDMI 0
Ethernet (RJ-45) 1
DC-in 1
Audio: line-in / microphone 1
Audio: line-out / headphone 1
Internal microphones Integrated dual-microphones array
Docking connector for Port Replicator Yes
Kensington Lock Support Yes
Keyboard 84 Keys Isolation
Optional: Backlit Keyboard (Backlit keyboard does not support Spill Resistant)
Pointing Devices Synaptics Click Pad™ (Multi-touch)
User Interface Status LED
Power/Standby Button
ECO Button
Wireless Button (w/ Status LED)
Power Supply
AC Adapter 19 V/65 W (5.26 A), 100 V - 240 V (AC Input), 50 Hz - 60 Hz, 3-pin (grounded) Stick Type AC Adaptor
19 V/80 W (4.22 A), 100 V - 240 V (AC Input), 50 Hz - 60 Hz, 3-pin (grounded) 0-Watt AC Adaptor technology1
1st battery options Li-Ion battery 6-cell, 63Wh
Li-Ion battery 6-cell, 72Wh
2nd battery (optional) Li-ion Bay Battery 6-cell, 28Wh
Runtime 1st battery6 15 hrs 20 mins
Runtime 1st + 2nd battery6 21 hrs
Battery notes Battery runtime information is based on worldwide acknowledged BAPCO® Mobile Mark 2007 Benchmark (e.g. surfi ng the internet, writing E-mails, viewing documents) which provides results that enable direct product comparisons between manufacturers. It does not guarantee any specifi c battery runtime which actually can be lower and may vary depending on product model, confi guration, application and power management settings. The battery capacity slightly decreases with every charging cycle and over the lifetime.
Dimensions / Weight / Environmental
Dimensions (W x D x H) 321 x 228 x 20.6-26.9 mm
Weight 1.69 kg
Weight notes Including weight saver and 6 cells battery, weight will vary by configuration
Additional Software
Additional Software (preinstalled) - vary by configuration7 Windows 8: CyberLink PowerDirector, CyberLink PowerDVD, Fujitsu Anytime USB Charge Utility, Fujitsu Battery Utility, Fujitsu Bonus Apps, Fujitsu Display Manager, Fujitsu LIFEBOOK Application Panel, Fujitsu Mobility Center Extension Utility, Fujitsu Pointing Device Utility, Fujitsu Power Saving Utility, Fujitsu Shock Sensor Utility, Fujitsu Software AutoInstaller, Fujitsu System Restore and Recovery, Microsoft® Office 2013 60 days Trial, Microsoft® OneNote, McAfee Multi Access 60 days Trial, [TBC] Roxio® Creator LJ, Sierra Wireless AirCard Watcher, Softex OmniPass, TPM Utility

Windows 7: Adobe® Reader®, CyberLink PowerDirector, CyberLink PowerDVD, Fujitsu Anytime USB Charge Utility, Fujitsu Battery Utility, Fujitsu Bonus Apps, Fujitsu Display Manager, Fujitsu Hotkey Utility, Fujitsu LIFEBOOK Application Panel, Fujitsu Mobility Center Extension Utility, Fujitsu Power Saving Utility, Fujitsu Shock Sensor Utility, Fujitsu Software AutoInstaller, Fujitsu System Restore and Recovery, Microsoft® Office 2013 60 days Trial, McAfee Multi Access 60 days Trial, [TBC] Roxio® Creator LJ, Sierra Wireless AirCard Watcher, Softex OmniPass, TPM Utility
Security
System protection Kensington Lock support
Audit proof protection Optional: Trusted Platform Module (TPM1.2)
Access protection8 Hard disk password
User and supervisor BIOS pa ssword
RF Fingerprint Sensor
Anti-theft Lock Slot
Environmental & Compliance
Europe CE, CB
Global9 RoHS II (Restriction of hazardous substances)
EMC (EN55022/EN5524/EN301489)
Microsoft Operating Systems (HCT / HCL entry / WHQL)
WiFi certified
ENERGY STAR® 6.0
EPEAT® Gold (dedicated regions)
China CCC
Taiwan BSMI
Warranty
Standard warranty 1 year
LIFEBOOK Shield: For more details, please visit http://hk.fujitsu.com/pc/contact
Service level Bring-in service, parts & labour
Recommended service 3 years on-site, next business day, parts and labour

The above information shows the general technical specifications of the product and does not represent actual configuration. For specific configurations and their availability, please check with your local distributors.



Disclaimer

1 Clock speed and performance will vary depending on workload and other variables. See  http://www.intel.com/go/turboOpen a new window.

2 4G configuration availability varies from countries. Please check with actual bundling of local distributor. 4G module comes with a 1 year local carry-in warranty.

3 Subjected to network and SIM capabilities. Data rates refer to download or upload speed which is also dependent on network capabilities and conditions.

4 This term does not represent actual data rate of 1000/100/10Mbps and simply indicates compliance with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab standards. Actual maximum data rate depends on network configurations, cable conditions as well as connected devices.

5.Please check actual bundling with country local distributor.

6 Results obtained from BAPCo MobileMark 2007 (Productivity Workload) performed on systems with maximum battery life settings under laboratory testing environment. Actual battery life will vary based on screen brightness, sound volume settings, running applications, connected peripherals, power management settings, battery conditioning, and other customer preferences in the real life situation. Built-in bay device or hard drive usage may also have a significant impact on battery life. Note: Battery life are based on Intel® Core™ i5-3340M, 4GB RAM and 500GB Hard Disk.

7 Subjected to network and SIM capabilities. Data rates refer to download or upload speed which is also dependent on network capabilities and conditions.

8 BIOS Lock needs a supervisor/user password to access BIOS setup. BIOS settings can be configured to prompt for password at every first bootup or all bootup sequences. Full security unlock sequence - Bootup Lock (BIOS Lock), Fingerprint Windows Logo. It is the customer's responsibility to ensure the safekeeping of password for data retrieval.

9 RoHS (Restriction on Hazardous Substances) compliance means the system and its internal components comply with the EU RoHS directive (2002/95/EC) on the restricted use of six hazardous substances in the production of the system and its internal components.
logo-spec-e733a

Features and Benefits

e753_features_yt_02

The LIFEBOOK E Series is made with excellent materials that guarantee maximum durability*, such as the thin and solid magnesium lid and strong hinges. Having undergone rigorous tests like the Qfinity standard tests and MIL-STD-810G test , it is perfect for businessmen who frequently travel or those in industries that demand work outdoors.

e733_features_04

Share compatible features and accessories between laptops. Besides a uniform design, the LIFEBOOK E Series offers the same accessory components, such as the common BIOS, components and accessories like the AC Adapter, modular bay elements and port replicator. This allows sharing of the same accessories between many users in the workplace and eliminates the need to buy multiple sets. For greater flexibility and cost efficiency.

e743_features_05a

Fully equipped for longer work stamina. From long battery life, to anytime USB charging even when turned off, to an optional 0-watt AC adaptor that does not consume power when switched off, you can be sure you will always have power when you need it. Also with ShockSensor to protect your hard drive and minimise loss of data, the LIFEBOOK E Series truly promises uninterrupted computing.

e743_features_06

Exceptional protection for important data. The LIFEBOOK E Series secures your company data against unauthorised third-party access with various software applications: Advanced Theft Protection (Intel® Anti Theft), optional TPM module and optional fingerprint sensor including Omnipass Security Software. With the Fujitsu Shield program, every machine is also protected against any accidental damage.

e743_features_07a

The latest high performance software for greater productivity. The LIFEBOOK E Series is loaded with the latest Intel® technology to ensure high performance and mobile productivity – up to 4th Generation Intel® Core™ i7 processors, Mobile Intel® QM87 chipset (vPro supported), so you can finish more tasks efficiently and with ease.

*HDD purchased separately.


Accessories

e733-acc-img_01_01 Slim Port Replicator
Enjoy more flexibility even with a slim body. Suitable for 13"/14"/15".
e733-acc-img_01_03 6-Cell Bay Battery
For expanding operating hours.
e733-acc-img_01_04 Mobile Bay Projector
For projecting presentation slides/video on the go.
e733-acc-img_01_05 Adjustable Notebook Stand
For an ergonomic and space-saving position.

e733-acc-img_01_06a 2nd HDD Kit*
For expanding storage anytime.
e733-acc-img_01_07 Display B24T-6 LED proGREEN
24" widescreen display for enhanced ergonomics and usability with 4-in-1 stand.
3-pin Stick Type AC Adapter#
For lightweight and easy travel.
e733-acc-img_01_09 Privacy Filter
For 13.3", 14" and 15.6" screens.
e733-acc-img_01_10 Display Port to DVI
For easy connection external display.
e743-acc-img_01_11 Fujitsu MicroSaver Notebook Lock
Patented T-bar locking mechanism along with an advanced carbon-tempered steel cable design for excellent security.

*HDD purchased separately.
