Servers for the data-driven world

PRIMERGY Servers

In today's rapidly evolving business landscape, IT plays an increasingly important role in enabling organizations to stay competitive and meet their customers' demands. To keep up with the latest IT trends, companies need to have the right infrastructure in place, including servers that can handle a wide range of workloads and business demands.

Fujitsu PRIMERGY Server systems are an ideal solution for this purpose, delivering workload-optimized x86 industry standard servers that can meet the needs of any business. Recognizing that there is no one-size-fits-all solution, Fujitsu offers a comprehensive server portfolio that includes expandable tower servers, versatile rack-mount servers, density-optimized multi-node servers, and GPU servers purpose-built for AI and VDI.

All of these systems are designed to handle multiple and computing-intensive workloads, but each server is optimized for specific use cases. Whether you are a large enterprise with multiple sites or a small or medium-sized company with limited space and budget, Fujitsu PRIMERGY Servers can help your IT become the business enabler you have always wanted it to be. With the right choice of server, you can ensure that your infrastructure is up to date with the latest IT trends and equipped to handle whatever demands the future may bring.


Quality

Designed to deliver high-quality performance and reliability.


Efficiency

Operate with high energy efficiency, reducing power consumption and costs.


Agility

Flexible and scalable solutions for changing business needs.


Integration

Seamless integration with existing IT infrastructures and applications.

Find the right server

18  Products

Filters

(0)

Form Factor

Height Units

Processor Quantity

Processor Type

Memory Slots

Memory Capacity

max. Storage Drive Bays

PCIe slots

Fujitsu PRIMERGY RX1330 M6

  • Mono-socket x86 server providing an ideal mix of performance and cost in a compact 1U space
  • Ideal foundation for many SMBs across industries and for a wide range of workloads such as file/print applications, web hosting, communication, collaboration, and virtualization
  • Cost-efficient performance based on Intel® Xeon® E-2400 processors either with 4-, 6-, or 8-cores
  • Address data sets with up to 4x DDR5 DIMMs (in total up to 128GB memory)

Read More

Fujitsu Server PRIMERGY RX1330 M5

  • Mono-socket x86 server providing an ideal mix of performance and cost in a compact 1U space
  • Ideal foundation for many SMBs across industries and for a wide range of workloads such as file/print applications, web hosting, communication, collaboration, and virtualization
  • Cost-efficient performance based on Intel® Xeon® E-2300 processors either with 4-, 6-, or 8-cores
  • Address data sets with up to 4x DDR4 DIMMs (in total up to 128GB memory)

Read More

Fujitsu PRIMERGY RX2530 M7

  • Dual-socket x86 server providing an ideal mix of performance and cost in a dense 1U chassis
  • Ideal for virtualization, scale-out scenarios, databases as well as HPC infrastructures
  • Boost performance with 4th or 5th generation Intel® Xeon® Scalable Processors (up to 60 / 64 cores / CPU)
  • Maximize performance with 32 DIMM modules (up to 8TB DDR5 @4,800 or 5,600 MT/s)
  • Gain storage flexibility with up to 4x 3.5” or up to 10x 2.5” storage devices

Read More

Fujitsu PRIMERGY RX2540 M7

  • Dual-socket x86 server that delivers new levels in performance in an optimized 2U chassis
  • Ideal for collaboration, AI applications, business processing, graphics rendering or in-memory databases
  • Boost performance with 4th or 5th generation Intel® Xeon® Scalable Processors (up to 128 cores/system)
  • Fastest DDR5 memory enables new levels of in-memory performance with up to 4800 / 5600 MT/s
  • Scale to meet demands with up to 12x 3.5” or up to 24x 2.5” storage devices

Read More

Fujitsu PRIMERGY RX1440 M2

  • Mono-socket x86 server (1U) powered by AMD EPYC™ 9004 series processor
  • Scale from 16 to 128 cores (32 to 256 threads) per socket, up to 1152 MB L3 Cache or highest frequencies
  • Ideal for AI machine learning, virtualized environments, as dense enterprise server and data-intensive workloads
  • Drive memory intensive and emerging workloads with 24 DDR5 DIMM slots (up to 6 TB memory)
  • Scale to meet demands with up to 10x 2.5” storage devices, upgrade kit +3x or 2x 2.5-inch rear bays, M.2 drives for booting, up to 3x NVIDIA GPU cards and up to 3x PCIe 5.0 expansion slots

Read More

Fujitsu PRIMERGY RX2450 M2

  • Dual-socket x86 server (2U) powered by AMD EPYC™ 9004 series processors
  • Scale from 16 to 128 cores (32 to 256 threads) per socket, or up to 1152 MB L3 Cache or highest frequencies
  • Ideal for virtualized environments, and Gen AI, LLM deep learning and analytics high performance server for data-intensive workloads
  • Drive traditional and emerging workloads with 24 DIMM slots (up to 6 TB DDR5 memory)
  • Scale to meet demands with up to 24x (+6) 2.5” storage devices, M.2 drives for booting, NVIDIA GPU cards and up to 6/8x PCIe 5.0 expansion slots

Read More

Fujitsu PRIMERGY RX4770 M7

  • Quad-socket x86 system providing superior levels of scalability in a 3U chassis
  • Ideal for business-critical workloads, large-scale virtualization and in-memory databases
  • Boost performance with 4th Generation Intel® Xeon® Scalable Processors (up to 60 cores / CPU)
  • Address large data sets with up to 48 DIMMs with DDR5 DIMM with up to 4800 MT/s
  • Scale capacity with 24x 2.5” storage drives, 11x PCIe 5.0 slots and support for 2x GPU cards

Read More

Fujitsu PRIMERGY RX8770 M7

  • The perfect reliable High-end server especially for in-memory databases and diverse SAP applications like SAP S/4HANA
  • Octo socket processing performance of the 4th generation Intel Xeon Platinum processor level 84xxH (up to a total of 480 cores)
  • In-memory datahase applications are powered by 32 TB fastest DDR5 memory in 128 DIMM slots
  • 12 or optionally 24 PCIe 5.0 slots enable tailored configurations to nearly any demand
  • Up to 24x 2.5-inch SATA/SAS/PCIe SSD storage devices support certain application scenarios to the max

Read More

Fujitsu PRIMERGY TX1310 M5

  • Supports Intel® Xeon® E3-2300 product family processors plus up to 128GB DDR4 RAM
  • Right sized performance with the latest technology for essential workloads
  • Cost-effective configurations – perfect as a "first server" for Small and Medium Enterprises, volume deployments
  • 24/7 server class reliability and versatile features at the best price
  • Silent, compact, and easy to service – ideal for small and branch offices

Read More

Fujitsu PRIMERGY TX1320 M5

  • Supports the latest Intel® Xeon® E-2300 processor family plus up to 128GB DDR4 RAM at 3,200 MT/s
  • Designed for standard small & medium business workloads: infrastructure (file, print, web), collaborative (email), or industry applications
  • Ultra-compact, silent design with dust protection – fits anywhere and ideal for offices or showrooms or industrial environments
  • Full-fledged server for your business needs – up to 8x storage devices, 4x PCIe 4.0/3.0 slots and a range of controllers, OS, device options

Read More

Fujitsu PRIMERGY TX1320 M6

  • Optimal performance for various computing tasks with Intel® Xeon® E-2400 processor
  • Designed for standard small & medium business workloads: infrastructure (file, print, web), collaborative (email), or industry applications
  • Featuring up to 128GB DDR5 main memory with faster DDR5 memory speeds of up to 4800 MT/s, the TX1320 M6 ensures seamless multitasking and enhanced performance
  • Supporting up to 8x 2.5-inch SSD/HDD and 4x PCIe (Gen5/4, 2x Gen5), this server accommodates varying storage needs, providing ample space for data-intensive applications
  • Unmatched adaptability, serving as an ultra-compact mono-socket server suitable for diverse deployment scenarios

Read More

Fujitsu Fujitsu PRIMERGY TX1330 M5

  • Fields the latest Intel® Xeon® E-2300 processor family plus 3,200 MT/s, up to 128GB, DDR4 RAM
  • Ideal for standard small & medium business workloads (infrastructure, collaborative, industry apps) plus storage demanding deployments
  • High capacity, secure storage – up to 24x storage devices with a range of configurations
  • Future ready - 4x PCIe Gen 4/3 slots, a range of advanced options, OS choices and a rack upgrade kit

Read More

Fujitsu PRIMERGY TX1330 M6

  • Powerful processing with Intel® Xeon® E-2400 processor, delivering exceptional performance for demanding workloads
  • Expandable memory with support for up to 128GB DDR5 memory, users can seamlessly multitask and handle data-intensive applications with ease
  • The server accommodates up to 24 2.5-inch hot-plug storage devices, ensuring ample space for data storage and backup
  • Future ready - 4x PCIe 5.0/4.0 (2x 5.0) slots, a range of advanced options, OS choices and a rack upgrade kit
  • Advanced management features with iRMC S6 and the Fujitsu Infrastructure Management Suite, users benefit from efficient remote server management and centralized infrastructure oversight

Read More

Fujitsu PRIMERGY TX2550 M7

  • Small powerhouse for unprecedented business applications, processes and virtualized workloads
  • Up to 2x CPUs of the 4th Generation Intel® Xeon® Scalable processors with 32 cores
  • 16x high speed DDR5 DIMM slots with up to 8TB and 4.800 MT/s
  • Up to 32x 2,5’’ SAS/SATA/NVME storage devices with Fujitsu hot-plug frames
  • Room for up to 4 full height double width GPUs for AI/VID driven business workloads

Read More

Fujitsu PRIMERGY GX2560 M7

  • Advanced NVIDIA GPU-accelerated dual-socket x86 server in a 4U chassis
  • Ideal for high-grade generative AI, Data-Science and HPC workloads
  • High-performance with 4x NVIDIA HGX H100 GPU acceleration, 4th Generation Intel® Xeon® Scalable processors, 2TB DDR5 memory
  • Flexible by design with up to 6x storage devices (4x NVMe), 10x PCIe 5.0 expansion slots with a range of upgrade options
  • Get comprehensive BMC support, including the latest security features, API integration, PFR, and TLS1.3 compatibility

Read More

Fujitsu PRIMERGY CX400 M7

  • Ideal for virtualization, high performance and technical computing as well as cloud computing
  • Powered by 4th Generation Intel® Xeon® Scalable processors
  • Enough space for your business needs with up to 24x 2,5’’ SAS/SATA/NVME storage devices
  • Allows nodes and components to share power, cooling, and management

Read More

Fujitsu PRIMERGY CX2550 M7

  • Ideal for high performance and technical computing with a 1U server node (4 nodes in CX400 M7)
  • Best performance with the 4th generation of Intel® Xeon® Processor Scalable Family (up to 32 cores/CPU)
  • 16x DDR5 DIMM slots with high memory bandwidth of up to 4800 MT/s ideal for memory intensive workloads
  • DynamicLoM adapter via OCP V3 and the new PCIe 5th Generation slots
  • Scale capacity and performance with up to two 2.5” SATA or PCIeSSD storage devices per node

Read More

Fujitsu Server PRIMERGY CX2560 M7

  • Ideal solution for virtualization and cloud scenarios with maximum power and security
  • 4th generation of Intel® Xeon® Processor Scalable Family brings the highest performance
  • 24 memory slots supporting up to 6TB with DDR5 DIMM modules
  • Gain storage flexibility 6 (4x SATA/SAS + 2x (SATA/PCIeSSD) or 6 PCIeSSD per node
  • DynamicLoM adapter via OCP V3 and 3 new PCIe 5th Generation slots

Read More
×
Fujitsu PRIMERGY RX1330 M6 Fujitsu Server PRIMERGY RX1330 M5 Fujitsu PRIMERGY RX2530 M7 Fujitsu PRIMERGY RX2540 M7 Fujitsu PRIMERGY RX1440 M2 Fujitsu PRIMERGY RX2450 M2 Fujitsu PRIMERGY RX4770 M7 Fujitsu PRIMERGY RX8770 M7 Fujitsu PRIMERGY TX1310 M5 Fujitsu PRIMERGY TX1320 M5 Fujitsu PRIMERGY TX1320 M6 Fujitsu Fujitsu PRIMERGY TX1330 M5 Fujitsu PRIMERGY TX1330 M6 Fujitsu PRIMERGY TX2550 M7 Fujitsu PRIMERGY GX2560 M7 Fujitsu PRIMERGY CX400 M7 Fujitsu PRIMERGY CX2550 M7 Fujitsu Server PRIMERGY CX2560 M7
Chipset Intel® C266
 Intel® C256
 Intel® C741
 Intel® C741
 System on Chip (SoC)
 System on Chip (SoC)
 Intel® C741
 Intel® C741
 Intel® C256
 Intel® C256
 Intel® C266
 Intel® C256
 Intel® C266
 Intel® C741
 - - Intel® C741
 Intel® C741
Mainboard type D4133
 D3929
 D3982
 D3983
 D4130
 D4129
 D3984
 D4029
 D3930
 D3931
 D4132
 D3931
 D4132
 D3985-A
 MBD-X13DGU
 - D 3988
 D 3989
Product Type Mono Socket Rack Server
 Mono Socket Rack Server
 Dual Socket Rack Server
 Dual Socket Rack Server
 Mono Socket Rack Server
 Dual Socket Rack Server
 Quad Socket Rack Server
 - Mono Socket Tower Server
 Mono Socket Tower Server
 - - - Dual Socket Tower Server
 Dual Socket Rack Server
 Multi-Node Server Chassis
 Dual Socket 1U Server Node
 Dual Socket 1U Server Node
Processor Intel® Xeon® E-2400 processor family, Intel® Pentium® processor
 Intel® Xeon® E-2300 processor family, Intel® Pentium® processor
 Intel® Xeon® Bronze 3xxx processor, Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor
 Intel® Xeon® Bronze 3xxx processor, Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor
1 - 2 x Intel® Xeon® Processor Scalable Family
 AMD EPYC™ 9004 series processor
1 x AMD EPYC™ 9004 series processor
 AMD EPYC™ 9004 series processor
1 - 2 x AMD EPYC™ 9004 series processor
 Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor
2 or 4
 Intel® Xeon® Platinum 84xxH processors
up to 8
 Intel® Xeon® E-2300 processor family, Intel® Pentium® processor
1 x Intel® Xeon® E-2300 processor family, Intel® Pentium® processor
 Intel® Xeon® E-2300 processor family, Intel® Pentium® processor
 Intel® Xeon® E-2400 processor family, Intel® Pentium® processor
 Intel® Xeon® E-2300 processor family, Intel® Pentium® processor
 Intel® Xeon® E-2400 processor family, Intel® Pentium® processor
 Intel® Xeon® Bronze 3xxx processor, Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor
 Intel® Xeon® Gold 54xx processor, Intel® Xeon® Gold 64xx processor, Intel® Xeon® Platinum 84xx processor
 Intel® Xeon® Silver 43xx processor, Intel® Xeon® Gold 53xx processor
 Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Silver 4xxx processor
 Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor
Memory 16 GB - 128 GB, UDIMM (DDR5)
 8 GB - 128 GB, UDIMM (DDR4)
 16 GB - 8 TB, DIMM (DDR5)
 16 GB - 8 TB, DIMM (DDR5)
 16 GB - 6 TB, DIMM (DDR5)
 16 GB - 6 TB, DIMM (DDR5)
 16 GB - 16 TB, DIMM (DDR5)
 128 GB - 32 TB, DIMM (DDR5)
 8 GB - 128 GB, UDIMM (DDR4)
8 GB - 32 GB, DIMM (DDR4)
 8 GB - 128 GB, UDIMM (DDR4)
 16 GB - 128 GB, UDIMM (DDR5)
 8 GB - 128 GB, UDIMM (DDR4)
 16 GB - 128 GB, UDIMM (DDR5)
 16 GB - 4.0 TB, DIMM (DDR5)
 64 GB - 2 TB
 12 TB
 8 GB - 4 TB, DIMM (DDR5)
8 GB - 4096 GB
 8 GB - 6 TB, DIMM (DDR5)
8 GB - 6144 GB
Memory slots 4
4
32 (16 DIMMs per CPU, 8 channels with 2 slots per channel)
 32 (16 DIMMs per CPU, 8 channels with 2 slots per channel)
 24 (24 DIMMs per CPU)
 24 (12 DIMMs per CPU)
 64 (16 DIMMs per CPU, 8 channels with 2 slots per channel)
 128 (16 DIMMs per CPU, 8 channels with 2 slots per channel)
 4
4
4
4
4
16 (8 DIMMs per CPU, 8 channels with one DIMM per channel)
 32
96
16 (8 DIMMs per CPU, 8 channels with 1 slot per channel)
 24 (12 DIMMs per CPU, 8 channels with 2 slots per channel)
Memory protection ECC
 ECC
 ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
 ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
 Advanced ECC
 Advanced ECC
 ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
 ECC, Memory Mirroring support, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction)
 ECC
 ECC
 ECC
 ECC
 ECC
 ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
 - - ECC, Memory Scrubbing, SDDC
 ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support
Drives (optional) DVD supermulti, ultraslim, SATA I
 DVD supermulti, ultraslim, SATA I
 DVD supermulti, ultraslim, SATA I
 LTO7HH Ultrium, 300 MB/s
DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s
LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s
 DVD supermulti, ultraslim, SATA I
 LTO7HH Ultrium, 300 MB/s
DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s
LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s
 DVD supermulti, ultraslim, SATA I
 - DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
 DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
 DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
 LTO7HH Ultrium, 300 MB/s
DVD-ROM, half height, SATA I
DVD Super Multi, half height, SATA I
DVD supermulti, ultraslim, SATA I
Blu-ray Disc™ Triple Writer, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s
LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s
 CD-RW / DVD Combo, ultraslim, SATA III
DVD-ROM, ultraslim, SATA III
LTO7HH Ultrium, 300 MB/s
DVD supermulti, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s
LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s
 LTO7HH Ultrium, 300 MB/s
DVD-ROM, half height, SATA I
DVD Super Multi, half height, SATA I
DVD supermulti, ultraslim, SATA I
Blu-ray Disc™ Triple Writer, ultraslim, SATA I
RDX Drive, 100 MB/s, 320 GB, 500 GB, 1 TB, 2 TB, USB 3.0
LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s
LTO7HH Ultrium, 300 MB/s, SAS 6Gb/s
 - - - -
Accessible drive bays 1 x 5.25/9.5mm for DVD-RW/Blu-ray
 1 x 5.25/9.5mm for DVD-RW/Blu-ray
 1 x 5.25/9.5mm for DVD-RW/Blu-ray
 1 x 5.25/9.5mm for DVD-RW/Blu-ray
1 x 5.25/0.4-inch for CD-RW/DVD
 1 x 5.25/9.5mm for DVD-RW/Blu-ray
 1 x 5.25/9.5mm for DVD-RW/Blu-ray
1 x 5.25/0.4-inch for CD-RW/DVD
 - - 1 x 5.25/9.5mm for DVD-RW/Blu-ray, 1 x 5.25/1.6-inch for backup devices
 1 x 3.5/1.6-inch for backup devices, 1 x 5.25/9.5mm for DVD-RW/Blu-ray
1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.4-inch for CD-RW/DVD
 1 x 3.5/1.6-inch for backup devices, 1 x 5.25/9.5mm for DVD-RW/Blu-ray
1 x 3.5/1.6-inch for backup devices, 1 x 5.25/0.4-inch for CD-RW/DVD
 3 x 5.25/1.6-inch
Accessible drive bays are not available in case of max. storage drive configuration
3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD
 3 x 5.25/1.6-inch
Accessible drive bays are not available in case of max. storage drive configuration
3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD
 3 x 5.25/1.6-inch
 - - - -
Optional accessible drives Not for 10x 2.5-inch HDD base unit. All possible options described in relevant system configurator.
 Not for 10x 2.5-inch HDD base unit. All possible options described in relevant system configurator.
 2x 2.5-inch hot-plug SAS/SATA rear option
Ultra slim 9.5mm optical drive (optional)
n/a
Not for 10x 2.5-inch base unit. All possible options described in relevant system configurator.
 ODD 5.25" possible
ODD 5.25" NOT possible
All possible options described in relevant system configurator.
 Ultra slim 9.5mm optical drive (optional)
All possible options described in relevant system configurator.
 ODD 5.25" possible
All possible options described in relevant system configurator.
 1 x 5.25/9.5mm for DVD-RW/Blu-ray
All possible options described in relevant system configurator.
 - - - - all possible options described in relevant system configurator
 all possible options described in relevant system configurator
 3x 1.6x5.25" bays for an optical and/or backup drives
All possible options described in relevant system configurator.
 - - - -
Storage drive bays 4/8 x 2.5-inch hot-plug SATA/SAS or 4x 3.5-inch hot-plug or 10 x 2.5-inch hot-plug SATA/SAS
Max. 8x 2.5-inch
Max. 4x 3.5-inch
4x 2.5-inch
Max. 10x 2.5-inch
 4/8 x 2.5-inch hot-plug SATA/SAS (Up to 4x NVMe PCIe SSD supported) or 4x 3.5-inch hot-plug or 10 x 2.5-inch hot-plug SATA/SAS
Max. 4x 3.5-inch
Max. 8x 2.5-inch
Max. 10x 2.5-inch
4x 2.5-inch
 up to 4 x 3.5-inch, 8 x 2.5-inch, 10 x 2.5-inch base unit
up to 8x 2.5" (SFF) hot plug drives (SAS/SATA)
up to 4x 3.5" (LFF) hot plug drives (SAS/SATA)
up to 10x 2.5" (SFF) hot plug drives (SAS/SATA)
up to 10x 2.5" (SFF) hot plug drives (SAS/SATA/PCIe SSD)
up to 10x 2.5" (SFF) hot plug drives (SATA/PCIe SSD)
 up to 16x 2.5-inch, 24x 2.5-inch, 10x 3.5-inch or 12x 3.5-inch base units
10 x 3.5-inch hot-plug SAS/SATA
12 x 3.5-inch hot-plug SAS/SATA
16 x 2.5-inch hot-plug SAS/SATA
16 x 2.5-inch hot-plug SAS/SATA/PCIe
24 x 2.5-inch hot-plug SAS/SATA
 Up to 10: 10x 2.5-inch SATA/SAS/NVMe (PCIe SSD)
up to 8x 2.5" (SFF) hot-plug drives (SAS/SATA)
up to 4x 3.5" (LFF) hot-plug drives (SAS/SATA)
up to 10x 2.5" (SFF) hot-plug drives (PCIe_NVMe)
 up to 16x 2.5-inch, 24x 2.5-inch, 10x 3.5-inch or 12x 3.5-inch base units
16 x 2.5-inch hot-plug PCIe/SAS/SATA SSD or 2x 2.5-inch hot-plug SAS/SATA HDD
8 x 3.5-inch hot-plug SAS/SATA
12 x 3.5-inch hot-plug SAS/SATA
24 x 2.5-inch hot-plug SAS/SATA/PCIe
8 x 2.5-inch hot-plug SAS/SATA
24 x 2.5-inch
16 x 2.5-inch hot-plug SAS/SATA
 2.5-inch hot-plug SAS/SATA/PCIe
2 x M.2 slots
8 x 2.5-inch hot-plug SAS/SATA/PCIe
24 x 2.5-inch hot-plug SAS/SATA/PCIe
Optional expandable up to 16 storage drives
 up to 24 x 2.5-inch hot-plug SAS/SATA/PCIe
24 x 2.5-inch hot-plug SAS/SATA/PCIe
 4 x 3.5-inch cold-plug SATA
 3.5-inch non hot-plug or 2.5-inch hot-plug SAS/SATA or 2.5-inch NVMe drives
Max. 8x (4x + 4x) x 2.5-inch hot-plug
Max. 2 x 3.5-inch non hot-plug SATA
 3.5-inch non hot-plug or 2.5-inch hot-plug SAS/SATA
Max. 8x (4x + 4x) x 2.5-inch hot-plug
Max. 2 x 3.5-inch non hot-plug SATA
 3.5-inch or 2.5-inch hot-plug SAS/SATA or 2.5-inch NVMe drives
Max. 12x 3.5-inch or 24x 2.5-inch
Max. 4x 3.5-inch or 8x 2.5-inch
 3.5-inch or 2.5-inch hot-plug SAS/SATA
Max. 12x 3.5-inch or 24x 2.5-inch
Max. 4x 3.5-inch or 8x 2.5-inch
 3.5-inch or 2.5-inch hot-plug SAS/SATA
8 x 2.5-inch hot-plug SAS/SATA
8 x 3.5-inch hot-plug SAS/SATA
24 x 2.5-inch hot-plug SAS/SATA
4 x 3.5-inch hot-plug SAS/SATA
Optional expandable up to 24 storage drives
Optional expanderble up to 12 storage drives
optional expanderble up to 32 storage drives
not expandable
optional expandable up to 8 storage drives
optional expandable up to 12 storage drives
optional expandable up to 24 storage drives
optional expandable up to 32 storage drives
 6x SAS/SATA/NVMe x 2.5-inch
8 x 2.5-inch hot-plug
 24x 2.5" drive or HDD less configuration x 2.5-inch hot-plug
 up to 2x 2.5-inch drive bay per node (in the PRIMERGY CX400 M7 chassis), and 2x M.2 device (in the CX2550 M7 node)
 up to 6x 2.5-inch drive bay per node (in the PRIMERGY CX400 M7 chassis), and 2x M.2 device (in the CX2560 M7 node)
LAN Controller Intel® i210 onboard
2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration)
 Intel® i210 onboard
2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration)
 Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28
Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28
Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28
Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28
Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adaptors:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28
Intel® i210 onboard
10/100/1000 Mbit/s Ethernet
 Intel® i210 onboard
2 x 1 Gbit/s Ethernet (RJ45)
 Intel® i210 onboard
2 x 1 Gbit/s Ethernet (RJ45)
 Intel® i210 onboard
2 x 1 Gbit/s Ethernet (RJ45)
 Intel® i210 onboard
2 x 1 Gbit/s Ethernet (RJ45)
 Intel® i210 onboard
2 x 1 Gbit/s Ethernet (RJ45)
 2 x 1 Gbit/s onboard
 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP+, 2x 100 Gbit/s QSFP28
- BCM5727 (On board LAN) (on D3893-Axx)
10/100/1000 Mbit/s Ethernet
 Intel X550 (Onboard LAN) (on D3989-A1x)
10/100/1000/10000 Mbit/s Ethernet
Remote Management Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
 Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
 Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller), IPMI 2.0 compatible
 Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller), IPMI 2.0 compatible
 Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
 Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
 Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller), IPMI 2.0 compatible
 Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
 - - - - - IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
 IPMI 2.0 compatible
 - IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
 IPMI 2.0 compatible, Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller)
USB ports 7 (Rear: 4x 3.2 Gen1 for all base units, Front (except 10x 2.5” base unit): 2x USB 3.2 Gen1, 1x USB 3.2 Gen2(20 Gb, Type
C) , Front (for 10x 2.5” base unit): 2x USB 3.2 Gen1)
 5 (Rear: 2x 3.2 Gen1 for all base units, Front (except 10x 2.5" base unit): 2x USB 3.2 Gen1, 1x USB 3.2 Gen2(20 Gb, Type C) , Front (for 10x 2.5" base unit): 2x USB 3.2 Gen1)
 5 x USB 3.0 (2x front, 2x rear, 1x internal)
 5 x USB 3.0 (2x front, 2x rear, 1x internal)
 4 x USB 3.0 (2x rear, 2x front)
 2 x USB 3.0 (2x rear, 1x internal)
 5 x USB 3.1 Gen1(USB3.0) (2x front, 2x rear, 1x internal)
 2 USB 3.1 (2x rear)
 5 (Front: 1x USB 3.2 Gen2x2(20 Gbps) Type C, 1x USB 3.2 Gen1x1(5 Gbps) / Rear:, USB 3.2 Gen2x1(10 Gbps) / Internal: 1x USB 3.2 Gen1x1(5 Gbps))
 6 (Front: 1x USB 3.2 Gen2x2(20 Gbps) Type C, 1x USB 3.2 Gen1x1(5 Gbps) / Rear:, 2x USB 3.2 Gen2x1(10 Gbps) / Internal: 2x USB 3.2 Gen1x1(5 Gbps))
 9 (Front: 1x USB 3.2 Gen2x2(20 Gbps) Type C, 1x USB 3.2 Gen1x1(5 Gbps) / Rear:, 6x USB 3.2 Gen1x1(5 Gbps) /
Internal: 1x USB 3.2 Gen1x1(5 Gbps))
 6 (Front: 1x USB 3.2 Gen2x2(20 Gbps) Type C, 1x USB 3.2 Gen1x1(5 Gbps) / Rear:, 2x USB 3.2 Gen2x1(10 Gbps) / Internal: 2x USB 3.2 Gen1x1(5 Gbps))
 9 (Front: 1x USB 3.2 Gen2x2(20 Gbps) Type C, 1x USB 3.2 Gen1x1(5 Gbps) / Rear:, 6x USB 3.2 Gen1x1(5 Gbps) /
Internal: 1x USB 3.2 Gen1x1(5 Gbps))
 8 x USB 3.1 Gen1(USB3.0) (2x front, 4 x rear, 1x USB 3.1 Gen1 for backup devices)
 2
- 2 x USB 3.0 (rear) with high density connector
 2 x USB 3.0 (rear) with high density connector
Graphics 1 x VGA (15-pin) / optional 1 x front VGA (not for 10x 2.5” base unit)
 1 x VGA (15-pin) / optional 1 x front VGA (not for 10x 2.5” base unit)
 2 x VGA (thereof 1x front optional - not for base unit with 10x 2.5” devices)
 2 x VGA (thereof 1x front optional - not for base unit with 12x 3.5” and 24x 2.5" drives)
 1 x VGA (1x rear)
 1 x VGA (1x rear)
 1 x VGA (1 x rear, 1 x front(Optional))
 2 (1x rear display port), (1x front VGA)
 1 x Display Port (Integrated processor graphics)
 2 (1x Display Port (Integrated processor graphics) / 1x VGA (15-pin) / can be used exclusively)
 1 x VGA (15-pin)
2 (1x Display Port (Integrated processor graphics) / 1x VGA (15-pin) / can be used exclusively)
 1 x VGA (15-pin)
 1 x VGA(1 x rear, 1 x front(Optional))
 - - 1 x VGA (1x rear) with high density connector
 1 x VGA (1x rear) with high density connector
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
 - 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s), Management LAN traffic can be switched to shared onboard Gbit LAN port
 Management LAN traffic can be switched to shared onboard LAN port, 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s)
 - - - Management LAN traffic can be switched to shared onboard Gbit LAN port
Trusted Platform Module (TPM) TPM 2.0 module (option)
 TPM 2.0 module (option)
 Infineon / TPM 2.0 module; TCG compliant (option)
 Infineon / TPM 2.0 module; TCG compliant (option)
 Infineon / TPM 2.0 module; TCG compliant (option)
 Infineon / TPM 2.0 module; TCG compliant (option)
 Infineon / TPM 2.0 module; TCG compliant (option)
 TPM 2.0 module
 TPM 2.0 module (option)
 TPM 2.0 module (option)
 TPM 2.0 module (option)
 TPM 2.0 module (option)
 TPM 2.0 module (option)
 optional TPM
 - - - optional TPM
Power supply configuration 1x standard power supply or 1x hot-plug power supply or 2x hot-plug power supplies for redundancy depending on model
 1x standard power supply or 1x hot-plug power supply or 2x hot-plug power supplies for redundancy depending on model
 1 x hot-plug power supply or 2 x hot-plug power supply for redundancy
 1 x hot-plug power supply or 2x hot-plug power supply for redundancy
 1x hot-plug power supply or 2x hot-plug power supply for redundancy
 1x hot-plug power supply or 2x hot-plug power supply for redundancy
 3 hot-plug power supplies (standard)
 hot-plug PSU, min. 4 / max. 6x per system
 1 x standard power supply
 1 x standard, 1 x hot-plug, 2 x hot-plug redundant (depending on
Model)
 1 x standard, 1 x hot-plug, 2 x hot-plug redundant (depending on
Model)
 1 x standard, 1 x hot-plug, 2 x hot-plug redundant (depending on
Model)
 1 x standard, 1 x hot-plug, 2 x hot-plug redundant (depending on Model)
 1x non hot-plug power supply or 2x hot-plug power supply for redundancy or 2x non hot-plug power supply
 - - - -
Active power (max. configuration) 494 W
 1,088 W
 2,608 W
 2,608 W
 2,608.6 W
 2,608.6 W
 3,700 W
 8,298.2 W
 284 W
 613 W
 477 W
 1,088 W
 507 W
 2,758 W
 5,347 W
 - - -
Weight Standard: max.13.1 kg [17.7 kg(including RMK/CMA)]
Short depth: max. 9.5 kg [13.8 kg(including RMK/CMA)]
 Std: max.13 kg / Short depth: max. 10 kg
 Std: max. 19.2 kg / Short depth: max. 16.6 kg
 max. 32 kg
 up to 18.9 kg
 up to 34.1 kg
 max. 40 kg
 approx. 105 kg
 up to 11 kg
 up to 11.1 kg
 up to 11.4 kg
 up to 26.4 kg
 Floor system: max.28.8 kg
Rack system: max. 25.8 kg [31.3 kg(including RMK/CMA)]
 Up to 41.9 kg
 - approx. 28-43 kg
 5.1 kg
 4.9 kg
Rack (W x D x H) 483 mm (Bezel) / 436 mm (Body) x 556 (including protrusion: 612) x 43 mm
 482.6 mm (Bezel) / 435.4 mm (Body) x 612 x 43 mm
 483 mm (Bezel) / 435 mm (Body) x 808 x 43 mm
 482.5 mm (Bezel) / 435 mm (Body) x 800 x 86.9 mm
 483 x 842 x 43 mm
 435 x 813 x 87 mm
 482.6 mm (Bezel) / 435 mm (Body) x 800 x 129.4 mm
 447.0 x 830.6 x 266.7 mm
 - - - 482.6 x 495.3 x 174.7 mm
 484 mm (Bezel) / 448 mm (Body) x 492 (including protrusion: 555) x 175 mm
 483 (Bezel); 448 mm (body) x 772 x 175 mm
 483 x 869 x 176 mm
 480 mm (w/ bezel) / 443.5 mm (body) x 860 x 86.5 mm
 - -
DC Infrastructure Management Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Please see "Management Notes" section
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
Operating system http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 - http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
 http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Warranty period 1 year
 1 year
 3 years
 3 years
 3 years
 3 years
 3 years
 3 years
 1 year
 1 year
 1 year
 1 year
 1 year
 3 years
 3 years
 3 years
 3 years
 3 years
Warranty type Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty Warranty conditions tbd
 Onsite warranty
 Onsite warranty
 Onsite warranty
 Onsite warranty
Service Lifecycle at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 5 years after end of product life
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 5 years
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
 at least 5 years after shipment, for details see https://support.ts.fujitsu.com/
Service Weblink http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/emeia/products/product-support-services/
 http://www.fujitsu.com/fts/products/product-support-services/
http://www.fujitsu.com/fts/products/product-support-services/
http://www.fujitsu.com/fts/products/product-support-services/
http://www.fujitsu.com/fts/products/product-support-services/
http://www.fujitsu.com/fts/products/product-support-services/
http://www.fujitsu.com/fts/products/product-support-services/
http://www.fujitsu.com/emeia/products/product-support-services/
 https://www.fujitsu.com/emeia/support/
 https://www.fujitsu.com/emeia/support/
 https://www.fujitsu.com/emeia/support/
PCI-Express 3.0 x4 - 1 x Low profile
- - - - - - 2 x Full height, up to 215 mm length
2 x Low profile
- 2 x Full height
- - - - - -
PCI-Express 4.0 x8 - 2 x Low profile
- - - - - - - 2 x Low profile (2x PCIe 4.0 x8 slots can be switched to 1x PCIe 4.0 x16)
 - 2 x Full height (2x PCIe 4.0 x8 slots can be switched to 1x PCIe 4.0 x16)
 - 8 x Full height Note: Refer to Slot Notes.
 - - - -
PCI-Express 4.0 x16 - - 1 x Low profile
1 x Low profile
- - 4 x Full height Refer to Slot Notes.
 - 1 x Full height
- - - - 4 x Full height Note: Refer to Slot Notes.
 - - 2 x low profile (via riser card)
 -
Mounting Depth Rack - - Std: 836.95 mm / Short depth: 756.95 mm
 873.1 mm
 - - 830.6 mm
 - - - - - - - - 812.8 mm
 - -
Server Management - - ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
 ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
 ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
 ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
 ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
 ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Agentless Service (SVAS), ServerView Update Manager Express (UME)
 - - - - - ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME)
 - Infrastructure Manager (ISM)
Essential Edition
Advanced Edition, ServerView Suite
 Infrastructure Manager (ISM)
Essential Edition
Advanced Edition, ServerView Suite
 ServerView Suite, Infrastructure Manager (ISM)
Essential Edition
Advanced Edition
Floor-stand (W x D x H) - - - - - - - - 180 x 313 x 379 mm
 98 x 400 x 340 mm
 98 (with foot stand: 193) x 400 (including protrusion: 440) x 340 (with foot stand: 360) mm
 177.2 x 521.7 x 456.2 mm
 178 x 521 (including protrusion: 551) x 448 (with feet: 457) mm
 177 x 776 x 456 mm
 - - - -
×

Solutions to maximize value and performance

Insights

Fujitsu uSCALE pay-per-use

Fujitsu uSCALE provides flexible on-premises IT infrastructure and services. These sustainable and scalable pay-per-use capabilities enable you to leverage your business potential. Choose the appropriate services you need to accelerate your digital transformation journey and de-risk your infrastructure investments with a cloud-like consumption model – where you only pay for what you use.

More info

Beyond the infrastructure



Find out how Fujitsu can help you excel in a connected data-driven word

Modernize with Windows Server 2022: The cloud-ready operating
system that boosts on-premises investments with hybrid capabilities.
